Instruction Manual
"PENSKY-MARTENS DIGITAL"
Product Code
B094 – B094N
Do not attempt to operate this equipment before reading
and comprehending the manual in all its parts
Users
|
|
|
|
MACHINE MANUFACTURERS
DRAUGHTSMEN
OPERATORS
MAINTENANCE WORKERS
ANY OTHERS
REV.
DESCRIPTION
MANAGED
APPROVED
PRODUCT CODE
PAGES
ISSUE DATE
04
User manual
K.Q.
Chief Technician
1/8
05/2019
B094.M01.EN.04
Matest S.p.a. Via delle Industrie 25, 24048 Treviolo (BG) Italy
+39 035 2055011
TEL.
info@matest.com | www.matest.com
Advertisement
Related Manuals for Matest B094
Summary of Contents for Matest B094
- Page 1 MACHINE MANUFACTURERS DRAUGHTSMEN OPERATORS MAINTENANCE WORKERS ANY OTHERS REV. DESCRIPTION MANAGED APPROVED PRODUCT CODE PAGES ISSUE DATE User manual K.Q. Chief Technician 05/2019 B094.M01.EN.04 Matest S.p.a. Via delle Industrie 25, 24048 Treviolo (BG) Italy +39 035 2055011 TEL. info@matest.com | www.matest.com...
- Page 2 Authorized to use the apparatus only the operators that has the knowledge of the method or is able to establish inside procedures of use of the same apparatus. The qualified operators are not able, however, in any case to work on the device for: Effect reparations Modify the components Use the apparatus for different uses from those imposed by the norm ASTM...
- Page 3 INTRODUCTION This machine is used for the dermination of the flash point of petroleum products according the ASTM D93, E502, IP 34, EN 22719, ISO 15267, ISO 2719, DIN 51578 Standards. The strirrer allows to perform both “A” and “B” methods. INSTRUMENT PRESENTATION Electrically heated by electronic regulator, mounted on a case painted with anti-acid epoxidic products.
- Page 4 TECHNICAL SPECIFICATIONS OF THE DEVICE Power Supply: 230V ±10%, 50/60Hz Power: 700W Dimensions: 40x33x52cm Weight: 11 Kg Working temperature: from 40 to 360°C Cooling: internal fan or external refrigerating unit Storage temperature: from -20 to +70°C Before any operation, please read carefully the “Warning information”. Be sure that all buttons are “OFF”...
- Page 5 “U” connector and connect it to gas ignitor, follow the laboratory security when use gas. Matest is not responsible if the laboratory security will not followed. THERMOMETER ASSEMBLING Connect the PT100 probe on rear of the instrument and insert it into the support on cover, the temperature...
- Page 6 D93. (NOTE: to perform immersion you must switch off sitter and than rotate the knob ) WARNING: Following ever the laboratory security when use gas, Matest is not responsible if the laboratory security is not followed. To more information about performing test, timing and sampling, regard the relative norm.
-
Page 7: Troubleshooting
TROUBLESHOOTING DAMAGE CAUSE REMEDY No voltage Provide power supply Room temperature is too Restore room temperature The instrument does to allowed range not start Wrong power supply to Contact service department instrument The instrument do not reach Wrong power supply to Check power supply the desired temperature instrument... -
Page 8: Electrical Drawing
ELECTRICAL DRAWING...
