Specification
LVDN25HM
Model
1/3"CMOS
Pick up Element
700TV Line
Horizontal Resolution
Minimum Illumination
0.001 Lux/F1.2
More than 46dB
S/N Ratio
2:1 interface
Scanning System
Internal, Negative sync.
Synchronous System
NTSC: 1/60s~1/100, 000s, PAL: 1/50s~1/100,000s
Auto Electronic Shutter
0.45
Gama Characteristic
Under 10Lux by CDS
IR Status
CDS AUTO Control
IR Power On
1Vpp, 75Ω
Video Output
Auto
Auto Gain Control
DC12V (+/-10%)/150mA
Power/Current
Board Lens 3.6mm/F2.0
Lens
￠94x 85(H)
Dimension (mm)
Weight (g)
Storage Temperature
-30~+60℃ RH95% MAX
-10~+50℃ RH95% MAX
Operating Temperature
Packing List
No
Name
1.
Vandalproof Dome Color Camera
LVDN25HM
2.
User Guide
LVDN25HM
650
Franchiser：
Model
Number
1
1
LVDN25HM Color Camera
Vandalproof Dome Color Camera
Notes:
Before providing power for the
camera, please read this User Guide in
detail!
Do not attempt to disassemble the camera.
If the camera can not work, please contact
local franchiser or our company.
Advertisement
Related Manuals for MAK LVDN25HM
Summary of Contents for MAK LVDN25HM
- Page 1 Specification LVDN25HM Color Camera LVDN25HM Model 1/3"CMOS Pick up Element 700TV Line Horizontal Resolution Minimum Illumination 0.001 Lux/F1.2 More than 46dB S/N Ratio 2:1 interface Scanning System Vandalproof Dome Color Camera Internal, Negative sync. Synchronous System NTSC: 1/60s~1/100, 000s, PAL: 1/50s~1/100,000s Auto Electronic Shutter 0.45...
- Page 2 BRIEF OF PRODUCT INTRODUCTION CONNECTING Congratulations on your purchase of this product. * Sensor This User Guide suits LVDN25HM product. We adopt the latest CMOS technical of sensor and driver. The most at- Adopt CMOS 1/3" Sensor. Monitor Video tractive characteristics are small and easy hidden, suits the elevator and corridor.
