Falcon EL-26HM Installation, Operation, And Parts Manual

Mobile lifting table lifting capacity, 2600 lbs.
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model No. Falcon EL-26HM
TRANSLATED VERSION
Mobile Lifting Table
Installation, Operation
Lifting Capacity, 2600 lbs.
and Parts Manual
Distributed by
Please read this entire manual carefully and completely before installation or operation of the lift.
12/04/2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EL-26HM and is the answer not in the manual?

Questions and answers

Related Manuals for Falcon EL-26HM

Summary of Contents for Falcon EL-26HM

  • Page 1 Model No. Falcon EL-26HM TRANSLATED VERSION Mobile Lifting Table Installation, Operation Lifting Capacity, 2600 lbs. and Parts Manual Distributed by Please read this entire manual carefully and completely before installation or operation of the lift. 12/04/2023...

  • Page 2: Important Notes

    Liability The liability of Falcon is limit to the amount that the customer has actually paid for this product. This exclusion of liability does not apply to damages caused through willful misconduct or gross negligence on the part of Falcon.

  • Page 3: Table Of Contents

    Installation, Operation and Parts Manual Falcon-EL-26HM IMPORTANT NOTES .............................. 2 SAFETY NOTES ..............................4 1.1 Operation of the lifting table ............................4 1.2 Checking of the lifting platforms ........................... 4 1.3 Important safety notices ............................... 4 1.4 Noise ..................................... 5 1.5 Warning labels ................................

  • Page 4: Safety Notes

    Installation, Operation and Parts Manual Falcon-EL-26HM SAFETY NOTES 1.1 Operation of the lifting table This mobile lifting table is designed for dismantling and fixing batteries of electric vehicles as well as engine, gearbox, drive axle, fuel tank, suspension, bracket and chassis components of traditional vehicles. Users are not allowed to use it for any other purposes. The applicable national regulations, laws and directives must be observed.

  • Page 5: Noise

    Installation, Operation and Parts Manual Falcon-EL-26HM 1.3.11 If the lift is going to be left unused for a long time, users are required to: a. Disconnect the power; b. Empty the oil tank; c. Lubricate the moving parts with hydraulic oil.

  • Page 6: Packing, Storage And Transportation

    Installation, Operation and Parts Manual Falcon-EL-26HM PACKING, STORAGE AND TRANSPORTATION Packing, lifting, handling, transporting operations must be performed only by experienced personnel with appropriate knowledge of the lift and after reading this manual. 2.1 The lift was packed as whole for transportation...

  • Page 7: Product Descriptions

    8.Side-tilt adjusting device 9.Front-tilt adjusting device 10.Fixed side of suspended platform 11.Extendable side of suspended platform 12. Adapters (Optional) 3.3 Technical data Model Falcon EL-26HM Max. capacity 2600 lbs. Motor 1.5kW Voltage 110V-1Ph-60Hz Full rise time with rated load (normal speed) Approx.45s...

  • Page 8: Dimensions

    Installation, Operation and Parts Manual Falcon-EL-26HM 3.4 Dimensions...

  • Page 9: Installation

    Installation, Operation and Parts Manual Falcon-EL-26HM INSTALLATION ONLY TRAINED AND QUALIFIED INSTALLERS CAN PERFORM LIFT INSTALLATION DUTIES. Step 1: Remove the packing frames and take out accessories placed under the platform. Prepare 2 wooden battens with thickness being more than 100mm and length being more than 700mm. (other dependable devices may also applicable).
  • Page 10 Installation, Operation and Parts Manual Falcon-EL-26HM Step 3: Install the jack. Put the steel ball B into position as indicated in the following FIGURE. Untighten screw A attached with the component 3. Insert ball B into component 3. Connect component 3 and component 2 as indicated.

  • Page 11: Commison

    Installation, Operation and Parts Manual Falcon-EL-26HM COMMISON Only authorized persons are allowed to operate the lifting table. Read and digest the complete operation instructions before operating the lifting table. 4.1 Fill the oil reservoir with hydraulic oil ONLY CLEAN AND FRESH OIL ONLY Lift must be fully lowered before changing or adding hydraulic oil.

  • Page 12: Control Button Descriptions

    Installation, Operation and Parts Manual Falcon-EL-26HM - Use the lifting table after reading the instruction manual carefully and understand the contents of them for safe and proper use. 4.3 Control button descriptions CODE Description Function Main switch Turn on or off the main power supply...
  • Page 13 Installation, Operation and Parts Manual Falcon-EL-26HM POS. Description Functions Hand-held control unit Control raising and lowering movement. The lower platform can be horizontally moved within 40mm by releasing the grips. When there is a slight deviation to align the fixture, release the grip and the lower...

  • Page 14: Trouble Shooting

    Installation, Operation and Parts Manual Falcon-EL-26HM TROUBLE SHOOTING ATTENTION: If the trouble could not be fixed by yourself, please do not hesitate to contact us for help .We will offer our service at the earliest time we can. By the way, your troubles will be judged and solved much faster if you could provide us more details or pictures of the trouble.

