Summary of Contents for Electrolux EWF7524CDWA
- Page 1 ELECTROLUX HOME PRODUCTS PTY LTD ABN 51 004 762 341 Issue: 5 Technical Publication Nº WMSI1008 Date: 10/22 SERVICE MANUAL Electrolux FRONT LOAD WASHING MACHINE & WASHER/DRYER © Copyright 2019 ELECTROLUX HOME PRODUCTS PTY LTD, Technical Services Classified as Internal...
- Page 2 Intentionally Blank Page Table of Contents Page 2 WMSI1008 Classified as Internal...
- Page 3 SAFETY INFORMATION Under NO circumstances should any service work be carried out unless you are qualified and licensed as per Federal, State and Territory requirements. General Safety • Work should not be under taken on any electrical appliance without first checking the earthing integrity of the appliance and electrical supply.
- Page 4 TOOLS • Standard socket and screwdriver set • T20 Torque Screw Bit Table of Contents Page 4 WMSI1008 Classified as Internal...
- Page 5 SAFETY INFORMATION ........................3 TOOLS ..............................4 DIAGNOSTICS & ALARM CODES ......................9 CONTROL PANELS & DESCRIPTIONS ..................... 9 EWF7524CDWA & EWF8524CDWA & EWF8024CDWA & EWF9024CDWA ........9 EWF1042BDWA ..........................10 EWF9043BDWA ..........................11 EWW7524ADWA ........................... 12 EWW9043ADWA ........................... 13 EWW1042ADWA ...........................
- Page 6 E60 ..............................49 E70 ..............................51 E80 ..............................52 E90 ..............................53 EA ..............................55 EB ..............................55 EC ..............................57 ED ..............................59 EE ..............................63 EF ..............................65 DIAGRAMS ............................67 BLOCK DIAGRAM – WASHING MACHINE ..................67 WIRING DIAGRAM –...
- Page 7 CONTROL PANEL ..........................96 USER INTERFACE ........................... 98 WiFi PCB (NIUX) ..........................99 ANALOGUE PRESSURE SWITCH ....................99 DETERGENT DISPENSER ......................100 DETERGENT DISPENSER ......................101 DETERGENT FILL PIPE ......................... 102 UPPER COUNTERWEIGHT ......................102 ACCESSING THE FRONT PART ....................102 DOOR HINGE - DOOR ........................
- Page 8 POWER FAN (DRYING FAN) ...................... 124 NTC SENSOR (humidity control) ....................125 Table of Contents Page 8 WMSI1008 Classified as Internal...
- Page 9 DIAGNOSTICS & ALARM CODES CONTROL PANELS & DESCRIPTIONS EWF7524CDWA & EWF8524CDWA & EWF8024CDWA & EWF9024CDWA Table of Contents Page 9 WMSI1008 Classified as Internal...
- Page 10 EWF1042BDWA Table of Contents Page 10 WMSI1008 Classified as Internal...
- Page 11 EWF9043BDWA Table of Contents Page 11 WMSI1008 Classified as Internal...
- Page 12 EWW7524ADWA Table of Contents Page 12 WMSI1008 Classified as Internal...
- Page 13 EWW9043ADWA Table of Contents Page 13 WMSI1008 Classified as Internal...
- Page 14 EWW1042ADWA Table of Contents Page 14 WMSI1008 Classified as Internal...
- Page 15 EWF1041ZDWA EWF1041R9WB Table of Contents Page 15 WMSI1008 Classified as Internal...
- Page 16 COMMON FUNCTIONALITIES On/Off Button These models have a dedicated mechanical tact-switch button for On/Off function always present. The Off function does not disconnect the machine from the mains supply, but put the appliance in a special low power consumption mode. The 0-Watt power consumption circuit that completely disconnects machine from the mains supply is not supported in Project ONE AEG range based on EWX13 and EWX14 main board electronic platforms.
- Page 17 Compared to a traditional absolute selector, the Hi-fi one has no index on the knob and no reset position. The knob itself doesn’t point to any position in the control panel; hence the selected programme is indicated by the associated LED. To reset a cycle in progress just press the On/Off button.
