Page 1 Instruction Manual...
Page 2 NOTICE All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC. For up-to-date product literature, visit www. horizonhobby.com or www.towerhobbies. com and click on the support or resources tab for this product.
Page 3 Do not attempt disassembly, use with incompatible components or augment product in any way without the approval of Horizon Hobby, LLC. This manual contains instructions for safety, operation and maintenance. It is essential to read and follow all the instructions and...
Page 4: Safety Precautions
Age Recommendation: Not for children under 14. This is not a toy. SAFETY PRECAUTIONS • Always ensure all batteries have been properly charged prior to using the model. • Always check all servos and their connections prior to each run. •...
Page 5: Charging Warnings
CHARGING WARNINGS CAUTION: All instructions and warnings must be followed exactly. Mishandling of Li-Po batteries can result in a fire, personal injury and/or property damage. • NEVER LEAVE CHARGING BATTERIES UNATTENDED. • NEVER CHARGE BATTERIES OVERNIGHT. • By handling, charging or using the included Li-Po battery, you assume all risks associated with lithium batteries.
Page 6 • Always charge batteries away from flammable materials. • Always inspect the battery before charging. • Always disconnect the battery after charging and let the charger cool between charges. • Always constantly monitor the temperature of the battery pack while charging. •...
Page 7 PRODUCTS: If you ever need to replace your Spektrum receiver found in a Horizon Hobby product, always purchase from Horizon Hobby, LLC or a Horizon Hobby authorized dealer to ensure authentic high- quality Spektrum product. Horizon Hobby, LLC disclaims all support and warranty with...
Page 8 TABLE OF CONTENTS Box Contents How To Use the Manual Navigating the Pages Return To Spektrum RaceWare App Using the Table of Contents CHARGING Transmitter Layout Android Operating System Android Navigation Icons Android Home Screen Elements Notification Screen iXSR Main Screens Basic Operation MODELS MENU Create New Model...
Page 9 Steering Rate Steering Override AWS Mode Steering Trim Throttle and Brake/Reverse Throttle Channel Properties Throttle Curve Throttle Brake/Reverse Rates Traction Control ABS (Automatic Braking System) Servo Speed AWD Mode- (MOA) Throttle Trim Idle Up Auxiliary (AUX) Channel Setup Channel Properties Input Control Servo Speed SETUP SETTINGS...
Page 10 (Active Vehicle Control) ® Steering Gain Throttle Gain Priority Binding Drive Modes Launch Control Launch Control Launch Curve Launch Control Tips Light/LED Flashlight Light Bars Mappings Mixes Sleep Mode Quick Sleep Telemetry Telemetry Gauges Timers PHYSICAL ADJUSTMENTS Throttle Tension Throttle Distance Steering Tension Steering Wheel Options...
Page 11 Dropdown Rotation Change Right- to Left-handed 1-Year Limited Warranty Warranty and Service Contact Information FCC Information IC Information Compliance Information for the European Union...
Page 12: Box Contents
BOX CONTENTS The iXSR radio system is supplied with the following: • Spektrum iXSR Transmitter • Foam Carry case • USB-C charge/data cable • 5° steering angle adapter • Smaller steering wheel • 32° steering limiter • Stiffer steering spring •...
Page 13: How To Use The Manual
HOW TO USE THE MANUAL The manual for the iXSR is an interactive .pdf document, optimally viewed in the .pdf viewer app on the Android. To access the manual from the Spektrum RaceWare app: 1. From the Setup screen, scroll to the bottom of the page and touch the App Settings icon.
Page 14 NAVIGATING THE PAGES 1. Touch the middle of the screen once to access the reader app toolbars. 2. Touch the page icon ( ) to set the viewing mode.
Page 15 Page-by-Page 3. Select for best viewing results. 4. After the viewing mode is set, touch in the center of the screen to enter full-screen mode. 5. Touch toward the far right side of the screen or swipe left to go the next page. Touch toward the far left side of the screen or swipe right to go to the previous page.
Page 16 RETURN TO SPEKTRUM RACEWARE APP To return to the Spektrum RaceWare app: 1. Swipe from the bottom of the screen to access the Android navigation tools. Overview 2. Touch the icon. 3. Touch the Spektrum RaceWare app in the list of running apps.
Page 17: Using The Table Of Contents
USING THE TABLE OF CONTENTS TABLE OF CONTENTS Box Contents How To Use the Manual Navigating the Pages Return To Spektrum RaceWare App Using the Table of Contents Charging Transmitter Layout Android Operating System Android Navigation Icons Android Home Screen Elements Notiﬁcation Screen iXSR Main Screens Basic Operation...
