- Page 1 User Manual, Operating Instructions and Specifications PrepMaster Multi Mechanical Rotary PE pipe end Scraping Tool Diameter Size Range: 90 – 400mm Product Code: 700-000147 ELECTROFUSION • • • • INNOVATION DESIGN MANUFACTURE SUPPLY...
-
Page 2: Table Of Contents
Contents Product description ……………………………………………………………………………………………Page 3 Introduction ……………………………………………………………………………………………………..Page 3 Health and safety notes ……………………………………………………………………………………..Page 4 Photo gallery ……………………………………………………………………………………………………..Page 5 Schematic parts drawing …………………………………………………………………………………….Page 6 Parts list and component part numbers ………………………………………………………………..Page 7 Specifications ……………………………………………………………………………………………………..Page 8 Operating instructions …………………………………………………………………………………………Page 9 Maintenance and storage …………………………………………………………………………………….Page 10 EC Declaration of conformity…………………………………………………………………………………Page 11 Certificate of calibration ……………………………………………………………………………………….Page 12 Decommissioning &... -
Page 3: Product Description
The Hy-Ram PrepMaster Multi range of scraping tools incorporate a hardened steel blade to give a controlled depth of cut over a range of pipe diameters. -
Page 4: Health And Safety Notes
Health and Safety Notes Warning: The PrepMaster Multi range of scraping tools incorporate a hardened steel blade to give a controlled depth of cut over a range of pipe diameters. The cutting blade is sharp and care must be taken when handling the tool and especially the blade [The cutting blade is 4-sided and can be easily rotated using a 2.5mm Allen key]. -
Page 5: Photo Gallery
Photo gallery Hy-Ram PrepMaster 90-400mm Complete with steel Carrying Case Handle (23) Front Plate (1) Carriage Arm (29) Carriage Arm Knob (31) Trolley Engage Knob (9) Cutter Carrier Knob (19) Trolley (6) Feed Screw (22) Cutter Block (14) Cutter Block Knob (13) -
Page 6: Schematic Parts Drawing
Schematic parts drawing P a g e... -
Page 7: Parts List And Component Part Numbers
Parts list and component part numbers ITEM PART NO: DESCRIPTION 645-000258 FRONT PLATE 023-000274 RUBBING BAR SCRW-M6x25mmBHSBZP M6 x 25LG HEX SKT BUTTON HD SCREW, BZP 033-000020 DEEP GROOVE BALL BEARING 645-000259 BACK PLATE 033-000020 DEEP GROOVE BALL BEARING 046-000038 TROLLEY 648-000091 PLUNGER... -
Page 8: Specifications
Plastic pipes and fittings – Equipment for fusion jointing polyethylene systems. (Note – this specification is mainly for control units) Note: Hy-Ram Engineering Co. Ltd. operate a policy of continual improvement and therefore reserves the right to modify product specifications without notice... -
Page 9: Operating Instructions
Operating Instructions 1. Check the pipe for any damage or abrasions that may be detrimental to the performance of the joint. Ensure the pipe ends to jointed are cut square to the axis and burrs removed. If required, wash down the pipe ends in excess of the area to be scraped to remove traces of dirt or mud. If using wet wipes, ensure they are in compliance with the relevant specification. -
Page 10: Maintenance And Storage
Maintenance and storage 1. When the tool is not in use always store in the steel carrying case. 2. Ensure the tool is stored in a clean condition free of dirt and mud. 3. Before storing, ensure the Cutter spring tension is released. i.e. rotate Cutter Carrier Knob (19) [1/4 turn] in order that the Cutter Holder (15) is in the low/engaged position. -
Page 11: Ec Declaration Of Conformity
Modifications to the equipment without prior written approval by the undersigned will render this declaration null and void. For and on behalf of the manufacturer: Being a nominated person appointed by the manufacturer, and employed by Hy-Ram Engineering Co Ltd]. Signature: ……………………………………………………………….. -
Page 12: Certificate Of Calibration
The standard Terms and Conditions of trade form part of this warranty. Hy-Ram Engineering Co Ltd will, at its option, repair or replace (with a new or reconditioned unit of like condition). - Page 13 (see also the form at the rear of this document). Hy-Ram will not be responsible for any loss or damage incurred in connection with the return of the product. To the extent that this warranty statement is inconsistent with the law of the locality where the customer uses the product, this warranty statement shall be deemed modified by the minimum necessary to be consistent with such local law.
- Page 14 For Sales, Hire and Repair support contact our admin team or scan the QR code for further details www.hyram.com +44 (0) 1623 422982 enquiries@hyram.com Head Office Mansfield (Hire & Repair) Bury (Hire & Repair) Enfield (Hire & Repair) Pelham Street Unit 5 Unit 18 Unit 2...
