Summary of Contents for Titan DBC Series
- Page 1 DBCSERIES Gasoline Brush Cutters USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1. PARTS LOCATION ..........................2 2. WARNING LABELS ON THE MACHINE ....................3 3. SYMBOLS ON THE MACHINE ....................... 3 4. FOR SAFE OPERATION .......................... 4 5. SET UP ..............................8 6. FUEL ..............................10 7. OPERATION ............................12 8. -
Page 3: Parts Location
1. PARTS LOCATION 1. Engine 11. Protection shield 2. Air cleaner cover 12. Protection shield plate 3. Choke lever 13. 3T blade 4. Recoil starter 14. Line Head 5. Handle 15. Wrench 6. Handle branket 16. Angled bar 7. Pipe 17. -
Page 4: Warning Labels On The Machine
2. WARNING LABELS ON THE MACHINE (1) Read owner's manual before operating machine. (2) Wear head, eye and ear protection. (3) Wear foot protection. (4) Wear gloves. (5) Beware of thrown objects. (6) Warning / Attention (7) Keep all children, bystanders and helpers 15 meters away from the brush cutter IMPORTANT If warning label peel off or become soiled and impossible to read, you should contact the dealer from which you purchased the product to order new labels and affix them in the required loca-... -
Page 5: For Safe Operation
4. FOR SAFE OPERATION 1. Read this manual carefully until you completely understand and follow all safety and operating instructions. 2. Keep this manual handy so that you may refer to it later whenever any questions arise. Also note, if you have any questions which cannot be answered herein, contact the dealer from whom you purchased the product. - Page 6 - WORKING CIRCUMSTANCE 1. Never start the engine inside a closed room or building. Exhaust gases contain dangerous carbon monoxide. 2. Never use the product, a. when the ground is slippery or when you can’t maintain a steady posture. b. At night, at times of heavy fog, or at any other times when your field of vision might be limited and it would be difficult to gain a clear view of the working area.
- Page 7 - BEFORE STARTING THE ENGINE 1. The area within a perimeter of 50 feet (15m) of the person using the product should be considered a hazardous area into which no one should enter. If necessary, yellow warning rope, warning signs should be placed around the perimeter of the area.
- Page 8 - USING THE PRODUCT IMPORTANT Cut only materials recommended by the manufacturer. And use only for tasks explained in the manual. 1. Grip the handles firmly with both hands using your whole hand. Place your feet slightly apart (slightly further apart than the width of your shoulders) so that your weight is distributed evenly across both legs, and always be sure to maintain a steady, even posture while working.
-
Page 9: Set Up
- HANDLING FUEL 1. The engine of the product is designed to run on a mixed fuel which contains highly flammable gasoline. Never store cans of fuel or refill the tank of the unit in any place where there is a boiler, stove, wood fire, electrical sparks, welding sparks, or any other source of heat or fire which might ignite the fuel. - Page 10 - INSTALLING PROTECTION SHIELD (04) Attach the protection shield with the bolts combined to the shaft tube. - INSTALLING CUTTING BLADE (05) 1. Put the angled bar (1) into the side holes of the gear case (2) and the plate (3) so as to fasten the axle. 2.
-
Page 11: Fuel
6. FUEL WARNING • Gasoline is very flammable. Avoid smoking or bringing any flame or sparks near fuel. • Wipe up all spills before starting the engine. • Make sure to stop the engine and allow it cool before refueling the unit. •... - Page 12 (1) Choke lever (2) Closed position (3) Open position 4. Set the ignition switch to the “start” position. While pulling the throttle lever, push the throttle set button, and release the throttle, then the throttle lever is into the “Start position. (OP3) (A) Stop position (B) Start position 5.
-
Page 13: Operation
- LINE HEAD USAGE WARNING 1. Always wear eye protection such as safety goggles. Never lean over the rotating cutting head. Rocks or other debris could be thrown into eyes and face and cause serious personal injury. 2. Keep the debris guard attached in place at all times when the unit is operated. - Page 14 METAL BLADE USAGE CUTTING METHOD Choose a suitable recommended cutting attachment according to the object to be cut. WARNING • When sharpening, removing, or reattaching the blade, be sure to wear thick, sturdy gloves and use only proper tools and equipment to prevent injury.
-
Page 15: Maitenance
• Turn off the engine and make sure the blade has completely stopped before checking the blade, and removing any object got caught in. CONTROLLING BLADE BOUNCE • Kick out can cause serious personal injury. Carefully study this section. It is important that you understand what causes kick out, how you can reduce the chance of kick out and how you can remain in control of the unit if kick out does occur. - Page 16 - AIR FILTER • The air filter, if clogged, will reduce the engine performance. Monthly check and clean the filter element in warm, soapy water as required. Dry completely before installing. If the element is broken or shrunk, replace with a new one. (1) Air filter - FUEL FILTER •...
- Page 17 SPARK PLUG • Starting failure and mis-firing are often caused by a fouled spark plug. Periodically clean the spark plug and check that the spark gap is in the correct range. • When you take off the spark plug, twist (1) and pull off the cap (2).
-
Page 18: Storage
- PROCEDURES TO BE PERFORMED AFTER EVERY 10 HOURS OF USE 1. Remove the muffler, insert a screwdriver into the vent, and wipe away any carbon buildup. Wipe away any carbon buildup on the muffler exhaust vent at the same time. 2. -
Page 19: Specifications
11. SPECIFICATIONS MODEL DBC260 DBC330 DBC430 DBC520 DTR300 Single cylinder, 2 stroke, air cooled Engine 26 cc 30.5 cc (CE) / 33 cc (not CE) 52 cc 26 cc 42.7 cc (CE) / 43 cc (not CE) Displacement 600 ml 850 ml 1200 ml 1200 ml... -
Page 20: Warranty
www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