- Page 18 • manage a serial port to connect the machine to external devices for testing, configuration, remote control purpose (EAP protocol); The User Interface Board electronic control has the purpose to: • manage the user selections and the machine status display by driving Leds and LCDs, and by reading push buttons and/or rotary knobs, •...
- Page 19 DEMO MODE In the shops and exhibitions sometime it could be necessary to show to the customer the machine behaviour in set- up condition and also during cycle execution. The duration of a cycle execution is in any case too long for a brief show.
- Page 20 EWF7524CDWA & EWF8524CDWA Table of Contents Page 20 WMSI1008 Classified as Internal...
- Page 21 DIAGNOSTICS MODE This mode is used in several conditions: • In factory assembly line to perform a manual test of the machine functionality (final assembly test). • By service people to check for faults and repair the machine. • In the labs to check the right machine functionality. To access Diagnostics Mode for each model: DIAGNOSTICS MODE To access Diagnostics Mode...
- Page 22 Table of Contents Page 22 WMSI1008 Classified as Internal...
- Page 23 FOR ANY POSITION THERE IS A DIFFERENT TEST: POSITION VERSION DESCRIPTION EWX14 User Interface Test EWX14 Water load from wash compartment d2 extended EWX14 Water load from salt box, and pump activation (fast “Regeneration” process) EWX14 Water load from prewash compartment EWX14 Water load from softener compartment EWX14...
- Page 24 USER INTERFACE TEST Selector-test position: Position 1 in clockwise direction or in test sequence(LCD models) Purpose of test: To test the functionality of all lights, switches and buzzer. Activated components All LEDs, LCD display (if present) and buzzer UI behaviour with display: All LEDs in sequence, pushing a button correspondent LED is lit, the key number is shown on LCD and the buzzer sound.
- Page 25 FOURTH ELECTROVALVE TEST Selector-test position: Position 6 in clockwise direction or in test sequence (LCD MODELS). Purpose of test: To test the water loading from fourth electric valve (hot electric valve if present). Activated components Door lock device, fourth electric valve. UI behaviour with display: The clock digits report the actual water level (in mm) in the tub Working conditions:...
- Page 26 DRAIN AND SPIN TEST Selector-test position: Position 9 in clockwise direction or in test sequence (LCD MODELS) Purpose of test: To verify the machine during spin phase, the drain pump functionality, and pressure switch calibration procedure Activated components Door lock device, main motor, drain pump. UI behaviour with display: The clock digits report the actual drum speed in rpm divided by 10.
- Page 27 LAST ALARM DISPLAY AND POSSIBLE RESET Selector-test position: Position 11 in clockwise direction or in test sequence (LCD MODELS) Purpose of test: Display three latest alarms, starting from the most recent. last alarm and possible reset. Activated components UI behaviour with Alarm complete code is shown in the format Exx (E 4 2) display: UI behaviour without...
- Page 28 DIGITS DISPLAY The warnings are displayed on the 7-segments digits display used to show the cycle time. A specific code appears on digits while the buzzer sounds (also if deactivated by customer via buttons combination) with a specific sequence of 3 short beeps about every 20 seconds for maximum 5 minutes. After the problem has been solved, pressing Start/Pause push button the warning code is not shown anymore, buzzer stops sequence and cycle restarts.
- Page 29 In case of Series 9 or (LCD MODELS), some alarms considered as final customer warnings are shown only with a specific message on text line. If the WM/WD is in diagnostic mode and an alarm is raised, the code is always shown regardless of the configuration.
- Page 41 DEFINITION OF TERMS, ACRONYMS & ABBREVIATIONS Anti Boiling Cycle Configuration File D&L Density & Level sensors Detergent Dispenser DDWS Detergent Dispenser assemblies with integrated a Water Softener Diverter Motor Digital Signal Processors DiVerter Field Control Vectorial, generally used to indicate motor control board Flow-Meter sensor Hard EV Electro-Valve to load hard water in the DD...
- Page 42 ALARMS SOFTWARE MANAGEMENT DESCRIPTION E11 – Washing Water Load Timeout This alarm will be set when the water load timeout has been exceeded. As on the previous platform EWX11 and EWX13, the new EWX14911 has foreseen several timeouts depending on current water level amount. Precisely we have: •...