  • Page 15: Maintenance

    Installation, Operation and Parts Manual Falcon-EL-26HM MAINTENANCE Easy and low cost routine maintenance can ensure the lift work normally and safely. Following are requirements for routine maintenance. 1. Lubrication before first use Lubricate the moving parts with NO.1 lithium grease. Regularly add grease for every 3 months.

  • Page 16: Annex 1, Electrical Diagrams And Parts List

    Installation, Operation and Parts Manual Falcon-EL-26HM Annex 1, Electrical diagrams and parts list...
  • Page 17 Installation, Operation and Parts Manual Falcon-EL-26HM...
  • Page 18 Installation, Operation and Parts Manual Falcon-EL-26HM...
  • Page 19 Installation, Operation and Parts Manual Falcon-EL-26HM Component Code P-code Descriptions Specification SB1,SB2,SB3,SB4 320307035 Hand-held control COP-4B 321301026 PCB circuit board AC24V/DI-11/DO-9 320901011 AC contactor CJX2-1810/AC24V 320301011 Limit switch TZ8108 320802001 Circuit breaker DZ47-63C32/2P(NXB-63C32/2P) 320307036 Power switch LW26-20GS/04-1 321201001 Indicating lamp...

  • Page 20: Annex 2, Hydraulic Diagrams And Parts List

    Installation, Operation and Parts Manual Falcon-EL-26HM Annex 2, Hydraulic diagrams and parts list Steel reservoir Filter Motor Gear pump Relief valve Non-return valve Spool of the solenoid valve Pressure make-up valve Spool of the solenoid valve Pressure make-up valve Cylinder connector...
  • Page 21 Installation, Operation and Parts Manual Falcon-EL-26HM Pos. P-code Descriptions Specification 320204239 Motor 110V-1.5KW-1PH-60HZ 330404006 Coupling 48mm（YBZ-F2.1D4H1/1-03） 207101100 O-seal ring EKM,6.5*1.5 210101015 Fitting YBZ1-PG02A 330308033 Pressure compensating valve BL-I0.8 330308035 Valve spool of the solenoid valve DHF08-220 203204102 Locking nut FHLM-1/2-20UNF...
  • Page 22 Installation, Operation and Parts Manual Falcon-EL-26HM Pos. P-code Descriptions Specification 690305227 Split washer 30502004 207101098 O-seal ring 109*5.3 330201005 Gear pump CBK-F220/CBK-2.1F 330402014 Oil-back pipe YBZ-D5B4H2/1-02 204101005 Flat washer D8-GB95 204201013 Split washer 202109071 Hex socket cylinder head screw M8x80-GB70_1...

  • Page 23: Annex 3, Exploded Mechanical Drawings And Parts List

    Installation, Operation and Parts Manual Falcon-EL-26HM Annex 3, Exploded mechanical drawings and parts list POS. Code Descriptions Specification 202208008 Hex socket cylinder head screw (with shaft shoulder) 20-M16X35-GB5281 202208009 Hex socket cylinder head screw (with shaft shoulder) 20-M16X40-GB5281 420270280 Rolling ball...
  • Page 24 Installation, Operation and Parts Manual Falcon-EL-26HM POS. Code Descriptions Specification 202109044 Hex socket cylinder head screw M10X35-GB70_1 202109142 Hex socket cylinder head screw M10X90-GB70_1 203103019 Hex locking screw M16-GB889 202109008 Hex socket cylinder head screw M5X12-GB70_1 202109020 Hex socket cylinder head screw...
  • Page 25 Installation, Operation and Parts Manual Falcon-EL-26HM POS. Code Descriptions Specification 205103004 Flange bearing 3026-SF-1F 205101054 Bearing 3030-SF-2X 204101012 Flat washer D24-GB95 204301009 Circlip D25-GB894_2 204301010 Circlip D28-GB894_2 204201003 Spring washer D6-GB93 204101004 Flat washer D6-GB95 330310018 Electromagnet DCT45X20 203103007 Hex locking nut...
  • Page 26 Installation, Operation and Parts Manual Falcon-EL-26HM POS. Code Descriptions Specification 614059203 Outside support arm MS12AC-A2-B2 614059204 Inside support arm MS12AC-A2-B3 420560050 Sliding block MS12AC-A2-B4 410562291 Middle shaft of the support bracket MS12AC-A2-B5 410562301 Downside shaft of the cylinder MS12AC-A2-B7 410562311...
  • Page 27 Installation, Operation and Parts Manual Falcon-EL-26HM POS. Code Descriptions Specification 204101004 Flat washer D6-GB95 204201004 Spring washer D8-GB93 204101005 Flat washer D8-GB95 203103007 Hex locking nut M10-GB889_1 202109042 Hex socket cylinder head screw M10X25-GB70_1 202109080 Hex socket cylinder head screw...
  • Page 28 Installation, Operation and Parts Manual Falcon-EL-26HM Optional Adapter 1 POS. Code Descriptions Specification 208109024 Adjustable foot D80-M20x100 202205013 Hex socket tight screw M12x30 410562011 Pad plate MS10-A08-B01 410563381 Support rod MS10-A08-B02 Optional Adapter 2 POS. Code Descriptions Specification 202205013 Hex socket tight screw...
