- Page 1 APA (All Points Addressable) Graphical Display Kit Instructions 7772-K451 Issue C © 2024 NCR Voyix. All rights reserved. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 2 NCR Voyix, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR Voyix in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR Voyix representative or NCR Voyix office for information that is applicable and current.
- Page 3 Table of Contents Copyright APA (All Points Addressable) Graphical Display Kit Contents Installation Procedure Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 4 Revision Record Issue Date Remarks Nov 2019 First Issue Jun 2020 Updated illustrations for steps 4 and 5 Dec 2021 Added Warning statement Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 5 APA (All Points Addressable) Graphical Display This kit provides an APA (All Points Addressable) Graphical Display for the following POS: NCR CX7 All-in-One POS (7772) NCR CX5 All-in-One POS (7773) Kit Contents Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 6 Remove the two (2) screws that secure the Cable Cover to the Back Cover. b. Rotate and unhook the Cable Cover from the Back Cover. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 7 Remove the Ethernet Cable from the Cable Management Hook then disconnect the Cable. 4. Loosen the two (2) captive screws that secure the Back Cover to the Display. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 8 5. Rotate the Back Cover away from the Display and unhook the Back Cover Tabs. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 9 6. Lift the bottom of the Plate (Logo Badge) to unsnap it from the display housing. 7. Route the Cable through the Bracket recess and install the Bracket on the display housing (2 screws). Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 10 9. Reinstall the Display Back Cover. 10. Reconnect the 180-degree USB-C Cable and Ethernet Cable. 11. Reinstall the Cable Cover. 12. Pivot the APA Graphical Display into position. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