- Page 43 This alarm can be reset also pressing Start/pause button or resetting the current cycle. The alarm can be set according to water drain flow values. The machine calculates the drain pump flow rate monitoring the water level every 5 seconds. If the flow rate value decreases less a configured threshold the alarm will be set.
- Page 44 E31 – Electronic Pressure Switch Failure Frequency coming from electronic pressure switch is out of acceptable limits for at least 5 seconds. The alarm will be set after 2 consecutive attempts performed after a pause of 10 seconds. Valid values are 44.676 ÷ 36.130 Hertz. This fault can be caused by a defective electronic pressure switch or due to wiring/main boards problems.
- Page 45 E38 – Air Trap Clogged This alarm is set when we have no water level change during motor movement phases. The alarm appears if the pressure remains stable for at least 30 seconds. This condition can be caused by different causes: •...
- Page 46 The alarm appears if this situation persists for 3 seconds. Before stopping the machine, if the door closed sensing is ON (DOOR_CLOSED_S = ON), a safety drain cycle is performed to empty the machine because the safety is compromised. This alarm cannot be reset by pressing Start/Pause button. To clear the alarm is necessary reset the current cycle by switching off the machine.
- Page 47 E52 – No Tachometer Signal While motor is running, this alarm is set because of bad tachometer signal for example due to a no perfect connection of tachometer (unsettled contacts) or a high level of electromagnetic noise. When this condition is detected the Motor Control SW power off the motor and goes into a safety state waiting for an alarm reset command from MB.
- Page 48 (6A) is configurable via MB. The Motor Control Board power off the motor via software, than the DSP SW goes into a safety state waiting for an alarm reset command from MB. The alarm appears only after 5 trials during a normal cycle. Every trial is separated by 10 seconds of pause where the FCV board is switched off.
- Page 49 The alarm appears only after 5 trials during a normal cycle. Every trial is separated by 10 seconds of pause where the FCV board is switched off. At the end of last trial if the machine is still in the alarm situation the alarm code is memorized, the machine is stopped in safety conditions.
- Page 50 E66 – Heating Element Relay Failure. There is an incongruent situation between the heater relay sensing and the status of the heater relay that connects the washing or the drying heating element. This allows the detection of all possible faults conditions (relay not driven, relay contact glue closed or opened, sensing damaged) If the heaters relay sensing remains in the faulty conditions for a time longer than 3 seconds, some components might be damaged and the safety of the machine is compromised.
- Page 51 • Whereas in normal cycle mode the alarm will be set after a retrial when the heating element is activated for 10 seconds and after that was switched off and re-tested. If the faulty condition still persist the alarm will be set.
- Page 52 E72 – Output Drying NTC Failure The voltage value read on the NTC sensing is out of limits and it means that the NTC sensor is in open circuit or in short circuit. The limits are referred to the conversion steps of the A/D converter, the high value is 250 and the low value is 5.
- Page 53 In fact when the pump is switched off on the negative half wave we have to read a signal closed to 5 Volts. This alarm performs the safety drain cycle and forces the door opening. To clear this alarm it is necessary to reset the current cycle by switching off the machine. E85 –...
- Page 54 E92 – User Interface Mother Board Protocol Incongruence The communication protocol in between user interface and Main board is not aligned. This could be due to incompatible configuration between user interface and Main board. This alarm is checked at the power-ON and the machine is stopped.
- Page 55 E9C – User Interface Wrong Configuration Configuration wrongly or not received correctly by UI To clear the alarm is necessary reset the current cycle or pressing start/pause button at the end of cycle or simply switching off the machine. E9E – User Interface Touch Failure User Interface touch sensor not working.
- Page 56 EB3/EH3 – Power Supply Voltage Too Low The power supply voltage value is lower than the configured value (~175 Volt). The machine measures continuously the power supply voltage and if its value exceeds the configurable limit the machine starts the power failure management. At the restart the machine waits a stable voltage value and measures the reaching time needed, if it exceeds the 5 seconds timeout, the machine is blocked in alarm situation.
- Page 57 EBF/EHF – FCV Relay Sensing Failure The sensing of the FCV relay gives to the microprocessor a signal out of the limits. The limits are different depending on the half wave of the power supply and the value refers to the conversion steps of the A/D converter.