Page 18 1. Connect a 2-3A USB power supply (not included) to an AC outlet. 2. Connect the included USB-C adapter to the USB port on the back of the transmitter. 3. The LED will glow solid blue while charging and stays on while connected to power. A fast press of the power switch will bring the Charge Battery icon to the touch screen display.
Page 19 CHARGING For optimum charging results, the built-in charger requires a USB power supply capable of at least 2-3A output. Using a power supply with a lower output will result in very long charge times or the transmitter not charging if it is powered on while attempting to charge.
Page 20 1. Connect a 2-3A USB power supply (not included) to an AC outlet. 2. Connect the included USB-C adapter to the USB port on the back of the transmitter. 3. The LED will glow solid blue while charging and stays on while connected to power. A fast press of the power switch will bring the Charge Battery icon to the touch screen display.
Page 21: Transmitter Layout
TRANSMITTER LAYOUT...
Page 22 Function 1 Touch Screen 2 Button L 3 Button R 4 Power Button 5 Charge Port 6 Steering Wheel 7 Rotary Knob 8 Switch I 9 Trim Button A 10 Trim Button B 11 Trim Button C 12 Trim Button D 13 Button E 14 Trim Button F 15 Trim Button G...
Page 23: Android Operating System
ANDROID OPERATING SYSTEM The iXSR transmitter is built on the Android operating system and features a large color touch screen display. Navigate the iXSR using the same actions and gestures as those used to operate any other Android device. To navigate, use your finger to tap, swipe and drag icons and menus found on the display.
Page 24 ANDROID NAVIGATION ICONS The Spektrum Raceware application hides the Android home screen navigation icons. To access the navigation icons, swipe up from the bottom or down from the top edge of the screen as shown.
Page 25 Press the circle icon to go to the Android home screen. Circle icon...
Page 26 ANDROID HOME SCREEN ELEMENTS • Search All Apps: Enter a search term to find a desired application on the system. • Back: Return to previous screen. • Home: Return to the home screen. • Overview: Allows switching between any currently running applications by scrolling left or right through the apps.
Page 27: Notification Screen
NOTIFICATION SCREEN 1. Swipe down from the top of the screen once to exit full screen mode and bring the home screen navigation icons to the front. 2. Swipe down a second time to open the Notification Screen for quick access to: •...
Page 28 IXSR MAIN SCREENS The RaceWare application features 3–4 main menu screens, depending on the receiver selected during model setup. Touch on the navigation tabs located along the top of the screen, or swipe left or right to change screens. Navigation Tabs TIP: Some screens display more information than can fit in the window.
Page 29 Dashboard The Dashboard is the home screen for the iXSR. Information shown on the dashboard includes: • Timers, Start and Reset • Trim positions • Steering rates • Braking rates...
Page 30 Setup Setup is the second navigation tab. The majority of model setup takes place within the setup screen. The setup screen also contains short cuts for Model Setup and App Settings.
Page 31 Monitor Monitor is the third navigation tab. This screen displays the position of the steering wheel, throttle/brake, trims and the position of any AUX channels.
Page 32 Telemetry When using the iXSR with a telemetry capable receiver, the telemetry tab will appear in the fourth tab position. Telemetry displays all available information including signal strength, temperature, rpm and receiver voltage. IMPORTANT: TELEMETRY is only available if you are using a telemetry capable receiver.
Page 33: Basic Operation
BASIC OPERATION The iXSR transmitter is based on an Android operating system. All RC related functions are handled by the Spektrum RaceWare application. ™ • Power On: Press and hold the power button for several seconds to power on the iXSR transmitter. The transmitter is designed to prevent inadvertently powering on from a touch to the power button.
Page 34 • WiFi Connection: Swipe down twice from the top of the screen and click on the WiFi icon to connect to an available WiFi network. Spektrum RaceWare app updates and firmware updates for the radio hardware are available through the Google Play Store.
Page 35 MODELS MENU The Models menu is accessed by touching the current model image in the top right corner of the touch screen. From the Models menu: • Create a new model • Import a model from a memory card • Select a different model •...
Page 36: Create New Model
CREATE NEW MODEL Some options in the model creation process will vary, depending on the equipment used and setup options chosen. To create a new model, from the Models menu: 1. Touch the Create New Model button. 2. Follow the on-screen prompts to complete the model setup.
