- Page 1 PL-12 USB-PAR12 Partyspot User Manual item number: 00069697 Version: 08/2020...
- Page 2 Thank you for choosing this product. To ensure that you are completely satisfied with this product, please read and understand this manual carefully. PLEASE READ CAREFULLY Please keep this manual in a safe place for future reference. Hand over all documents when passing on the product to third parties.
- Page 3 Caution Please observe the following basic instructions in order not to endanger yourself or others and to avoid damage to external devices. Warnings Do not disassemble or modify the product. This could result in injury from electric shock. If you notice that the power cord shows obvious signs of wear, the appliance is malfunctioning, smells burnt or smokes, immediately unplug the appliance from the wall outlet and refer servicing, maintenance or repair to an authorised service centre or your dealer.
- Page 4 Installation / Hanging mounting The installation may only be carried out by authorised specialist personnel! In case of overhead rigging, please observe the applicable standards and regulations in your country. In any case, a second independent suspension must be used to secure the unit. This can be ensured by a safety net or a suitable safety rope/chain or similar.
-
Page 5: Table Of Contents
5. Technical data ....................9 1. General overview The PL-12 USB-PAR12 Partyspot is a powerful RGBW LED light effect that produces multicolored light beams. The best effect you get in connection with a fog machine. This light effect has an integrated auto program and music control. The included IR remote control can be used for color control. -
Page 6: Product Overview And Operating Elements
3. Product overview and operating elements Name Function IR receiver Receives the signal from the remote control Bracket For mounting the fixture. Loosen the plastic screws on the sides to change the angle and then tighten them again sufficiently. Lens Light emission... - Page 7 Name Function USB port for power Connect this connector to the supplied power supply 5V 2A supply. Selector switch Mode selection: Close, Auto, Sound Position Close: Blackout Auto position: Auto program Position Sound: Music control...
-
Page 8: Ir Remote Control
4. IR remote control Auto program green Music control green+blue Blackout red+30%green Reduce speed blue Increase speed white Not assigned 55% red+30% green green+30%blue red+white red+green Not assigned Not assigned Not assigned... -
Page 9: Technical Data
5. Technical data Article description PL-12 USB-PAR12 Partyspot LED Power 3x1W red, 3x1W green, 3x1W blue, 3x1W white Operating Modes Auto/Sound Size in mm 156x53.6x171 Weight in kg 0,25 Power supply 5V/2A via USB-C Power consumption Operating temperature max. 40°C... - Page 10 WEEE declaration (Waste of Electrical and Electronic Equipment) Your product has been designed and manufactured with high quality materials and components that are recyclable and can be reused. This symbol means that electrical and electronic devices must be disposed of separately from household waste at the end of their useful life.