- Page 58 EC8 – TY5_Triac_Al Triac TY5 according to power board type can be used to drive motor fan, hot valve or the water softener board. On the below alarm description, the expression “Load” will refer to one of the previous listed loads (drive motor fan, hot valve or the water softener board).
- Page 59 ECB/EBH – Detergent Dispenser Water Softener board fault This alarm can happen if on the DDWS board there is at least one of the following faults: • Diverter position fault • Microcontroller Memory faulty • Power supply out of limits The alarm appears only after 5 trials during a normal cycle.
- Page 60 ED2 – WDM Heating Element Relay Failure There is an incongruent situation between the sensing of the relay that drives the drying heating1 relay and the output given by the microprocessor. The alarm appears if these situations persist for 5 seconds. This alarm skips the drying phase and tries to cool the machine.
- Page 61 To detect this conditions we have defined 2 different thresholds as follow: H_thrs= 3 * (VBULK_READ/4) – (VBULK_READ /16); L_thrs = VBULK_READ /2; According to these thresholds when the corresponding sensing reads a value greater than H_thrs we have the automatic thermostat opened.
- Page 62 EDA – WDM Power Supply Alarm There is no ZC signal or lower power supply for at least 5 seconds. Alarm will be cleared automatically when the ZC or the power supply signals return to nominal condition. This board can be configured to work at: •...
- Page 63 This alarm doesn’t allow the satellite board switching on. For this reason all phases that foreseen a satellite board action will be skipped. To clear this alarm it is necessary switch off the machine to reset the current cycle or press the Start/Pause button. EE1 –...
- Page 64 EE6 – Fan Over Voltage Alarm This alarm is set if the voltage input on the board is above282 Vrms for a time of 20 ms. This alarm is managed with an hysteresis and so to go out from this condition the input voltage goes below the value of 275 Vrms. The alarm will be set after 5 consecutive trials executed after a pause of 1 minute.
- Page 65 EF1 – Filter Clogged Warning The problem is put in evidence during a drain phase. If the virtual AB level doesn't go to empty state after a configurable time during a drain phase. The filter-clogged warning is displayed (on a dedicated led or on the display) only at cycle end. This warning happens before the Wash Drain Alarm.
- Page 66 EF7 - Dry Filter Alarm This warning is set when the air drying filter is not closed or missing. The warning is set after 1 minute of drying filter absence and the machine goes in pause state. The filter presence is detected by a micro switch positioned closed to the drying filter. For this reason a not appropriate warning can be set in case of micro switch not working properly.
- Page 67 IMPORTANT SAFETY NOTICE This diagram has been prepared for use by electrically qualified service technicians. Electrolux cannot be held responsible for the interpretation of its service publications nor for any injury or damage that may occur in connection with their use.
- Page 68 IMPORTANT SAFETY NOTICE This diagram has been prepared for use by electrically qualified service technicians. Electrolux cannot be held responsible for the interpretation of its service publications nor for any injury or damage that may occur in connection with their use.
- Page 69 IMPORTANT SAFETY NOTICE This diagram has been prepared for use by electrically qualified service technicians. Electrolux cannot be held responsible for the interpretation of its service publications nor for any injury or damage that may occur in connection with their use.
- Page 70 IMPORTANT SAFETY NOTICE This diagram has been prepared for use by electrically qualified service technicians. Electrolux cannot be held responsible for the interpretation of its service publications nor for any injury or damage that may occur in connection with their use.
- Page 71 PCB & COMPONENTS LAYOUT Table of Contents Page 71 WMSI1008 Classified as Internal...
- Page 72 TECHNICAL SPECIFICATIONS ELECTRICAL COMPONENTS • When replacing the pump, please refer to the code shown in the list of spare parts relating to the appliance. AutoDose Dispenser Please refer to a separate service instruction WMSI1012 regarding this component Table of Contents Page 72 WMSI1008 Classified as Internal...
- Page 73 Drain Pump – Aqua Control General Characteristics 1. Wheel 2. Rotor 3. Stator The pump, which drains the water at the end of the various washing cycle phases, is centrifugal and is activated by a synchronous motor. The rotor consists of a permanent magnet and the direction of rotation can be either clockwise or anticlockwise. It can turn by approximately a quarter of a revolution without turning the wheel.