Page 37 Setup options include: User Name Tap in the name field to access the keypad. Enter a user name using up to 20 characters. After initial setup, the name can be changed in the App Settings screen. Model Name Tap in the name field to access the keypad. Enter a model name using up to 20 characters.
Page 38 TECHNOLOGY ® Activates or deactivates AVC technology in this model. This menu is only available if an AVC receiver was selected in RECEIVER TYPE. Power System Select either electric or gas/nitro engines. Remote Onboard Starting System (ROSS) Select either active or not used if an onboard starting system is available.
Page 39 Steering Select either a single servo or dual steering setup. Depending on options selected, front and rear steering will be available. The next menu asks to select a receiver channel for the rear steering. Auxiliary Features If there are additional receiver channels available in which to add additional functions, select the desired AUX channel and select Next.
Page 40 IMPORT MODEL FROM A MEMORY CARD 3. Insert a micro memory card (not included) into the memory card port located under the removable cover on the front of the transmitter, as shown. 4. Raceware will prompt you to select the memory card and select a folder.
Page 41 SELECT A DIFFERENT MODEL To select a different model from the models list, touch Activate next to the desired model image. The model is equipped and the screen changes to the Dashboard for the selected model.
Page 42 EDIT MODEL PROPERTIES To edit the properties of any model, from the models list, touch the Edit tab on the desired model image.
Page 43 Within the Model Properties menu you can: • Change the model name. • Change the model theme, including changing the photo to one of the stock images or an image from a memory card and changing the model theme color. •...
Page 44: Setup Menu
SETUP MENU The Setup menu allows for editing of all model settings. The screen is divided into three sections: • Channels • Settings • Links and Information...
Page 45 CHANNELS The Channels section includes links to the specific channels, based on the options chosen during model setup, including Steering, Throttle/Brake/Reverse, and any Aux channels currently being used.
Page 46 STEERING The steering screen allows for programming of all steering functions of each steering channel, including: • Travel • Steering Rate • Subtrim • Steering Override • Reverse • AWS Mode • Steering Curve • Trim • Steering Speed If dual steering was selected during the model setup process, choose which steering channel you wish to program by selecting under Channel Properties on the Steering screen.
Page 47 STEERING CHANNEL PROPERTIES Steering Travel Allows independent adjustments of the right and left steering end points. Adjustment range is from 0 to 150%. Make large adjustments by dragging the slider left or right and fine tune by touching the + or – buttons at the ends of the scale. Steering Subtrim Use subtrim to correct minor inaccuracies in servo arms and linkages.
Page 48 Steering Reverse Use reverse to reverse the servo output direction. Select either Normal or Reverse.
Page 49: Steering Curve
STEERING CURVE Steering response is adjustable using an EXPO or Custom steering curve. Standard (default) The standard curve option provides linear steering output throughout the travel range.
Page 50 Custom The custom curve option allows for up to 7 points to be added to the steering curve, which can be adjusted to custom tailor steering response throughout the travel range. • Tap on the line to add points. • Adjust the point position by tapping on a point and using the sliders below.
Page 51 Exponential The right and left steering exponential values can be adjusted independently. Adjust the values large amounts by touching and dragging the slider right or left. Fine tune the value by touching the + or – buttons on the ends of the scale. •...
Page 52: Steering Speed
STEERING SPEED Steering Speed allows adjustment of the servo transit time to prevent overly sensitive steering response. Adjust by dragging the slider in this menu or assign an on-the-fly button to allow easy adjustment while driving. The default value is 100%.
Page 53: Steering Rate
STEERING RATE Steering rate allows for on-the-fly adjustments of steering travel. Steering rate is assigned to Switch F but can be changed to any available trimmer/switch. The default value is 100%.
Page 54 STEERING OVERRIDE Steering override allows you to bypass the steering rate to momentarily give you a higher or lower rate. This feature is useful if you normally run a lower steering rate and need a little “extra” to get out of a situation. Adjust the slider to program the desired override rate, either higher or lower than the programmed steering rate.
Page 55 AWS MODE AWS (All Wheel Steering) Mode supports 4 types of all wheel steering: • AWS (Opposed): The front wheels turn one direction, and the rear wheels turn the other. The rear steering rate is adjustable. • Crab Mode: Both front and rear wheels turn the same direction.
Page 56: Steering Trim
STEERING TRIM Steering trim adjusts the steering neutral position. The number of steps each press of the trim button affects the steering trim, as well as the button assignment, is adjusted in this menu. The default value is +9 and is assigned to Switch B.
