- Page 1 Automatic Fiber Stripping Machine Model: ST-5000T Operating Instruction www.SunmaFiber.com...
- Page 2 Simple introduction The newly developed ST-5000T automatic fiber peeling machine is a new type of optical cable end processing equipment, which is based on the eagerness of optical fiber connector manufacturers to improve production efficiency and reduce the skilled manual emergence of optical cable end processing equipment. In order to solve the problem that the skin layer of optical fiber is usually peeled manually with wire peeling pliers, the diameter of optical fiber is 0.9mm, while the central...
- Page 3 Pre-statement First of all, thank you very much for using our equipment. Before using this machine, be sure to read this instruction. This machine belongs to electrical products. It shall comply with the safety matters and pay enough attention to the safety. The machine shall be used correctly. The wrong operation and use method can cause other accidents or shorten the service life of the equipment.
-
Page 4: Main Parameters
I. main parameters Length and source power pressure output width height weight rating >600pcs/H 420*330*240 15KG AC220 420W 0.5~0.6Mpa size of fiber-stripping length range product 2 to 8 cores 5~40 II. Structure description and working principle 1. The machine main frame adopts a novel and unique technical scheme, so that the whole machine is light and convenient to operate and is in accordance with the human engineering. -
Page 5: Adjustment Method
IV. Adjustment method The source must be turned off and off before calibration!!! 1, wire module adjustment: put the optical fiber to 1 from the input port, then press the manual screen from the main interface on the touch screen, and then click on the pressing switch to see if the optical fiber is loose. - Page 6 (2) Loosen the four M4 screws at the base to adjust the distance between the upper and lower knife edges. The normal operation of the lower knife is good (no need to be re-adjusted). When the outer skin is peeled, the upper knife will be fine-tuned while the glass fiber is cut and the upper knife is fine-tuned.
- Page 7 4. Upper pressing block guide post Note that the guide column adds oil ( MACHINE oil) once a day while working 5.Temperature control: because the material difference is generally 50~C °. www.SunmaFiber.com...
-
Page 8: Matters Needing Attention
V. matters needing attention 1. This machine is suitable for air pressure between 0.5~0.6Mpa; 2. Input voltage is AC220V 3. During the operation. If the machine is abnormal, turn off the power supply, and ask the mechanic to carry out the repair or debugging in a timely manner; 4. - Page 9 Warranty card for after-sales service User unit Contacts Contact Address number Purchasing time Device name Unit name Equipment number Unit seal: www.SunmaFiber.com...