- Page 74 Circulation Pump General Characteristics In models with Jetsystem washing, a synchronous circulation pump is fitted, which is designed to circulate water continuously, withdrawing it from the filter body and introducing it into the tub through the bellow seal. It is powered directly by the main circuit board via a triac and is fitted with a thermal cut-out.
- Page 75 “Concentrated Wash” Wash Pump General Characteristics The models featuring the “Concentrated Wash” are fitted with a synchronous pump, whose task it is to circulate the water in the cycle, to allow the detergent to break down and disperse fully, withdrawing it from the filter body and introducing it into the tub at the heating element height.
- Page 76 Aqua Control (where featured) General Characteristics The aqua control is a sensor positioned in contact with the bottom of the machine. It detects any water leakage from inside the washing machine and feeds the drain pump (not only during normal operation but also when the appliance is turned off with the plug inserted into the power socket).
- Page 77 Heating Element • When replacing the heating element, please refer to the code shown in the list of spare parts relating to the appliance. • It is strictly forbidden to tamper with the heating element in any way!!! (eg: changing the NTC probe, etc...) General Characteristics 1.
- Page 78 Temperature Sensor • When replacing the heating element, please refer to the code shown in the list of spare parts relating to the appliance. • It is strictly forbidden to tamper with the heating element in any way!!! (eg: changing the NTC probe, etc...) General Characteristics 1.
- Page 79 Analogue Pressure Switch General Characteristics 1. Small pipe 2. Core 3. Oscillating coil The pressure switch is connected via a pipe to the pressure chamber. When water is introduced into the tub, this creates a pressure inside the hydraulic circuit that causes the membrane to change position. This in turn modifies the position of the core inside the coil, thus changing the inductance and the frequency of the oscillating circuit.
- Page 80 Door Safety Interlock PTO (Pull to Open) General Characteristics This appliance is not fitted with a safety device featuring the traditional fastening latch which necessitated the removal of the handle to open the appliance door. The new safety device uses a new latch version with a hole in the middle, shown by the arrow (see figure) and you pull the handle to open the appliance door.
- Page 81 Operating Principle 1. Solenoid protection PTC2. Door safety interlock 2. Solenoid 3. Lifting assembly 4. Cam (with Labyrinth) 5. Locking pin 6. Electrical contacts (main switch) 7. Door sensing switch 8. Cursor 9. Manual opening When the program starts (start/pause button) the main circuit board sends a voltage pulse, lasting 20msec., to the solenoid valve (2) (at least 6 seconds should have passed since turning it on), which moves the cam (4) to a locking position;...
- Page 82 Mechanical Operation 1. Latch 2. Ratchet When the appliance door closes, the latch (1) fits inside the ratchet (2). Which, turning on itself, hooks onto and locks the ratchet in place. If the appliance is switched off or paused and the appliance handle is pulled, the latch is released from the ratchet (2), effortlessly, whereas if the START/PAUSE button has been pressed, the cursor (8) - being locked - does not allow the ratchet to turn (2) so the fastening latch is locked for the entire wash cycle.
- Page 83 Manual Opening of the Appliance Door Previous door safety devices released the door automatically, in the following cases: power failure, the appliance being turned off with the ON/OFF button (before the wash cycle ended, solenoid valve malfunction or faulty main board, because inside they had a PTC bi-metal which allowed the door to be opened after cooling, between 55 seconds and 4 minutes.
- Page 84 Triple-Phase Synchronous Motor with Permanent Magnets General Characteristics 1. Main electronic circuit board 2. Door safety interlock (with Door sensing switch) 2a Door safety interlock (without Door sensing switch) 13. Inverter 14. Motor X-Y-Z = Motor Windings Power supply to motor Three-phase power is fed by the inverter (13), which sends through connectors 5-6-7 the three phases to connectors 1-2-3 on the motor, where the windings (Y-X-Z) are connected.
- Page 85 Operating Principle The alternating current permanent magnets motor is a synchronous electric motor: the speed of rotation when stationary only depends on the frequency of power supply and it is independent of the load (torque at the axis). Like all electric motors, the permanent magnets motor consists of a stator and a rotor: both these components contribute to the production of torque by iteration between the respective magnetic fields.