Page 57 THROTTLE AND BRAKE/REVERSE The Throttle and Brake/Reverse screen allows for programming of all throttle, brake and reverse functions. • Throttle Curve • Servo Speed • Throttle Trim • Channel Properties • Throttle Rate • Travel • Reverse Rate • Subtrim •...
Page 58 THROTTLE CHANNEL PROPERTIES Throttle/Brake/Reverse Travel Allows independent precise adjustments of the throttle and brake/reverse end points. Throttle/Brake/Reverse Subtrim Use sutrim to correct minor servo arm/linkage inaccuracies. IMPORTANT: Use minimal Subtrim values. Subtrim offsets the entire stroke including the center and endpoint positions.
Page 59 Throttle/Brake/Reverse Reverse Reverses output direction.
Page 60: Throttle Curve
THROTTLE CURVE Throttle and brake/reverse response is adjustable using a standard, custom or exponential curve. Standard (default) The standard curve is a linear throttle brake/ reverse output.
Page 61 Custom The custom curve option allows for separate throttle and brake/reverse curves with up to 7 adjustment points on the curve. These points can be adjusted to custom tailor response throughout the travel range. • Tap on the line to add points. •...
Page 62 Exponential The throttle and brake/reverse exponential values can be adjusted independently. Adjust the values large amounts by touching and dragging the slider right or left. Fine tune the value by touching the + or – buttons on the ends of the scale. •...
Page 63 THROTTLE BRAKE/REVERSE RATES Throttle and brake/reverse rate limits the full travel position values. Adjust the value by dragging the slider or fine tune the value by touching the + or – buttons at the ends of the scale. Throttle and brake/reverse rates may be assigned to any trim switch.
Page 64: Traction Control
TRACTION CONTROL Traction Control adjusts the acceleration (ramp) rate providing improved throttle control especially on slippery tracks. • Cutoff Point: Allows the selection of a throttle position where the ramp rate is disengaged when the throttle output is above that point. •...
Page 65 ABS (AUTOMATIC BRAKING SYSTEM) ABS helps prevent brake lock-ups and improves braking performance by pulsing the brakes. • Engagement Point: The throttle position that the pulse braking takes place (0 to 100, default is 60). • Pulse Width: The distance the throttle travels during the pulse braking (0 to 100, default is 50).
Page 66: Servo Speed
SERVO SPEED Use the servo speed menu to slow the output speed of the throttle servo. Change the servo speed by dragging the slider to make large adjustments and fine tune the value by touching the the + or – buttons on the ends of the scale.
Page 67 AWD MODE- (MOA) Motor-On-Axle (MOA) programming allows on the fly power distribution from the front to rear wheels. The adjustment ranges from 100% rear 0% front to 0% rear 100% front. The default setting is 50%/50%. This setting can be assigned to a trimmer switch, or programmed and attached to drive modes.
Page 68: Throttle Trim
THROTTLE TRIM Throttle trim adjusts the throttle neutral position. The number of steps each press of the trim button affects the throttle trim, as well as the button assignment, is adjusted in this menu. The default value is +9 and is assigned to trimmer A.
Page 69 IDLE UP Used with gas engines, Idle Up advances the throttle’s idle position allowing for easier cold engine starting. Idle up can be assigned to any trimmer or switch. When idle up is available, an alert can be programmed warning when idle up is active. See the Alerts section for information on how to create the idle up alert.
Page 70: Channel Properties
AUXILIARY (AUX) CHANNEL SETUP Similar to the steering and throttle brake/ reverse menus, the AUX setup menu allows for programming of any auxiliary channel functions added in the model setup process: • Travel • Input Control • Subtrim • Servo Speed •...
Page 71 Subtrim Used to correct minor servo arms/ linkages inaccuracies. IMPORTANT: Use minimal subtrim values. Subtrim offsets the entire stroke including the center and endpoint positions. Reverse Reverses the channel output direction.
Page 72: Input Control
INPUT CONTROL This menu changes depending on which button or switch is selected to control the function. • Select the input switch. • If the switch selected allows, choose how many positions will be used. • If the switch selected allows, choose the number of steps for each button press.
Page 73 SERVO SPEED Use the servo speed menu to slow the output speed of the aux channel. Change the servo speed by dragging the slider to make large adjustments and fine tune the value by touching the the + or – buttons on the ends of the scale.
