Summary of Contents for Serato RANE SEVENTY
- Page 1 User Guide English (3–19) Guía del usuario Español (20–38) Guide d'utilisation Français (39–57) Guida per l'uso Italiano (58–75) Benutzerhandbuch Deutsch (77–95) Appendix English (97–98) Powered by Serato DJ Pro...
-
Page 2: Box Contents
Box Contents Seventy Power Cable (2) Serato NoiseMap™ Control Vinyl Records (2) Serato NoiseMap™ Control CDs Serato Pitch 'n Time Download Card with Serial Number (2) USB Cables Rane Stickers User Guide Safety & Warranty Manual Support For the latest information about this product (documentation, technical specifications, system requirements, compatibility information, etc.) and product registration, visit rane.com. - Page 3 Player Note: Seventy is Serato DVS enabled, which allows you to control a track in Serato DJ Pro with a vinyl turntable or CD player connected to one of Seventy’s PH/CD or Aux inputs. To use DVS with Seventy, you need Serato...
- Page 4 Features Top Panel...
- Page 5 Hold Shift and press this button to cycle through the Files, Browse, Prepare, and History windows in Serato DJ Pro. Load Prep: Press this button to send the highlighted track to the Prepare window in Serato DJ Pro. Hold Shift and press this button to open the Prepare window.
- Page 6 FX Buttons: Use these buttons to select or deselect effects for activation by the Effects Toggles. FX Mode Button: Use this button to determine whether the FX Buttons select Seventy’s internal Flex FX or software effects. While in Flex FX Mode, the FX Mode Button will be lit blue. While in Software Effects Mode, the button will be lit amber.
-
Page 7: Rear Panel
Rear Panel Power Input: While Seventy is powered off, connect the included power cable to this input and then to a power outlet. Power Switch: Use this switch to power Seventy on or off. Power on Seventy only after you have connected all of your input devices and before you power on your amplifiers and loudspeakers. -
Page 8: Front Panel
Front Panel Headphone Outputs (1/4”, 1/8” / 6.35 mm, 3.5 mm, TRS): Connect your 1/4” or 1/8” (6.35 mm or 3.5 mm) headphones to this output for cueing and mix monitoring. Mic 2 On: When set to On, the Mic 2 Input on the rear panel is active, and its audio signal is routed directly to the program mix and cue mix. - Page 9 Operation Looping Each deck on the Seventy is equipped with three buttons on the top panel that you can use to easily create and modify loops. Each button has a primary function (printed above the button) and a secondary function (printed below the button). To activate an autoloop of a track playing on a deck, press the deck’s Loop On/Off (Reloop) button.
- Page 10 Main Menu section of this manual for more help navigating the settings). Also, make sure that Serato DJ Pro is set to Multi FX mode by going to the FX tab and selecting the deck’s icon. In Software Effects Mode, the FX buttons to the left of the FX Mode button will correspond to Bank A software effects (routed by default to Deck 1), and the three FX buttons to the right of the FX Mode button will correspond to Bank B software effects (routed by default to Deck 2).
- Page 11 By default, the available beat division settings for the Flex FX range from 1/32T (32nd note triplet) – 32D (32 bars dotted), while the beat division settings for Serato DJ Pro effects range from 1/16 (16th note) – 8 (8 bars).
-
Page 12: Pad Modes
The Serato Pitch ‘n Time DJ Expansion Pack must be installed to use this mode. See learn how to assign hot cue points. Note: A Serato Pitch 'n Time download card with (original semitone semitones semitones serial number is included with your Seventy. - Page 13 (i.e., as if the track had been playing forward the whole time). Note: Disable Show Beat Jump Controls in the Serato Setup menu to access 8 loop rolls at once. You can also view and edit the set loop sizes in the software.
- Page 14 To assign a sample, first highlight the desired sample in your library. Then hold Shift and press a pad corresponding to an empty sampler slot. The sampler slot volume can be adjusted in Serato. To play a sample, press a lit pad. The pad will flash as the sample plays.
- Page 15 In the main Serato DJ Pro window, click the MIDI button at the top of the screen to begin mapping. Click a feature in Serato DJ Pro, then touch or move a control on your hardware to map the feature to that control.
-
Page 16: Menu Options
Clean Feed: When this setting is On, Serato DJ Pro will not receive audio from the Seventy’s Mic 1 Input while recording is in progress. This way, you can record your live DJ set and still use the... - Page 17 • Defaults: Select this option to restore all of the Flex FX settings to their factory default values. Software FX: Select this page to adjust how Serato DJ Pro’s software effects function with the Seventy: • Multi FX: Setting this to On will enable you to use stacked software effects (as described in the Effects section).
-
Page 18: Control Panel
Control Panel The Rane Control Panel allows you to adjust settings on your Seventy mixer and save and load these settings to a file (.r72) on your computer. Using settings files lets you maintain several different control configurations to use in different situations.