- Page 86 Inverter - UIMC / EMC14 General Characteristics The EWX14 electronics use a new asynchronous motor, with 2 poles, three-phase, with high performance and low noise levels. “INVERTER” operating diagram = Phase = Neutral = “INVERTER” board = Motor = Condenser = Diodes I1÷6 = Switches...
- Page 87 Solenoid Valves General Characteristics SOLENOID VALVE SOLENOID VALVE TWO WAYS THREE WAYS This component introduces water into the detergent dispenser and is controlled electrically by the main circuit board via Triac. The level of water in the tub is controlled by the analogue pressure switch. 1.
- Page 88 Flowmeter General Characteristics Flowmeter Flowmeter 1. Main circuit board (2 WD) 5. Flow sensor (6 WD) Some models of solenoid valves have a built-in flow sensor, which measures the quantity of water in litres that is loaded into the appliance. In the event of a sensor failure, the water level is controlled by the analogue pressure switch.
- Page 89 Operating Principle of the Flowmeter The main components of the flowmeter are: Closed contact Open contact 1. Turbine (with magnet and counterweight mounted on the outside) Reed contact (normally open) Magnet Counterweight Signal 0 Signal 1 Water entering the solenoid valve rotates the turbine (1) and magnet (3), which passes in front of the Reed contact (2), thus closing it.
- Page 90 WM Main Electronic Control The electronic control is made up of: 1. Main electronic circuit board 2. Control/display circuit board 3. INVERTER motor control board (not shown in the figure, positioned at the bottom right of the appliance seen from the rear) 4.
- Page 91 Water Circuit ( Recic & CW pumps, Turbidity & Conductivity sensor) OKO Version Drain Circuit Ball lock ring Ball Pressure chamber Filter body tub tube Drain pipe Drain pump Filter body Filter or needle trap Filter dial seal Filter dial Locking lever seal Locking lever JET Version Drain Circuit...
- Page 92 Concentrated Wash (CW 2.0) 1. Tub drain pipe 2. Concentrated wash pump & scroll 3. CW Hose Operating Principle During the washing cycle, the electronic control powers the “Concentrated wash” pump (2) at set intervals, which suctions the water and detergent deposited in the drain circuit (1) and introduces them back into the circuit inside the tub (along pipe 3), so as to allow the full break-down and...
- Page 93 DISASSEMBLY / ASSEMBLY WORKTOP Remove the screws that secure it to the back panel. Pull it out from the back. MAIN BOARD(Washer) Remove the worktop (see relevant paragraph) Pull out the power supply cable from the hooks and from the connector Unfasten the two screws securing it to the cabinet Pull out the wiring of the hooks positioned at the rear of the main board box.
- Page 94 Remove the main board. Release the hooks securing the connectors protection on one side, then the other. Remove the connectors’ protection. Pull out the connectors positioned beside the board. Pull out the other connectors, taking care as they are retained by hooks. Table of Contents Page 94 WMSI1008 Classified as Internal...
- Page 95 MAIN BOARD (Washer/Dryer) Disconnect the connector: from the Push the main board assembly NTC probe (blue arrow). towards the inside of the Cut the clamp which secures the Remove the screws which secure appliance. wiring of the NTC probe (red the main board assembly to the arrow).
- Page 96 SOLENOID VALVE (2 or 3 way) Remove the worktop (see relevant paragraph). Disconnect the connectors. Pull out the pipes which connect the solenoid valve to the detergent dispenser. Unscrew the water fill pipe from the solenoid valve. Push the two retainers indicated by the arrows towards the inside of the appliance.
- Page 97 Remove the four screws which secure the crosspiece to the cabinet Remove the screws which secure the crosspiece to the detergent dispenser. Release the anchor tab which secures the detergent dispenser to the crosspiece. Raise both sides of the control panel so as to pull out the hooks which secure it to the front panel.
- Page 98 USER INTERFACE Remove the worktop (see relevant paragraph). Remove the control panel (see relevant paragraph). Remove the screws and release the hooks which secure the PCB assembly to the control panel. Disconnect it from the control panel and remove it from the two side pins. Selector light diffuser: To remove, unhook the hooks that fasten it to the control panel.