Page 74: Setup Settings
SETUP SETTINGS ALERTS Select the Alerts menu to enable idle up and timer alerts as well as assign the type of alert desired. Tone, Vibrate, Tone + Vibrate or Voice are the available options. Available alerts include: • Idle Up •...
Page 75 IDLE UP ALERT The idle up alert is available when the gas/ nitro power option is selected in the model setup process. To set up an idle up alert: 1. Ensure idle up is configured in the throttle brake/reverse menu, including assigning it to a button or switch.
Page 76: Timer Alert
TIMER ALERT Alerts are available for timers 1-3 and are enabled by default. The options for each timer are listed individually in the alerts menu. 1. Select disabled or enabled for the timer. 2. Select the alert type. 3. Select the voice announcement button. When depressed, the voice announcement gives the current time on the timer.
Page 77 AUDIO EVENTS REPORTS To add a switch report: 1. Touch Add Report. 2. Touch the new bar.
Page 78 3. Touch the bar under Input Control to connect the alert to a button. 4. Select the alert type for each switch position; tone, vibrate, tone + vibrate, or voice. 5. If voice was selected in the previous step, touch the field beneath the alert type. Either touch the blank field to enter the voice text or touch the Macros button to choose from a list of pre-defined alerts.
Page 79 WARNINGS To access the warnings list touch the Warnings tab at the top of the Audio Events menu. All currently programmed warnings are listed. Warnings with grayed out tabs are disabled. Touch any of the warnings listed to enable/ disable or change the warning settings.
Page 80 TX BATTERY VOLTAGE THRESHOLD To set the voltage threshold for the transmitter battery warning: 1. Select the TX Battery warning bar. 2. Touch in the Threshold bar. 3. Enter the desired voltage threshold. 4. Select any other desired changes for the transmitter battery alert.
Page 81 To add a new warning: 1. Scroll to the bottom of the warnings list. 2. Touch Add Warning. 3. Touch the new warning, marked “None” to access the settings. 4. Select Enable to activate the warning. 5. Select a telemetry type. Types are divided by general category.
Page 82 To delete a warning: 1. Touch the warning you wish to delete. 2. Scroll to the bottom of the Settings list. 3. Touch the Delete Warning button. 4. Touch Yes to confirm.
Page 83: Avc ® (Active Vehicle Control)
(ACTIVE VEHICLE CONTROL) ® technology is available, only when an ® AVC capable receiver is selected. Enable/Disable Turn AVC on or off. STEERING GAIN The default value is 50%. As the value increases, the AVC steering stability increases. If the front wheels begin to shake, the ST Gain value is too high.
Page 84: Throttle Gain
THROTTLE GAIN The default value is 50%. As the value increases, the throttle management increases.
Page 85 PRIORITY The default value is 0%, meaning AVC technology is active throughout the steering range. As you turn the steering wheel away from center (neutral), the transmitter controls have priority over the AVC system. Increasing the Priority value decreases how active AVC is as the steering wheel is turned left and right.
Page 86 BINDING Binding is the Process of teaching the receiver the specific transmitter’s code called GUID (Globally Unique Identifier) and storing failsafe values. When a receiver is bound to a transmitter/model memory, the receiver will only respond to that specific transmitter/ model memory.
Page 87 To bind the transmitter to a receiver 1. Touch the Desired Frame Rate drop down to select from 5.5ms, 11ms and 22ms. • 5.5ms is only available on certain receivers from the model setup procedure. Check your receiver manual for more information. •...
Page 88: Drive Modes
DRIVE MODES Drive modes allow for different setups for a particular model. For example, you can create one drive mode for racing on a high bite clay track and another drive mode for a dry, loose track. Each model can have several drive modes programmed to a switch or button for on-the-fly changes between modes.
Page 89 • Touch the On-the-Fly Button drop down to select a button or switch to enable instant mode changes. The number of drive modes available will change according to which button is chosen. • Touch the Drive Mode button to change the drive mode name.
Page 90: Launch Control
LAUNCH CONTROL This feature allows the driver to customize a launch curve to control the duration of time it takes to reach full throttle as well as adjusting points in the throttle curve to effectively ramp the throttle to the driver’s preference, allowing for consistent starts race after race.
Page 91 LAUNCH CONTROL Start Button The start button controls the start of the Launch Control sequence. There are two common ways to use the start button: • As a hand brake: Press and hold the assigned button to disable the throttle channel.
