- Page 1 DABX1 SERIES Arc welders USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
- Page 2 INDEX 1. SAFETY ..............................2 2. USE ................................6 3. MAINTENANCE AND REPAIR ......................... 8 4. SPECIFICATION ............................9 5. FIG. OF SHELL ............................10...
- Page 3 1. SAFETY a. For the correct use,please read this manual carefully before you use the product. b. All the notice in this booklet is to make sure the correct use of this machine and to be sure that you are away from any danger and injuries. c.
- Page 4 Please obey the safety items In order to avoid the serious personal injury ,please obey the following items. 1. The design of the welder is fully consider the user' s security. please pay attention to the notice on the manual once operate it,otherwise may cause human' ' ‘ s accidents such as death or badly injury.
- Page 5 Noise can obstruct the sense of hearing. 1. Please use the protection apparatus with enough light-hidden degree. 2. Please put on protection glasses. 3. Please use fur-gloves、 long-sleeves、 overfeet fur apron etc.protection appararus during welding. 4. Arranging protecting shield around operating area can avoid to damage others by arc-light. 5.
- Page 6 1. Please correctly use a gas-bottle according to rules. 2. please use gas regulators which our company suggests and adapt. 3. Please read the manual or a gas regulator before using it and obey the notice items. 4. Please do not place the gas bottle at a high temperature on direct sunshine place. 5.
- Page 7 1. Please separate welding operation、 gringding operation from the welding mains in case for avoiding splashing steel- powder go into the inside of mains. 2. Please maintain repair at fixed time in case for avoiding to cause worse of insulation by powder-dust pliing up.
- Page 8 [Notice items for connection] When connecting cables etc.,please close the mains switch of the power -distribution box. Every cable is connected by copper ends and then insulated with insulating tape.after fixed by a bolt or a nut. Output cable (mm²) Input cable (mm²) Auto Air Switch Type...
- Page 9 using life. (2) Overloading can produce noise and make cuttent-adjust handle difficult to turn ete. 3. The connection between welding ends and cable should be firm,otherwise badly connection will cause some parts heat,make ends and cables burn down. Please notice it carefully. 4.
- Page 10 slideway grease slide part (self lubricating material ) Moving guide screw sliding part of the slideway uses self-lubricating material does not. need anv grease. Greasing will make a bad effect on sliding. Please notice it. 5. Check in bolts and tightening situationsof-screws and if there are any fiexibilty then tighten them completely.
- Page 11 Input Capacity: 41.8 kV A No load voltage: 76 V Output current: 260 A Welding current: 100-500 A Rated duty cycle: 35% Insulation class: F Protection grade: IP21S Applied welding rod: 3.2-4.0 mm N.W. / G.W. : 81/91 kg DABX 1-630 Input Voltage: 220/380 V ±...
- Page 12 Manufactured under license of Daewoo International Corporation, Korea...
