- Page 1 COMMISSIONING, OPERATING AND MAINTENANCE MANUAL MODEL: MAXLOGIC SERIES ML-1170 SUB MODEL: INTELLIGENT ADDRESSABLE BEAM TYPE SMOKE DETECTOR...
-
Page 2: Table Of Contents
6.2.4 “E4” Installation Fault..........................13 7 - DISPLAYS...............................13 8 - BOX CONTENTS..............................13 9 - TECHNICAL SPECIFICATIONS........................14 10 - DEVICE COMPATIBILITY LIST........................14 11 - EXPLANATION OF TERMS..........................14 12 - ABBREVIATIONS............................14 KK-611.089 Rev.No:0 27.02.18 ML-1170 Beam Type Smoke Detector User Manual Page 2/14... -
Page 3: General Description
Authorized Service: TEKSIS TEKNIK ELEKTRONIK SIS. TIC. VE SAN. A.S. Address: SERIFALI MAHALLESI, KUTUP SOKAK NO: 27/3 UMRANIYE / ISTANBUL / TURKEY TEL: +90 216 313 60 60 FAX: +90 216 313 47 49 E-mail: destek@mavili.com.tr KK-611.089 Rev.No:0 27.02.18 ML-1170 Beam Type Smoke Detector User Manual Page 3/14... -
Page 4: Warnings
• Must be posted at least 3 meters high if there are people divisions. • Detectors should not be mounted close to the walls and partitions less than 0.5 m. KK-611.089 Rev.No:0 27.02.18 ML-1170 Beam Type Smoke Detector User Manual Page 4/14... -
Page 5: Placement
0,5m ≤ H 2 ≤ 7,5m 5m ≤ L 1 ≤ 100m 0,5m ≤ L 2 ≤ 7,5m 1m ≤ L 3 ≤ 15m L 4 ≤ 1m KK-611.089 Rev.No:0 27.02.18 ML-1170 Beam Type Smoke Detector User Manual Page 5/14... -
Page 6: Pitched Roof
The screw is removed which is at the top of Beam Detector. While holding the latch on the top cover of the detector, the force applied to the cover the detector with 45° an angle and provides opening cover. Press and hold the latch Unscrewing Valve opening direction KK-611.089 Rev.No:0 27.02.18 ML-1170 Beam Type Smoke Detector User Manual Page 6/14... -
Page 7: Physically Installation And Cable Input Points
NOTE 1 : Transmitter can be damaged if more than one “ON” is selected from the switches. Should be selected only one point. NOTE 2 : Yellow fault LED lights if the cover of transmitter is open. KK-611.089 Rev.No:0 27.02.18 ML-1170 Beam Type Smoke Detector User Manual Page 7/14... -
Page 8: Receiver Connection Settings
Loop in Loop out Loop in Loop out Intelligent Analogue Addressable Fire Alarm Control Panel 24V DC 24V DC 24V DC 24V DC 24V DC 24V DC Power Supply KK-611.089 Rev.No:0 27.02.18 ML-1170 Beam Type Smoke Detector User Manual Page 8/14... -
Page 9: Alignment Adjustment
Latch Screw Points Cable Input Points Mirror Point of view Looking point Lens Alignment Alignment Button Button (Red) (Blue) Plane Mirror “Point of View” “Looking Point” A Detail KK-611.089 Rev.No:0 27.02.18 ML-1170 Beam Type Smoke Detector User Manual Page 9/14... -
Page 10: Coarse Adjustment
: To the next settings and to increase the value. Down : To the previous settings and to decrease the value. : To enter into value section, to save value and to exit features section. KK-611.089 Rev.No:0 27.02.18 ML-1170 Beam Type Smoke Detector User Manual Page 10/14... -
Page 11: Receiver Circuit
In the following table, steps which are activated in the receiver menus, and step options values, were specified. The black filler cells are default values. Menu Values Menu Code %90 Blocking, Fire Event Fault Latch UnLatch Time-Out Alarm Level Return Factory Settings Signal Reading Menu KK-611.089 Rev.No:0 27.02.18 ML-1170 Beam Type Smoke Detector User Manual Page 11/14... -
