- Page 1 Memory Module Kit Instructions 7772-K134/K136 Issue D © 2024 NCR Voyix. All rights reserved. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
-
Page 2: Copyright
NCR Voyix, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR Voyix in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR Voyix representative or NCR Voyix office for information that is applicable and current. -
Page 3: Table Of Contents
Table of Contents Copyright Memory Module Kit Contents Installation Procedure NCR CX7 All-in-One POS (7772) NCR CX8 POS (7736) Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions. - Page 4 Jul 2019 First Issue Jun 2020 Updated illustrations for steps 4 and 5 Aug 2020 Added installation procedure for CX8 (7736) Dec 2021 Added Warning statement Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
-
Page 5: Memory Module
Description 7772-K134 8GB Memory Module 006-8626889 Memory Module – 8GB, DDR4 2400MHz, SO-DIMM, 1.2V 7772-K136 16GB Memory Module 006-8626890 Memory Module – 16GB, DDR4 2400MHz, SO-DIMM, 1.2V Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions. -
Page 6: Installation Procedure
Always use a soft material (cloth, foam) to protect the display screen when placing the terminal face down. 2. Remove the Cable Cover. a. Remove the two (2) screws that secure the Cable Cover to the Back Cover. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions. - Page 7 Loosen the thumbscrew of the 180-degree USB-C Cable then disconnect the Cable. b. Remove the Ethernet Cable from the Cable Management Hook then disconnect the Cable. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 8 4. Loosen the two (2) captive screws that secure the Back Cover to the Display. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 9 5. Rotate the Back Cover away from the Display and unhook the Back Cover Tabs. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
-
Page 10: Ncr Cx8 Pos
1. Remove the Top Cover. There are two types of Top Covers: Top Cover without Duct — Remove the four (4) screws securing the Top Cover to the chassis. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions. - Page 11 Top Cover with Duct a. Remove the four (4) screws securing the Top Cover to the chassis. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 12 (Socket 1). Memory can be expanded by installing a second module in the upper socket (Socket 2). 3. Press the Memory Module down until it latches in position. Ensure the latches are completely engaged. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 13 4. Reinstall the Top Cover. Top Cover without Duct – Install the Top Cover on the chassis using four (4) screws. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 14 Slide the Top Cover in the direction shown to align the screw holes of the Cover with the screw holes of the chassis. c. Secure the Top Cover with four (4) screws. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
