- Page 2 Please read this manual for proper operation and keep it for future reference. Ultrasonic Blind Spot Detection System is designed for safety driving warning assistant only. It is the driver's responsibility to always drive safely. Step 1: Installation 1. Tools The diameter of drill bit depends on the sensors...
- Page 3 www.PyleUSA.com 3...
- Page 4 Step 2: Sensor Installation 1. The ideal height to mount L & R sensors (Up 7°) is about 60cm-70cm where the bumper is vertical to the ground, CL & CR sensors (0°) is about 50cm-65cm. Otherwise it may cause false alarm. 2.
-
Page 5: Function Introduction
Function Introduction Blind Spot Dectection Function (Blind spot detection are both for XY-BSD500-4 and XY-BSD500-2) System is activated when vehicle is driving. Detection area is 5m long and 2.5m wide at the rear side of vehicle. LED indicator turns ON if the sensor detects another vehicle that comes near the next lane. - Page 6 Notes for instaIIation, test and tips 1. Installation a. This product is applied to 12V battery vehicles, please read manual carefully before installation. b. To insure the length of cables t the vehicles and convenience of routing cables, please install control box at the left trunk. c.
- Page 7 Features: • Helps Driver Lane Changing Safely During Driving • With the Aid of 58KHZ Ultrasonic Sensor • Two Ultrasonic Sensors • Two Blind Regions Monitor (or LED Light) • With Buzzer and the Wire Harness, Perfect Connection of Ultrasonic and Computer •...
- Page 8 Questions? Comments? We are here to help! Phone: (1) 718-535-1800 Email: support@pyleusa.com...