Page 12: Commissioning
• The distance between transmitter and receiver may be farther than possible distance. • Can be a barrier between the transmitter and receiver optical axis. • Receiver or transmitter optics may be contaminated. KK-611.089 Rev.No:0 27.02.18 ML-1170 Beam Type Smoke Detector User Manual Page 12/14... -
Page 13: E2" High Signal Fault
: Shows the fire status, flashes continuously. Yellow LED : Shows the fault status, flashes continuously. 8 - BOX CONTENTS 1 pcs Transmitter 1 pcs Receiver 3 pcs Test Filter KK-611.089 Rev.No:0 27.02.18 ML-1170 Beam Type Smoke Detector User Manual Page 13/14... -
Page 14: Technical Specifications
Şerifali Mahallesi Kutup Sokak No:27/1-2-4 Ümraniye TR-34775 İSTANBUL Meter Gram 1922-CPR-0779 EN 54-12 Decibel ML-1170 °C Celsius Technical specifications: Light Emitting Diode Please check KK-611.089 that is held by manufacturer. KK-611.089 Rev.No:0 27.02.18 ML-1170 Beam Type Smoke Detector User Manual Page 14/14... - Page 15 COMMISSIONING, OPERATING AND MAINTENANCE MANUAL MODEL: MAXLOGIC SERIES ML-1170.SCI SUB MODEL: INTELLIGENT ADDRESSABLE BEAM TYPE SMOKE DETECTOR, SHORT CIRCUIT ISOLATOR...
- Page 16 6.2.4 “E4” Installation Fault..........................13 7 - DISPLAYS...............................13 8 - BOX CONTENTS..............................13 9 - TECHNICAL SPECIFICATIONS........................14 10 - DEVICE COMPATIBILITY LIST........................15 11 - EXPLANATION OF TERMS..........................15 12 - ABBREVIATIONS............................15 KK-611.034 Rev.No:11 11.11.19 ML-1170.SCI Beam Type Smoke Detector User Manual Page 2/15...
-
Page 17: General Description
Certification Authority Title, Address and Phone Information LPCB is part of BRE Certification Ltd., Garston, Watford WD25 9XX. Tel: +44 (0) 1923 664100 Fax: +44 (0) 1923 664603 www.RedBookLive.com KK-611.034 Rev.No:11 11.11.19 ML-1170.SCI Beam Type Smoke Detector User Manual Page 3/15... -
Page 18: Warnings
• Must be posted at least 3 meters high if there are people divisions. • Detectors should not be mounted close to the walls and partitions less than 0.5 m. KK-611.034 Rev.No:11 11.11.19 ML-1170.SCI Beam Type Smoke Detector User Manual Page 4/15... -
Page 19: Placement
0,5m ≤ H 2 ≤ 7,5m 5m ≤ L 1 ≤ 100m 0,5m ≤ L 2 ≤ 7,5m 1m ≤ L 3 ≤ 15m L 4 ≤ 1m KK-611.034 Rev.No:11 11.11.19 ML-1170.SCI Beam Type Smoke Detector User Manual Page 5/15... -
Page 20: Pitched Roof
The screw is removed which is at the top of Beam Detector. While holding the latch on the top cover of the detector, the force applied to the cover the detector with 45° an angle and provides opening cover. Press and hold the latch Unscrewing Valve opening direction KK-611.034 Rev.No:11 11.11.19 ML-1170.SCI Beam Type Smoke Detector User Manual Page 6/15... -
Page 21: Physically Installation And Cable Input Points
NOTE 1 : Transmitter can be damaged if more than one “ON” is selected from the switches. Should be selected only one point. NOTE 2 : Yellow fault LED lights if the cover of transmitter is open. KK-611.034 Rev.No:11 11.11.19 ML-1170.SCI Beam Type Smoke Detector User Manual Page 7/15... -
Page 22: Receiver Connection Settings
Loop in Loop out Loop in Loop out Intelligent Analogue Addressable Fire Alarm Control Panel 24V DC 24V DC 24V DC 24V DC 24V DC 24V DC Power Supply KK-611.034 Rev.No:11 11.11.19 ML-1170.SCI Beam Type Smoke Detector User Manual Page 8/15... -
