- Page 1 DAARC - 120 INVERTER WELDING MACHINE / ЗАВАРЪЧЕН ИНВЕРТОРЕН АПАРАТ ТИП "ПИСТОЛЕТ", 120A, 4.6 KW USER‘S MANUAL Manufactured under license of Daewoo International Corporation, Korea Daewoo International Corporation, Korea...
-
Page 3: Safety Warning
1. SAFETY WARNING Electric shock——May lead to death ！ ！ - Set the earth fitting according to applying standard. - Forbidden to touch the bare electric parts and electrode with uncovered skin, wet gloves or clothes. - Make sure you are insulated from the ground and the workshop. - Make sure you are in safe position. -
Page 4: Machine Description
2. MACHINE DESCRIPTION The welding machine is a rectifier adopting the most advanced inverter technology. The development of inverter gas-shielded welding equipment benefits from the development of the nverter power supply theory and components. Inverter gas-shielded welding power source utilizes high-power component IGBT to transfer 50/60Hz frequency up to 30~50KHz , then reduce the voltage and commutate, and output high-power voltage via PWM technology. - Page 5 ccording to input voltage grade, connect power cable with power supply box of relevant voltage de. Make sure no mistake is made and make sure the voltage difference is among permission ge. After the above job, installation is finished and welding is available. OPERATION INSTRUCTION onnect AC220V power supply.
- Page 6 nel picture above is for reference only. If any difference with the real machine, please follow e real machine. ES OR PREVENTIVE MEASURES onment machine should be operated in dry environments with humidity levels of max 90%. bient temperature should be between -10 to 40 degrees centigrade. id welding in sunshine or drippings.
-
Page 9: Maintenance
of voltage will assure that welding current keeps in allowable range. If power voltage is exceeding allowable range limited, it will damage to components of machine. The operator should understand this situation and take preventive measures. 4) If welding time is exceeded duty cycle limited, welding machine will stop working for protection. Because machine is overheated, temperature control switch is on “ON’’... -
Page 10: Technical Parameters Table
D. Too much spatter when use MMA welding, 1. Maybe current is too big and stick’s diameter is too small. 2. Output terminal polarity connection is wrong, it should apply the opposite polarity at the normal technics, which means that the stick should be connected with the negative polarity of power source, and work piece should be connected with the positive polarity.