Page 92 • As a pre-launch stage: When you are on the starting line, ready to run, tap the button to start the Launch Control sequence. The alert selected for the launch sequence will activate and continue until the sequence runs. When the race starts, pull full throttle to begin the run.
Page 93 Curve Selector Curve Selector allows the selection of a different launch curve with the touch of the selected switch. This may be configured to as many positions as the selected switch supports. When set to None a total of five curves are available, and the curve selected is specified in the Active Curve field.
Page 94 LAUNCH CURVE Duration Select the total duration time of the launch control sequence, up to 5.0 seconds. Curve The default launch curve has 4 points. The first and last points will always be at 0,0 and 100,100 respectively and are not adjustable. The horizontal value represents time as a percentage of the total sequence duration.
Page 95 Add up to 4 additional points (8 total) to the curve by touching the the curve where you wish to add a point. Change the position of the points by first touching the point to be adjusted, then dragging the Time or Power slider to make major value changes and the + or –...
Page 96 LAUNCH CONTROL TIPS Start Button: set to any available switch that is easily accessible. An easy way to select the switch is to choose the option and press the button/trimmer on your transmitter to automatically change it to the switch of your choice. Launch control must be activated before every run down the track, so remember to hit the start button before every run.
Page 97 Mode to an open switch in the Drive Mode menu and select how many drive modes you would like to use, before proceeding to assign it in the Launch Control menu. We use the “I” switch next to the knob as it’s easy to toggle at the line and is not easy to accidently change.
Page 98 LIGHT/LED The Light/LED menu contains the LED flashlight as well as the LED light bar controls. FLASHLIGHT To activate the flashlight, from the Light/LED menu, touch the slider. When the flashlight is on, select a Turn Off After value to automatically turn the flashlight off, or keep the default value of Never to keep the flashlight on.
Page 99: Light Bars
LIGHT BARS The RGB color LEDs on the sides of the iXSR are adjustable in the light bars menu. The LED bars are on by default. • Turn off the LEDs by touching the slider. • When the LEDs are on, select a Turn Off After value to automatically turn the LEDs off, or keep the default value of Never to keep the them on.
Page 100 MAPPINGS The Mappings menu displays an overview of all transmitter and receiver functions as they are currently setup for the active model. Use the mapping screen to help correctly connect servo and auxiliary equipment to the correct receiver port.
Page 101 MIXES A mix connects a source channel to target channel. The iXSR features preset steering mixes (activated in the model setup process) and up to 16 programmable mixes. • Steering, Throttle/Brake, AUX1, AUX2, AUX3 and AUX4 are available to serve as the target or source channel.
Page 102 3. Touch the new mix to enter the mix options screen. 4. Enable the mix. 5. Touch the mix name to enter a new name.
Page 103 6. Select the mix source. The source can be either a group (steering, throttle, etc...) or an input (button or switch). • If a group is selected, choose to include the source trim or not. • If an input is selected, choose the type of switch desired.
Page 104 To delete a mix: 1. Enter the mix options screen. 2. Scroll to the bottom of the menu. 3. Touch Delete Mix 4. Confirm by touching Yes.
Page 105: Sleep Mode
SLEEP MODE The Sleep Mode menu allows you to turn off specific functions of the iXSR or put the transmitter in full sleep mode to conserve the transmitter battery between runs. The following options are available: • Spektrum RF • Screen •...
Page 106 Select Spektrum RF, Screen, or Bluetooth and long press Apply to turn off any of these functions. Depending on which functions you chose to put to sleep, either rapidly press the power button once to wake the screen, or return to the Sleep Mode menu to power on the RF or bluetooth.
Page 107 TELEMETRY The Telemetry SetUp Screen allows for editing values as well as how the information is displayed on the Telemetry Screen. Available functions: • Temperature • Receiver Battery • Speed/RPM • GPS For each telemetry sensor listed, tap Display on Dashboard to either hide or display the telemetry information.
Page 108 For the Speed/RPM to display accurately, you must input the sensor type, motor pole count (if using a brushless motor/sensor type), and an accurate roll-out measurement for the vehicle.
Page 109 To save a log file of your run, enable the File Settings at the bottom of the menu. Select a file name, On/Off button, and designate it as a one time event or not.
Page 110 TELEMETRY GAUGES Add custom telemetry gauge panels to the main screen with the telemetry gauges menu. Up to 6 additional panels can be created, only 1 of which can be displayed on the main screen list. To add a custom telemetry panel: 1.