Page 23: Alignment Adjustment
Latch Screw Points Cable Input Points Mirror Point of view Looking point Lens Alignment Alignment Button Button (Red) (Blue) Plane Mirror “Point of View” “Looking Point” A Detail KK-611.034 Rev.No:11 11.11.19 ML-1170.SCI Beam Type Smoke Detector User Manual Page 9/15... -
Page 24: Coarse Adjustment
: To the next settings and to increase the value. Down : To the previous settings and to decrease the value. : To enter into value section, to save value and to exit features section. KK-611.034 Rev.No:11 11.11.19 ML-1170.SCI Beam Type Smoke Detector User Manual Page 10/15... -
Page 25: Receiver Circuit
In the following table, steps which are activated in the receiver menus, and step options values, were specified. The black filler cells are default values. Menu Values Menu Code %90 Blocking, Fire Event Fault Latch UnLatch Time-Out Alarm Level Return Factory Settings Signal Reading Menu KK-611.034 Rev.No:11 11.11.19 ML-1170.SCI Beam Type Smoke Detector User Manual Page 11/15... -
Page 26: Commissioning
• The distance between transmitter and receiver may be farther than possible distance. • Can be a barrier between the transmitter and receiver optical axis. • Receiver or transmitter optics may be contaminated. KK-611.034 Rev.No:11 11.11.19 ML-1170.SCI Beam Type Smoke Detector User Manual Page 12/15... -
Page 27: E2" High Signal Fault
: Shows the fire status, flashes continuously. Yellow LED : Shows the fault status, flashes continuously. 8 - BOX CONTENTS 1 pcs Transmitter 1 pcs Receiver 3 pcs Test Filter KK-611.034 Rev.No:11 11.11.19 ML-1170.SCI Beam Type Smoke Detector User Manual Page 13/15... -
Page 28: Technical Specifications
Maximum current in the event of short circuit (ILmax) 45mA Maximum contact resistance (ZCmax) 0.5Ω Entering isolation voltage range (VSOmax) - (VSOmin) 8V - 13V Exiting isolation voltage range (VSCmax) - (VSCmin) 8V - 13V KK-611.034 Rev.No:11 11.11.19 ML-1170.SCI Beam Type Smoke Detector User Manual Page 14/15... -
Page 29: Explanation Of Terms
Mavili Elektronik Ticaret ve Sanayi A.Ş. Şerifali Mahallesi Kutup Sokak No:27/1-2-4 Ümraniye TR-34775 İSTANBUL 2831-CPR-F1180 EN 54-12, EN 54-17 ML-1170.SCI Technical specifications: Please check KK-611.034 that is held by manufacturer. KK-611.034 Rev.No:11 11.11.19 ML-1170.SCI Beam Type Smoke Detector User Manual Page 15/15... - Page 45 COMMISSIONING, OPERATING AND MAINTENANCE MANUAL MODEL: MAXLOGIC SERIES ML-1173.SCI SUB MODEL: INTELLIGENT ANALOGUE ADDRESSABLE REFLECTOR BEAM TYPE SMOKE DETECTOR, SHORT CIRCUIT ISOLATOR...
- Page 46 INTRODUCTIONS 1 - GENERAL DESCRIPTION............................3 1.1 Detection Principles............................3 1.2 Utilization Fields..............................3 1.3 Manufacturer Info..............................3 1.4 Warnings................................4 2 - INSTALLATION...............................4 2.1 General Placement Rules.............................4 2.2 Placement.................................5 2.3 Pitched Roof...............................6 2.4 Ventilated Area..............................6 3 - INSTALLATION STEPS.............................7 3.1 Opening the Detectors Cover..........................7 3.2 Physically Installation and Cable Input Points......................7 3.3 Detector Connections and Settings........................8 3.3.1 Connections to the Addressable Panel........................8...
