Ava GJD GJD1220 Instruction Manual

LX
I/O Module
GJD1220 LoRa LX I/O Module 868MHz
PACKAGE CONTENTS
• 1 x LoRa I/O Module
• 1 x Installation guide
Transfer The Unique ID Code from the I/O Module to
the Gateway
Set the LoRa® LX Gateway to 'Device Learn' (see LoRa®
LX Gateway manual) then after being powered press and
release the module's 'PAIR' button.
Connections to the I/O Module
The I/O Module can be powered by either 2 x CR123
batteries or a 12 volt supply.
The I/O Module has a N/O negative applied input which is
active when powered by battery or 12 volts.
The input response is configured in the LoRa® LX
Gateway 'EVENTS' page.
The I/O Module has a changeover relay output which is
only active when powered by 12 volts.
The output relay is configured in the LoRa® LX Gateway
'EVENTS' page.
w: www.gjd.co.uk
Unit 2, Birch Business Park, Whittle Lane, Heywood, Greater Manchester, OL10 2SX, UK
Batteries
Only use CR123 3 V Lithium batteries.
Observe correct polarity when fitting.
Battery safety information
• Do not put in a fire
• Do not charge
• Do not heat
• Do not short circuit
• Do not disassemble
• Only fit batteries of the same type and voltage
Specifications
Supply Voltage
Supply Current
Batteries
Output Relay Rating
Operating temperature
Protection
Dimensions
Weight
Housing
Communication
SIMPLIFIED EU DECLARATION OF CONFORMITY
Hereby, GJD Manufacturing Ltd declares that the radio
equipment type GJD1220 LoRa LX I/O Module 868 MHz is
in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available
at gjd.co.uk
This equipment operates on 868 MHz frequency band therefore must
only be used in regions where this is permitted license-free