Page 111 Gauge Name Touch the name to add a custom name. Sensor Type Select the desired sensor from the list. Gauge Type Touch on the gauge to change the appearance of the gauge. Select from the pre-configured list. Gauge Style Select from solid fill, major gridlines or minor gridlines.
Page 112 TIMERS The iXSR offers 5 timers, all viewable from the dashboard. Pause and reset the timers directly on the dashboard or configure a timer switch or button. Available timers include: • Total Time • Down Timer • Model Time • Rolling Lap Timer •...
Page 113 Touch the Timers menu item from the Setup menu to configure the timers as well as to clear the model and total drive times. Timers 1-3 can be configured to be either an up, down or lap timer. Configure the Timers Alert type (Tone, Vibrate, Tone + Vibrate or Voice), by going to the Alerts screen in SetUp.
Page 114 Up Timer The Up Timer counts up, functioning as a stopwatch when triggered via a selectable button/switch. It is useful for timing a fuel run to determine fuel mileage/pit stop strategy or, for electrics, to time the run time of a pack to determine gear ratio and setup information.
Page 115 Down Timer The down Timer counts down, when triggered via a selectable button/switch. When the down timer expires, an Alert will sounds and the timer begins to count up. • Select minutes (0-599) and seconds (0-59) by tapping in the appropriate box. •...
Page 116 Repeat Timer Start the Repeat Timer via a selectable programmable switch. When the timer expires, an alarm sounds and the timer resets and begins to count down again. • Select minutes (0-599) and seconds (0-59) by tapping in the appropriate box. •...
Page 117 PHYSICAL ADJUSTMENTS The iXSR is designed to be adjustable to suite a wide variety of driver needs. All control inputs can be configured for left or right handed driving with adjustable angle and spring tension. Available adjustments: • Trigger and steering tension •...
Page 118 THROTTLE TENSION To adjust the throttle trigger tension, using a 1.5mm hex wrench, turn the throttle tension screw counter clockwise to decrease the tension or clockwise to increase the tension.
Page 119 THROTTLE DISTANCE To adjust the throttle trigger forward or bacward: 1. Remove the front cover. 2. Using a 2mm hex wrench, turn the trigger position adjustment screw clockwise to move the trigger forward and counter clockwise to move the trigger backward. IMPORTANT: Do not turn the adjustment screw past the stopping point of the trigger adjustment range.
Page 120 STEERING TENSION To adjust the steering wheel tension, using a 1.5mm hex wrench, turn the steering tension screw clockwise to decrease the tension or clockwise to increase the tension...
Page 121 STEERING WHEEL OPTIONS The iXSR includes two different size steering wheels to better fit your driving style. To change the steering wheel: 1. Using a 1.5mm hex driver, remove the steering wheel retention screw. 2. Remove the steering wheel. 3. Install the desired steering wheel. 4.
Page 122 DROPDOWN ROTATION The iXSR dropdown steering mechanism can be rotated forward or backward to customize the wheel location for a perfect feel. 1. With the transmitter powered OFF, using a 2.5mm hex wrench, remove the steering mechanism cover screw, and remove the cover. 2.
Page 123 3. Rotate the drop down to the desired angle. The mechanism has detents to aid in holding an angle. There are 4 notches of travel from one extreme to the other. IMPORTANT: Do not try to force the mechanism to rotate further. Damage to the transmitter or mechanism may result.
Page 124 CHANGE RIGHT- TO LEFT-HANDED The iXSR can be configured for either right or left handed drivers. Before beginning, find the alternate side covers included with your transmitter. 1. Power OFF the iXSR 2. Using a 2.5mm hex wrench, remove the front cover screw and remove the cover.
Page 125 7. Connect the 2 wire connectors of the steering mechanism to the board on the other side of the transmitter. Note that one connector has 6 pins and the other has 7. 8. Align the screw holes of the mechanism and the body of the transmitter and re- install the 3 screws being careful not to pinch any wires.
Page 126 detents in the transmitter body before fully tightening the screws. IMPORTANT: Do not overtighten the screws. 9. Install the steering cover over the steering mechanism. Use the open bottom cover designed for the selected side of the transmitter. The covers are not interchangeable.
Page 127: Year Limited Warranty
1-YEAR LIMITED WARRANTY What this Warranty Covers Horizon Hobby, LLC, (Horizon) warrants to the original purchaser that the product purchased (the “Product”) will be free from defects in materials and workmanship for a period of 1 years from the date of purchase.
