- Page 1 A u t o m o t i v e E n e r g y & P o w e r A n a l y s i s A e r o s p a c e & D e f e n s e T r a n s p o r t a t i o n G e n e r a l T e s t &...
- Page 2 Copyright © DEWETRON elektronische Messgeraete Ges.m.b.H. This document contains information which is protected by copyright. All rights are reserved. Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. All trademarks and registered trademarks are acknowledged to be the property of their owners.
- Page 3 BNC connectors (± 50V max.), D-SUB connectors (± 50V max.), thermocouple connectors (± 50V max.), BINDER connectors (± 50V max.), SMB connetcors (± 50V max.), µdot connectors (± 50V max.), ® LEMO connectors or RJ-45 connectors. ® DE-M070302E • DEWE-5001 • Technical Reference Manual • Printing version 1.0.4 • August 16, 2012...
- Page 4 Preface Notes...
-
Page 5: Table Of Contents
Safety instructions for all DEWETRON systems ……………………………………… 9 Environmental Considerations …………………………………………………………… 10 Main System System specifications ……………………………………………………………………… 11 Connectors ………………………………………………………………………………… 12 Software A/D Conversion Internal Wiring CE-Certificate of conformity DE-M070302E • DEWE-5001 • Technical Reference Manual • Printing version 1.0.4 • August 16, 2012... - Page 6 Table of content...
-
Page 7: General Information, Safety Instructions
Warranty Information A copy of the specific warranty terms applicable to your DEWETRON product and replacement parts can be obtained from your local sales and service office. Support For any support please contact your local distributor first or DEWETRON directly. -
Page 8: Safety Symbols In The Manual
Failure to comply with these precautions or with specific warnings elsewhere in this manual violates safety standards of design, manufacture, and intended use of the product. DEWETRON Elektronische Messgeraete Ges.m.b.H. assumes no liability for the customer’s failure to comply with these requirements. -
Page 9: Safety Instructions For All Dewetron Systems
DO NOT substitute parts or modify equipment: Because of the danger of introducing additional hazards, do not install substitute parts or perform any unauthorized modification to the product. Return the product to a DEWETRON sales and service office for service and repair to ensure that safety features are maintained. -
Page 10: Environmental Considerations
Any change in the file structure as deleting or adding files or directories might cause a system crash. Before installing software updates contact DEWETRON or your local distributor. Use only software packages which are released by DEWETRON. Further informations are also available in the internet (http://www.dewetron.com). -
Page 11: Main System
Dimensions (W x H x D): approx. 453 x 200 x 351 mm (17.8 x 7.9 x 13.8 in.) Weight: typ. 17 kg (37.4 lbs), depending on confi guration DE-M070302E • DEWE-5001 • Technical Reference Manual • Printing version 1.0.4 • August 16, 2012... -
Page 12: Connectors
Main System Connectors Typical DEWE-5001 front view Combustion Analyzer option Connector overview: 1. Power supply connector with general power switch 2. PS/2 keyboard connector 3. PS/2 mouse connector 4. USB interface connectors 5. LPT interface connector 6. 2x RS-232 interface connectors 7. - Page 13 0.16 Hz for structural and modal analysis, human body vibration measurement 3.4 Hz for noise and shock response measurement Option: test signal input for all channels DE-M070302E • DEWE-5001 • Technical Reference Manual • Printing version 1.0.4 • August 16, 2012...
- Page 14 Main System Filter modules for MDAQ Filter Modules for MDAQ Module # CH Filter characteristics Cutt-off frequencies Order MDAQ-AAF4-5-BU Butterworth order 100 Hz, 1, 10, 30, 100 kHz, Bypass Note: not possible in all system confi gurations. Please contact factory for details. MDAQ-FILT-5-BU Butterworth 30, 100, 300 Hz, 1, 10 kHz,...
- Page 15 Range up to 50000 pC, AC coupled with 0.07 Hz, BNC signal connection Max. 100 kHz bandwidth (dependent on the max. bandwidth of the amplifi er) Automatic adapter identifi cation DE-M070302E • DEWE-5001 • Technical Reference Manual • Printing version 1.0.4 • August 16, 2012...
- Page 16 Main System Power supply connectors 400 W AC power supply 400 W AC power supply BEA-640 Input: Input range: 100 to 240 V (active PFC) Input frequency: 47 to 63 Hz Max. input current: 7 A (115 V ), 3.5 A (230 V Output: Output power: 400 W continuous...
- Page 17 The USB interface connectors meets standard USB pin assignment. LPT printer interface connector The printer interface connector (female) is located on the right side of the DEWE-5001. It is configured as standard LPT interface. DE-M070302E • DEWE-5001 • Technical Reference Manual • Printing version 1.0.4 • August 16, 2012...
- Page 18 Schematic RS-232 interface connector (COM1) The RS-232 interface connector (male) is located on the right side of the DEWE-5001. It is configured as standard RS-232 interface COM 1 and can be used for mouse or other peripheral units. 1 2 3 4 5...
- Page 19 The pin assignment is depending on the used A/D board - details are available in appendix B. Ground connectors For some kind of measurements, it’s necessary to give the system an additional ground connection. DE-M070302E • DEWE-5001 • Technical Reference Manual • Printing version 1.0.4 • August 16, 2012...
- Page 20 Main System Combustion Analyzer I/O connectors (DEWE-5000-CA) The Combustion Analyzer requires several special input signals to work. Please refer to appendix B (wirings) for details. Signal output 1 (wiring according to appendix B) Signal output 2 (wiring according to appendix B) Crank Angle Sensor CA Connector ‘Zero position’...
-
Page 21: Software
Another important new feature is the sequencer which provides a way to automate test procedures. DE-M070302E • DEWE-5001 • Technical Reference Manual • Printing version 1.0.4 • August 16, 2012... - Page 22 DEWETRON hardware cards as well as some third-party cards, like Spectrum cards for ™ transient recording. Multiple cards of the same family are supported for high channel counts. There is also a huge range of DEWETRON signal conditioners which are all perfectly implemented into the soft- ware. Besides the analog inputs DEWESoft supports the digital I/Os, counters and CAN interfaces of DEWETRON ™...
- Page 23 This allows you to work with the data as you were at the test bench or on the proving ground. DE-M070302E • DEWE-5001 • Technical Reference Manual • Printing version 1.0.4 • August 16, 2012...
- Page 24 DEWESoft ™ Notes...
-
Page 25: A/D Conversion A1
Please find information about the A/D conversion in the attached DEWE-ORION series manual. The latest version of the manual can be downloaded from: http://download.dewetron.com/dl/components/adboards Informations regarding different manufacturer's see the corresponding D/A card manual. DE-M070302E • DEWE-5001 • Technical Reference Manual • Printing version 1.0.4 • August 16, 2012... - Page 26 A/D & D/A Conversion Notes...
-
Page 27: Internal Wiring B1
Internal Wiring Please find information about the MDAQ amplifiers in the attached DEWE-MDAQ series manual. The latest version of the manual can be downloaded from: http://download.dewetron.com/dl/products/signal/mdaq DE-M070302E • DEWE-5001 • Technical Reference Manual • Printing version 1.0.4 • August 16, 2012... - Page 28 Internal Wiring Notes...
- Page 29 EN 55011 Class B Immunity EN 61000-6-2 Group standard Graz, April 28, 2010 Dipl.-Ing. Roland Jeutter / Managing director Place / Date of the CE-marking DE-M070302E • DEWE-5001 • Technical Reference Manual • Printing version 1.0.4 • August 16, 2012...
- Page 30 Notes...