-
Page 47: General Description
1 - GENERAL DESCRIPTION Beam type smoke detector is included with transmitter receiver module and reflector. Maximum and minimum distance should be 5-35m between transmitter receiver module and reflector. Can be expanded to 50m with 4pcs reflector. The infrared beam normally goes to reflector from the transmitter and then from the reflector goes to receiver. -
Page 48: Warnings
1.4. Warnings The control unit contains static-sensitive high quality electronic control equipment. Do not use the panel before reading this manual. • This product should be stored as packed on indoor areas. • Storing ambient temperature should be (-30°C) to (+60°C) and relative humidity should not be exceed %95 as uncondensed. •... -
Page 49: Placement
2.2 Placement 3m ≤ H 1 ≤ 11m 0,5m ≤ H 2 ≤ 7,5m 5m ≤ L 1 ≤ 35m 0,5m ≤ L 2 ≤ 7,5m 1m ≤ L 3 ≤ 15m L 4 ≤ 1m 5-35 m 35-50 m KK-611.047 Rev.No:10 13.11.19 ML-1173.SCI User Manual 5/15... -
Page 50: Pitched Roof
2.3 Pitched Roof For detectors which are mounted on peak of the pitched ceilings. 7,5m given distance can be increased %1 for each 1° roof slope. It can be maximum %25 increase. In case of a curved roof, average slope should be used for an extended distance. Roof Angle 10°... -
Page 51: Installation Steps
3 - INSTALLATION STEPS Installation of the product should be made according to the “Installation Steps”. 3.1 Opening the Detectors Cover The screw is removed which is at the top of Beam Detector. While holding the latch on the top cover of the detector, the force applied to the cover the detector with 45°... -
Page 52: Detector Connections And Settings
Detector Connections and Settings 3.3.1 Connection to the addressable panel POWER FIRE FAULT Loop in Loop out 24V DC 24V DC Intelligent Next Next Analogue Power Transmitter Transmitter Addressable Supply Panel 3.3.2 Detector Connections - Connection Diagram Loop in Loop out Loop in Loop out Loop in Loop out Intelligent... -
Page 53: Alignment Adjustment
3.4 Alignment Adjustment Alignment is a setting for seeing between transmitter, receiver module and reflector each other. Red and Blue alignment buttons are used for alignment. Red button is left and right, blue one moves towards up and down side Alignment status is controlled from “Looking point” and “Point of view”. -
Page 54: Coarse Adjustment
3.4.1. Coarse Adjustment Looking at 10-15 cm away from the point of view of the device to the eye level in paralel, alignment is performed with alignment buttons until other device appears on the mirror. 10-15 cm 3.4.2. Precise Adjustment Signal value is checked in detector Menu (Section 4.2 Detector Menus) while precise adjustment. -
Page 55: Detector Menus
4.2 Detector Menus “Up” and “Down” buttons should be pressed for 2 sec after energizing the detector. Menu section is opened. Up and down buttons are pressed to scroll through the menu steps. “OK” button should be pressed in order to enter into Menu steps. Navigation through menus should be made with “Up”... -
Page 56: Commissioning
5 - COMMISSIONING 5.1. Operation of Detector After the sets have done, covers are closed. Then in several seconds , installation begins. Yellow LED flashing is sign that the installation is done. Installation process can take several minutes. If installation has done correctly, after these several minutes yellow LED turns off. Only the green LED blinks is sign that transition to state of quiescence. -
Page 57: Fault Status
6 - FAULT STATUS Yellow LED shows the fault. In this case, the transmitter receiver modules’ cover is opened, the relevant operations should be carried out according to the error code on the display. Error codes and things to do are as follows: 6.1 “E1”... -
Page 58: Displays
7 - DISPLAYS Receiver-Transmitter module 3 LED lights (Power, Alarm, Fault) POWER ALARM FAULT LED Position Status Green LED : Shows power, flashes in 0,5 s. Red LED : Shows the fire status, flashes continuously. Yellow LED : Shows the fault status, flashes continuously. 8 - BOX CONTENTS 1 pcs Receiver-Transmitter Module 1 pcs Reflector... -
Page 59: Device Compatibility List
ML-05110 MaxLogic SMPS Power Supply, 10A ML-123X / ML-124X.P / ML-125XX MaxLogic Inteligent Addressable Fire Alarm Panel 11 - EXPLANATION OF TERMS. Optical path length: The total distance of the beam between transmitter receiver module and reflector. Fire Sensitivity Settings: Any settings after or during of the changing in responding to fire.