Page 128 AND FITNESS FOR A PARTICULAR PURPOSE. THE PURCHASER ACKNOWLEDGES THAT THEY ALONE HAVE DETERMINED THAT THE PRODUCT WILL SUITABLY MEET THE REQUIREMENTS OF THE PURCHASER’S INTENDED USE. Purchaser’s Remedy Horizon’s sole obligation and purchaser’s sole and exclusive remedy shall be that Horizon will, at its option, either (i) service, (ii) repair, or (iii) replace, any Product determined by Horizon to be defective.
Page 129 CONTRACT, WARRANTY, TORT, NEGLIGENCE, STRICT LIABILITY OR ANY OTHER THEORY OF LIABILITY, EVEN IF HORIZON HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Further, in no event shall the liability of Horizon exceed the individual price of the Product on which liability is asserted. As Horizon has no control over use, setup, final assembly, modification, use or misuse, no liability shall be assumed nor accepted for...
Page 130 WARRANTY SERVICES Questions, Assistance, and Services Your local hobby store and/or place of purchase cannot provide warranty support or service. Once assembly, setup or use of the Product has been started, you must contact your local distributor or Horizon directly. This will enable Horizon to better answer your questions and service you in the event that you may need any assistance.
Page 131 carrier that provides tracking and insurance for lost or damaged parcels, as Horizon is not responsible for merchandise until it arrives and is accepted at our facility. An Online Service Request is available at http:// www.horizonhobby.com/content/service- center_render-service-center. If you do not have internet access, please contact Horizon Product Support to obtain a RMA number along with instructions for submitting your...
Page 132 Warranty Requirements For Warranty consideration, you must include your original sales receipt verifying the proof-of-purchase date. Provided warranty conditions have been met, your product will be serviced or replaced free of charge. Service or replacement decisions are at the sole discretion of Horizon. Non-Warranty Service Should your service not be covered by warranty, service will be completed...
Page 133 www.horizonhobby.com/content/service- center_render-service-center. ATTENTION: Horizon service is limited to Product compliant in the country of use and ownership. If received, a non-compliant Product will not be serviced. Further, the sender will be responsible for arranging return shipment of the un-serviced Product, through a carrier of the sender’s choice and at the sender’s expense.
Page 134: Warranty And Service Contact Information
RequestForm/ Horizon Product Support (Product Technical Assistance) productsupport@horizonhobby.com 877-504-0233 Sales websales@horizonhobby.com 800-338-4639 2904 Research Rd Champaign, IL 61822 USA European Union Horizon Technischer Service service@horizonhobby.de Sales Horizon Hobby GmbH +49 (0) 4121 2655 100 Hanskampring 9 D 22885 Barsbüttel, Germany...
Page 135: Fcc Information
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Supplier’s Declaration of Conformity Spektrum iXSR 6 Channel Surface Transmitter (SPM6420); This device complies with part 15 of the FCC Rules. Operation is subject...
Page 136 CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
Page 137 • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/ TV technician for help. Horizon Hobby, LLC 2904 Research Road, Champaign, IL 61822 Email: compliance@horizonhobby.com Web: HorizonHobby.com...
Page 138 IC INFORMATION IC: 6175A-SPMR6420 CAN ICES-3 (B)/NMB-3(B) This device contains license-exempt transmitter(s)/receivers(s) that comply with Innovation, Science, and Economic Development Canada’s license-exempt RSS(s). Operation is subject to the following 2 conditions: 1. This device may not cause interference. 2. This device must accept any interference, including interference that may cause undesired operation of the device.
Page 139: Compliance Information For The European Union
FOR THE EUROPEAN UNION EU Compliance Statement: Spektrum iXSR 6 Channel Surface Transmitter (SPM6420); Hereby, Horizon Hobby, LLC declares that the device is in compliance with the following: EU Radio Equipment Directive 2014/53/EU; RoHS 2 Directive 2011/65/EU; RoHS 3 Directive - Amending 2011/65/EU Annex II 2015/863.
Page 140 Bluetooth: Frequency Band: 2402-2480MHz Max EIRP: 8.30 dBm EU Manufacturer of Record: Horizon Hobby, LLC 2904 Research Road Champaign, IL 61822 USA EU Importer of Record: Horizon Hobby, GmbH Hanskampring 9 22885 Barsbüttel Germany WEEE NOTICE: This appliance is labeled in...
Page 141 ® registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Horizon Hobby is under license. The WiFi logo is a registered trademark of WiFi Alliance. All other trademarks, service marks and logos are property of their respective owners.
