Page 1: Table Of Contents
Commissioning & Training For Precision Fill 2.0 Rev#0.2.0 09/25/2023 INTRODUCTION OVERVIEW PRE CHECKLIST Compressed Air Electrical Cable Foot Pedal NEXT STEPS Setting Up the HMI Understanding the Home Page Setting the Administrator Password Changing the Language Preferences Setting Up the Weight Display...
Page 2: Introduction
Precision Fill Commissioning & Training INTRODUCTION The Precision Fill Commissioning & Training Manual will allow you to transition your installed machine into a fully functional, programmed piece of machinery while equipping you with the knowledge to comfortably operate the device. companion video to this document can be located at the QR code to the right.
Page 3 Precision Fill Commissioning & Training Setup Checklist Note: Information on how to perform assembly & utility setup is provided in the Uncrate & Assembly guide. Check that the regulator is set to .3mpa: Ensure the electrical cable is plugged in and seated properly both at the outlet and the machine plug-in point.
Page 4: Next Steps
Precision Fill Commissioning & Training NEXT STEPS Setting Up the HMI The HMI (“Human Machine Interface,”commonly called a “screen”) controls all operations of the Precision Fill. Note: The machine must be plugged in and powered to perform these steps. Press the power button on the front of the machine. It should glow yellow/amber.
Page 5 Precision Fill Commissioning & Training [Image 4] 【recipe】The current Recipe number and Recipe name are displayed (02)1kg 【target】The recipe targets output weight. 【set-bat】The desired amount of bags that constitute a batch. For instance, you set a batch at 10 bags. Once 10 bags are ﬁlled, you can't ﬁll more bags, unless you press "clr alarm"...
Page 6: Setting The Administrator Password
Precision Fill Commissioning & Training Setting the Administrator Password The default Administrator Password is “0”. You do not need to set a different password, however this step will allow you to create your own passcode. Note: There are no recovery or password reset options available to the user besides factory reset.
Page 7 Precision Fill Commissioning & Training Before you put any coffee into your Precision Fill, it’s strongly recommended to check all of the functional buttons are working properly. Remove the access panels from the sides of your Precision Pill. On the Home Screen, tap the “manual testing”...
Page 8: Calibration
Precision Fill Commissioning & Training 4. slow [Slow Feed Button]: When you tap the Slow Feed button, the ﬁlling gate should be totally closed and the vibrator should be operating. When you turn the slow feed off, the vibrator should stop. You can now exit the manual testing menu and return to the home page.
Page 9 Precision Fill Commissioning & Training If the machine measures 50g, you don't need to recalibrate the weighing function. However in most cases, your machine will need to be calibrated. Follow the steps below to calibrate your machine. 1. Put a vessel below the ﬁlling spout and press “Manual Discharging”. This ensures no coffee is in the weighing chamber during calibration.
Page 10 Precision Fill Commissioning & Training 4. Press “wt-calib” 5. Press “material clb” 6. Press manual discharging to make sure all the coffee is out of the weight chamber, then press manual discharging again to close the outlet 29 July 22...
Page 11 Precision Fill Commissioning & Training 7. Press “zero clb” 29 July 22...
Page 12 Precision Fill Commissioning & Training 8. Add about 4000 grams of coffee to the intake hopper of the machine, then press “med” until coffee has entered the weighing chamber and the screen indicates about 2520g 9. Place a bag capable of holding 3000g worth of coffee on a scale and tare the scale.
Page 13: Creating A Recipe
Precision Fill Commissioning & Training Weigh the coffee in the bag and record the weight. Press the “0” and enter the weight you recorded. Press wt-calib CREATING A RECIPE 1. On the home page, tap “system maintenance” then “recp-set” Video Link 29 July 22...
Page 14: Adjusting A Recipe
Precision Fill Commissioning & Training 2. You should see this screen: 3. Tap “target set” to get to the main recipe interface. 4. Select a recipe number that hasn't been used, and tap [recipe-hide] until it displays “shown”. 5. Enter the desired name for this recipe by tapping the recipe name tab 6.
Page 15 Precision Fill Commissioning & Training The machines are calibrated at the factory with a default recipe. However as the electrical input differs from location to location, you'll have to readjust it. Starting with the default values and adjusting as needed is the best way to start. Key Characteristics: The weight listed next to a feed is the weight difference from zero which will shut off that feed type.
Page 16 Precision Fill Commissioning & Training Set Target Weight. Tap the text box next to “target” and enter 340g. Tap “ok.” Set Fast Feed. Since fast feed is used primarily for recipes weighing 1000 grams or more, we will not use Fast Feed on this recipe. Disable it by entering the target weight (340g) in the text box next to “Fast Feed.”...
Page 17 Precision Fill Commissioning & Training Wait for Cycle to Finish. Once the cycle is complete, you will see a screen similar to this (likely with different values): Adjust Slow Feed. Note that we are below our goal of 340g. This means our slow feed is too large.
Page 18 Precision Fill Commissioning & Training Generally speaking, the difference in weight will be the change needed to the slow feed value. In the example above, the end weight was 4 grams below our target so the slow feed value was reduced by 4 (from 10 to 6). In other words, decreasing the value of the slow feed by 1 will increase the ﬁnal weight by 1 gram (and increasing slow feed value by 1 will decrease the ﬁnal weight by 1 gram.
Page 19 Precision Fill Commissioning & Training ADDITIONAL RECIPE EXAMPLES: Consistency After running your recipe 4 times with a Med Feed Speed of 40, you get the following weights: 240g 258g 260g 276g Solution: Since you have inconsistent recipe outputs (regardless of target value), you'll need to increase your med feed value.
Page 20 Precision Fill Commissioning & Training Since inconsistencies returned at a Med Feed value of 85, you will return to the previous lowest value that provided consistent results (90). Repeat the same process from above, this time reducing the value by 1 instead of 5: Med Feed: 54 Med Feed: 53...
Page 21: Operating The Weigh & Fill
Precision Fill Commissioning & Training OPERATING THE WEIGH & FILL Congratulations! You have completed the Commissioning & Training portion of your Sovda Precision Fill setup! Now it’s time to run the machine as you will for days to come. CHOOSING & CHANGING OUTLET HEADS 1.
Page 22 Precision Fill Commissioning & Training Slide the tri-clamp and head off of the outlet: Place the tri-clamp around the ﬂange on the desired head: 29 July 22...
Page 23 Precision Fill Commissioning & Training Slide the head and tri-clamp onto the outlet: 5. Orient the head direction and tighten the tri-clamp: 29 July 22...
Page 24 Precision Fill Commissioning & Training SELECTING A RECIPE 1. On the Home Screen, tap “adjust”: Tap the white text box displaying the current recipe name: 3. Tap the check box next to the recipe you would like to use. 29 July 22...
Page 25 Precision Fill Commissioning & Training Verify the correct recipe box is blacked out: 5. Hit exit. Your new recipe will be displayed on the Home Screen. Operating Your Precision Fill 1. Ensure your air compressor is running, air to the machine is on, and the machine is powered on.
Page 26 Precision Fill Commissioning & Training 4. You should immediately hear the weighing cycle begin. Once the weight stabilizes, place your bag on the head and step on the foot pedal to discharge coffee. 29 July 22...