- Page 99 WiFi PCB (NIUX) WiFi PCB is located behind the User interface PCB. Unscrew the Philips head screw. Use a small srew driver to press the tab where indicated by blue arrow then slide the PCB in direction shown to remove. ANALOGUE PRESSURE SWITCH Remove the worktop (see relevant paragraph).
- Page 100 DETERGENT DISPENSER Remove the worktop (see relevant paragraph). Remove the control panel (see relevant paragraph). Pull out the pipes that connect it to the solenoid valves (cold water and where featured hot water) Unfasten the two screws securing it to the central crosspiece. Unfasten the screw in the clamp that fixes the detergent loading pipe to the tray, and remove it from its housing.
- Page 101 DETERGENT DISPENSER Remove the worktop (see relevant paragraph). Remove the control panel (see relevant paragraph). Pull out the pipes that connect it to the solenoid valves (cold water and where featured hot water) Unfasten the two screws securing it to the central crosspiece. Unfasten the screw in the clamp that fixes the detergent loading pipe to the tray, and remove it from its housing.
- Page 102 DETERGENT FILL PIPE Remove the worktop (see relevant paragraph). Remove the control panel (see relevant paragraph). Remove the detergent tray (see relevant paragraph). Pull out the pipe from the detergent dispenser after breaking/loosening the clamp between the detergent dispenser and the detergent loading pipe. When reassembling, use a new clamp with the same characteristics.
- Page 103 DOOR SAFETY INTERLOCK Manual Opening of the Appliance Door Note: Door handle or door covers shown in the pictures are a guide only. Different models may have slightly different look or colour. The functionality remains the same for all models. With the new safety device (PTO) the appliance door remains closed and necessitates manual door opening, according to the instructions provided below: Before proceeding with the manual opening of the appliance door, check:...
- Page 104 Replacing the Door Safety Interlock Remove the metal ring securing the bellow seal to the unit. Remove the part of the bellow seal concerned from the unit. (PTO) Push the pin at the top inwards and at the same time move the door safety device towards the left.
- Page 105 Remove the small rod from the pin (after removal, it stays in the vertical position). Pull a little of the wiring out of the protection and remove the connector. Disconnect the connector. Release the hook, remove the wiring and move it. Insert a flat-tip screwdriver into the slot near the hook.
- Page 106 BLADE This blade is secured to the drum with slides and secured with blades carved into the drum. To remove it from the drum: Insert a flat-tip screwdriver into hole 6 (see figure). Place the screwdriver with the handle tilted towards the right; push the left- hand tab down.
- Page 107 Before securing the new blade: Insert a screwdriver beneath the tabs and raise them a little. Position the new blade inside the drum guides. Push it towards the back. Insert the flathead screwdriver at a right angle to the blade (hole 6), so as to position it at the centre of the two tub tabs.
- Page 108 FRONT PANEL Remove the worktop (see relevant paragraph). Remove the control panel (see relevant paragraph). Remove door bellow seal from the front panel. Remove the door safety interlock. Tilt the washing machine towards the back. Unfasten the three screws securing the front panel at the bottom. NOTE: These models have round filter door which is attached to the front panel.
- Page 109 RECIRCULATION PUMP SYSTEM Recirculation pipe (1) Pull it out of the circulation pump, while you will have to break/widen the clamp from the bellow seal (when reassembling, use a new clamp with the same characteristics with size 20.5). If necessary, pull it out of the hooks that secure it to the side panel. When re-assembling the front panel make sure the small rod of the door safety device is correctly positioned (see “Door safety device”...
- Page 110 FRONT COUNTERWEIGHT Remove the worktop (see relevant paragraph). Remove the control panel (see relevant paragraph). Remove the iron ring securing the bellow seal to the front panel. Unfasten the screws securing the door safety interlock (see related paragraph). Remove the front panel (see relevant paragraph). Pull out the Jet pipe (see related paragraph).
- Page 111 Reference in the bellow seal. References. Reassemble the snap ring between the door bellow seal and the tub. Reposition the circulation pipe in its seat. Reassemble the iron ring between the door bellow seal and the cabinet. When re-assembling the front panel make sure the small rod of the door safety device is correctly positioned (see “Door safety device”...
