SOVDA Precision Fill Mini Quick Start Manual

Hide thumbs Also See for Precision Fill Mini:

Advertisement

Quick Links

Download this manual
Quick Start Guide
For Precision Fill Mini
Rev#2.0.1 02/28/2024
Introduction
Assembly
Performing a Weight Calibration
Selecting and Modifying a Recipe
Additional Notes
Technical Ambassador:
service@sovdacoffee.com
+1 (971) 200-5140 (Call/Text/Whatsapp)
Europe
North America
Julian Mamaj
Neil Soque
(In Munich, GMT+1)
(In Las Vegas, GMT-8)

Advertisement

loading
Need help?

Need help?

Do you have a question about the Precision Fill Mini and is the answer not in the manual?

Questions and answers

Related Manuals for SOVDA Precision Fill Mini

Summary of Contents for SOVDA Precision Fill Mini

  • Page 1 Quick Start Guide For Precision Fill Mini Rev#2.0.1 02/28/2024 Introduction Assembly Performing a Weight Calibration Selecting and Modifying a Recipe Additional Notes Technical Ambassador: service@sovdacoffee.com +1 (971) 200-5140 (Call/Text/Whatsapp) Europe North America Julian Mamaj Neil Soque (In Munich, GMT+1) (In Las Vegas, GMT-8)
  • Page 2 Thank you for purchasing the Sovda Precision Fill Mini! This guide covers the mechanical setup of the machine. Additional recipe creation and calibration information can be found in the Precision Fill Mini user manual, linked at the bottom of this guide.
  • Page 3 Precision Fill Mini Quick Start Guide 4. Install the air regulator on the back right side of the machine using the included hardware and make the following connections: a. From air compressor to left side of regulator b. From right side of regulator to the left blue tube coming from the back of the Precision Fill Mini c.
  • Page 4 Precision Fill Mini Quick Start Guide 5. Connect your compressed air source to the air regulator and use the knob on the top of the regulator to set air pressure to .3mpa: 6. Make sure the scale sensor shipping protectors are removed.
  • Page 5 Precision Fill Mini Quick Start Guide b. Inside the machine, also remove any internal supports (you may have 2 or 3 depending on when your machine was shipped): Install the filler head by placing the tri-clamp around the top of the filler head, slide the head and tri-clamp onto the outlet, and tighten the clamp: R2.0.1...
  • Page 6 Precision Fill Mini Quick Start Guide 8. Plug in the foot pedal and power cable to the bottom of the machine and plug the power cable into the wall 9. Push the center power button on the right underside of the machine to turn the machine on.
  • Page 7 Precision Fill Mini Quick Start Guide Performing a Weight Calibration Your Precision Fill Mini was calibrated at the factory. However, we recommend re-calibrating your machine to account for possible changes in regional electrical supply or shifting of components during shipping.
  • Page 8 10. Tap “WT CLB.” The display should read 2000g 11. Tap Home You have now calibrated your Precision Fill Mini! Selecting and Modifying a Recipe On the Home Screen, tap the recipe name. You will get a list of recipes like below you can select from.
  • Page 9 Precision Fill Mini Quick Start Guide ● Slow Speed Key Characteristics: The weight listed next to a feed is the weight difference from zero which will shut off that feed type. For example, take the recipe below (or the ones enter in your precision fill mini) :...
  • Page 10 Precision Fill Mini Quick Start Guide Note the difference between a recipe being “off” and a recipe being “inconsistent;” a consistent recipe will always have a very similar output, regardless of whether or not that number is close to the target value.
  • Page 11 Precision Fill Mini Quick Start Guide Set Target Weight. Tap the text box next to “Target” and enter 340g. Tap “ok. ” Set Fast Feed. Since fast feed is used primarily for recipes weighing more than 1000 grams, we will not use Fast Feed on this recipe. Disable it by entering the target weight (340g) in the text box next to “Fast Feed.
  • Page 12 Precision Fill Mini Quick Start Guide a. If your results are not consistent over 3 filling cycles, do the opposite: Increase your Medium value by 10 until they are consistent. This also provides the fastest, consistent Medium value. Fine-Tune Slow Feed: Once you have found a consistent Medium value, you can fine-tune the recipe to hit your Target weight.

  • Page 13: Additional Notes

    (as described in the Assembly section step 6. ● If the machine presents “ADOFL” when powered on, contact Sovda Service at the below contact info and mention the machine says “ADOFL” on the screen: service@sovdacoffee.com...
