- Page 1 Users MACHINE MANUFACTURERS DRAUGHTSMEN OPERATORS MAINTENANCE WORKERS ANY OTHERS REV. DESCRIPTION MANAGED APPROVED PRODUCT CODE PAGES ISSUE DATE Instruction E142.M01.EN.03 UTEC 11/2022 Manual Matest S.p.a. Via delle Industrie 25, 24048 Treviolo (BG) Italy +39 035 2055011 TEL. info@matest.com | www.matest.com...
-
Page 2: Table Of Contents
MANAGED APPROVED PRODUCT CODE PAGES ISSUE DATE Instruction Manual UTEC E142.M01.EN 11/2022 Contents 1. GENERAL INFORMATION ..................... 3 WARNINGS ......................... 3 WARNING AND DANGER INDICATIONS - SIGNS ............ 3 AIM OF THE INSTRUCTIONS MANUAL ..............3 STRUCTURE OF THE INSTRUCTIONS MANUAL ............. 4 COMPOSITION OF THE INSTRUCTIONS MANUAL .......... -
Page 3: General Information
PRODUCT CODE PAGES ISSUE DATE Instruction Manual UTEC E142.M01.EN 11/2022 1. GENERAL INFORMATION 1.1 WARNINGS The manufacturer does not accept any responsibility for direct or indirect damage to people, things or animals and use of the appliance in different conditions from those foreseen. -
Page 4: Structure Of The Instructions Manual
PRODUCT CODE PAGES ISSUE DATE Instruction Manual UTEC E142.M01.EN 11/2022 This responsibility is entrusted to the installer and Laboratory or Site Manager where the machine is installed. The Constructor is available to provide further information. 1.4 STRUCTURE OF THE INSTRUCTIONS MANUAL The manual can consist of a number of documents, as shown in the appropriate list. -
Page 5: Storage
ISSUE DATE Instruction Manual UTEC E142.M01.EN 11/2022 - To know the machine functions, its commands, safety and protection devices, possible dangers of use and all the information in this manual in detail. This knowledge can only be gleaned from detailed reading of this manual. -
Page 6: Technical Characteristics
REV. DESCRIPTION MANAGED APPROVED PRODUCT CODE PAGES ISSUE DATE Instruction Manual UTEC E142.M01.EN 11/2022 2. TECHNICAL CHARACTERISTICS 2.1 GENERAL MACHINE DESCRIPTION DIGITAL DISPLAY UPPER HANDWHEEL PISTON PLATE THREE LEGS HYDRAULIC PUMP ROUND COUNTER HAND WHEEL FOR FORCE APPLICATION TENSILE HEAD... -
Page 7: Dimensions And Weight
MANAGED APPROVED PRODUCT CODE PAGES ISSUE DATE Instruction Manual UTEC E142.M01.EN 11/2022 2.2 DIMENSIONS AND WEIGHT Dimensions 410 x 210 x 270 mm Weight 3,5 kg 2.2 POWER SUPPLY Li-Ion 1800mA/h 3.7V Batteries. Rechargeable from USB port (5Vdc) via supplied cable. -
Page 8: Assembling Procedure
PAGES ISSUE DATE Instruction Manual UTEC E142.M01.EN 11/2022 4.2 ASSEMBLING PROCEDURE After removing the packaging, make sure the machine is intact, checking that there are no visibly damaged parts. In case of doubt DO NOT USE THE MACHINE and contact the retailer. -
Page 9: In Function - Use
PRODUCT CODE PAGES ISSUE DATE Instruction Manual UTEC E142.M01.EN 11/2022 IN FUNCTION - USE 6.1 MACHINE CALIBRATION – METERS – INDICATORS The machine is checked in the factory, using sample equipment periodically checked by officially recognised institutes. These checks cannot guarantee that the machine, meters and indicators will provide accurate values and results conforming to the standards in force in the countries the machine has been installed and used in. -
Page 10: Test Start Up
PRODUCT CODE PAGES ISSUE DATE Instruction Manual UTEC E142.M01.EN 11/2022 B – HOW TO PREPARE THE TEST SURFACE AND TO GLUE THE ADHESION DISC It is preferable to perform the following operations before starting the test: Screw the upper hand wheel (2) completely without forcing it and by rotating it clockwise. - Page 11 PAGES ISSUE DATE Instruction Manual UTEC E142.M01.EN 11/2022 Slightly rotate the upper handwheel (2) clockwise until the digital display starts recording a little increase. This procedure is useful to eliminate any clearance between the tie rod and the tensile head.
-
Page 12: Maintenance
For spare parts contact the manufacturer’s Sales Service department. ITEM CODE QUANTITY DESCRIPTION RE142-99 16 KN LOAD CELL WITH CONNECTOR FOR E142 MODEL STVS03651 DIGITAL DISPLAY SPARE HYDRAULIC PUMP RE142-96 Please note the replacement of some parts might imply a necessary WARNING recalibration of the instrument.