- Page 112 DRAIN WATER CIRCUIT • Tub drain pipe. Remove the worktop (see relevant paragraph). Remove the control panel (see relevant paragraph). Remove the iron ring securing the bellow seal to the front panel. Unfasten the screws securing the door safety interlock (see related paragraph).
- Page 113 Make a note of the latch and hook with which it is secured to the tub. If the hook securing the chamber to the welded tub is broken, use the eyelet (indicated by the red arrow). Use a screw Code 405 50 33-52/8 (AF/2P 5x16 TE/SP must have a maximum length of 16 mm and without a tip to avoid perforating the tub), secure the chamber to the tub as shown by the arrow in the photo.
- Page 114 DRAIN PUMP and CONCENTRATED WASH Remove the worktop (see relevant paragraph). Remove the control panel (see relevant paragraph). Remove the iron ring securing the bellow seal to the front panel. Unfasten the screws securing the door safety interlock (see related paragraph). Remove the front panel (see relevant paragraph).
- Page 115 When reattaching the springs (after repair work which required their removal), make sure that the bushings shown in the figure are featured on both ends. Pay attention to the differences between the bushings (see enlarged details). Apply some grease on either end of the spring. Use grease. Attachment position of springs to top crosspiece.
- Page 116 When positioning the shock absorber inside the fastening (situated at the bottom of the cabinet or in the tub), take care when positioning the bushing, so as to insert the pin from the part of the bushing with the widest profile. The spare bushing is supplied under Code 344 91 25-30/5.
- Page 117 BELT Remove the back panel (see relevant chapter). Take the belt, turning the pulley, and remove it. When reassembling: Position the belt and align it with the centre of the pulley (Ø273mm) as shown in the figure. Turning the pulley, check that the belt positions itself and remains in the central part of the pulley.
- Page 118 Slide off the clamp. Push the washing unit towards the inside and pull out the inverter. By releasing the hooks on one side. Then on the other Pull out the wiring from the hooks securing it to the casing of the INVERTER.
- Page 119 When reassembling, repeat these steps in the reverse order. Beware that before you secure the Inverter to the cabinet with screws, the wiring is positioned inside the rails indicated by the arrows to avoid any wiring getting crushed. MOTOR Remove the back panel (see relevant chapter). Remove the belt (see relevant chapter).
- Page 120 AQUA CONTROL (some models) Remove the back panel (see relevant chapter). From the base of the cabinet, release the hooks that secure it to the base Remove the inverter (see relevant chapter). Lift the sensor. Remove the connector. REAR SHOCK ABSORBER Remove the back panel (see relevant chapter).
- Page 121 DRAIN HOSE\CABLING SUPPORT When fixing the drain pipe/cabling support make sure that the two stops (indicated by the red arrows) fit into their housings, locking the support to the unit. If the fixing is not stable and there is a risk of it coming out of its position, fasten the support to the unit with a screw (6.5x 3.5mm) screwed into the hole indicated by the blue arrow.
- Page 122 DRYER COMPONETS THERMOSTATS Auto-reset thermostat Remove the worktop (see relevant paragraph 15.1). Remove the connectors Loosen the screws that secure it to the conduit Replace the seal too. SAFETY THERMOSTAT Remove the connectors Loosen the two screws (Torx T20) that fix it to the conduit. Replace the seal too.
- Page 123 NTC PROBE (DRYING) Remove the worktop (see relevant paragraph). Remove the detergent dispenser 1) Loosen the two screws that secure the control panel to the detergent dispenser 2) Remove the two screws securing the detergent drawer to the crosspiece 3) Release the hook that secures the detergent dispenser to the crosspiece (blue arrow) 4) Pull the detergent dispenser out of the control panel Pull out the clamp from the crosspiece (blue arrow)
- Page 124 POWER FAN (DRYING FAN) Disconnect the connectors from: Remove the clamps that secure the Loosen the five pairs of screws the NTC probe power fan wiring and the NTC probe shown by the arrows which secure the thermostats to the support. the conduit to the welded tub.
- Page 125 NTC SENSOR (humidity control) Disconnect the connector Loosen the two screws that secure the sensory wiring support to the tub Remove the probe When reassembling the probe Insert the seal in its position and check that it is correctly in place Insert the probe Reposition the wire, tighten the two screws that secure it to the welded tub and insert the connector...
