Summary of Contents for Crystal Image LCD-APX24
- Page 1 LCD display solutions User Manual 24” Ultra High Resolution LCD LCD-APX24 Aluminum front bezel LCD-NAPX24 Front NEMA4 / IP65 LCD-OPX24 Universal Mounting Open Frame Designed and manufactured by Austin Hughes UM-UV-X24-Q112V1 www.austin-hughes.com...
- Page 2 Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
-
Page 3: Table Of Contents
Contents < Part. 1 > LCD-APX24 / NAPX24 Package Content Structure Diagram & Dimension P.2 - 3 Mounting Hardware & Installation P.4 - 5 LCD-OPX24 < Part. 2 > Package Content Structure Diagram & Dimension P.7 - 8 Mounting Hardware & Installation <... - Page 4 Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.
- Page 5 < Part 1 > < 1.1 > Package Content - LCD-APX24/NAPX24 24” High Res LCD Display 24” Ultra High Res LCD display X 1 LCD-APX24/NAPX24 6ft VGA cable X 1 6ft DVI-D cable X 1 6ft HDMI cable X 1...
- Page 6 < 1.2 > Structure Diagram - LCD-APX24/NAPX24 Front view AP-X24 NAP-X24 Rear view Rear case LCD panel Protective 3mm glass 6mm aluminum front bazel Audio speaker, pair LCD membrane Remote sensor Audio Audio Power HDMI DVI-D S-Video R C A...
- Page 7 < 1.2 > Dimension - LCD-APX24/NAPX24 24” Ultra High Res LCD Display Front View Side View AP-X24 NAP-X24 Rear View UNIT : mm 1mm = 0.03937 inch Bottom View UM-UV-X24-Q112V1 www.austin-hughes.com...
- Page 8 < 1.3 > Panel Mount Installation - LCD-APX24/NAPX24 M4*50mm screw M4*6mm screw Mounting bracket x 8 pcs x 8 pcs x 4 pcs Hardware set part no. UV-BK#2 Steps ■ Install 4 mounting brackets with 8 x M4*6mm screws ■...
- Page 9 < 1.3 > VESA mount Installation - LCDAP-X24/NAPX24 24” High Res LCD Display M4 screw VESA mount ( 100*100mm ) ■ Hardware and M4*4 pcs for VESA mount are not provided UM-UV-X24-Q112V1 www.austin-hughes.com...
-
Page 10: Package Content
< Part 2 > < 2.1 > Package Content - LCD-OPX24 24” Ultra High Res LCD display X 1 LCD-OPX24 6ft VGA cable X 1 6ft DVI-D cable X 1 6ft HDMI cable X 1 6ft RCA cable X 1 6ft S-Video cable X 1 Power cord X 1 Remote controller X 1... - Page 11 < 2.2 > Structure Diagram - LCD-OPX24 24” Ultra High Res LCD Display Front view OP-X24 Rear view Rear case LCD panel Audio speaker, pair Universal open frame mounting LCD membrane Extended remote sensor membrane cable ( 66cm from AD board to sensor end ) Audio Audio Power...
- Page 12 < 2.2 > Dimension - LCD-OPX24 Front View Side View OP-X24 Rear View UNIT : mm 1mm = 0.03937 inch Bottom View UM-UV-X24-Q112V1 www.austin-hughes.com...
- Page 13 < 2.3 > Installation - LCD-OPX24 24” Ultra High Res LCD Display ( I ) Universal mount ( II ) VESA mount ( 100*100mm ) M4 screw Hardware and M4*4 pcs for VESA mounting are not provided UM-UV-X24-Q112V1 www.austin-hughes.com...
-
Page 14: Product Specifi Cations
< Part 3 > < 3.1 > Product Specifi cations LCDAP/NAPX24 LCD-OPX24 Mechanical Design Front Panel Black, RAL 9005 Rear Casing Dark grey, RAL 7037 Dark grey, RAL 7037 VESA Mounting 100 x 100mm 100 x 100mm Other Mounting Panel mount Universal mount Protection 3mm protective glass... - Page 15 24” Ultra High Res LCD Display Regulatory Safety Approval FCC & CE Environmental Operating Temperature 0 to 50°C degree Conditions Humidity 20~90%, non-condensing Storage Temperature -5 to 60°C degree Humidity 5~90%, non-condensing Shock 10G acceleration (11ms duration) Vibration 5~500Hz 1G RMS random LCDAP/NAPX24 LCD-OPX24 Physical...
-
Page 16: On-Screen Display Operation ( Osd )
< 3.2 > On-screen Display Operation ( OSD ) Power light Green = On Orange = Power saving Membrane Switch Function Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control (To auto adjustment by pressing the button for 5 seconds) Exit the OSD screen Toggle analog, digital &... - Page 17 < 3.2 > On-screen Display Operation ( OSD ) 24” Ultra High Res LCD Display Audio Audio mode : Movie / Voice / Normal / Music mode to choose Volume : Adjust the volume of sound Bass : Set the value of bass sound Treble : Set the value of treble sound Balance :...
-
Page 18: Remote Controller ( Rc-2 )
< 3.3 > Remote Controller ( RC-2 ) INPUT MUTE -/-- AUTO FREEZE MENU SELECT ASPECT SLEEP ENTER BACK EXIT SWAP SOURCE POSITION AUDIO INPUT Select the source Switches on or off the TV Only use in TV mode. Select channels. For channel numbers 10 0 - 9 and above, enter the second digit within two seconds. -
Page 19: < 4.1 > Option Table
< Part 4 > Options 24” Ultra High Res LCD Display < 4.1 > Option Table Basic Options AP / NAP SDI *** Touchscreen MCS multi-display control *** MIL-type / lockable connector The user can only select either SDI or MCS inputs. P.15 UM-UV-X24-Q112V1 www.austin-hughes.com... - Page 20 CCTV market. Designed for use with CIT's Full HD 1080p and ultra high resolution 1920 x 1200 LCD displays, Crystal Image provides a SDI input module without using additional space or power and it comes standard with a 2-year warranty.
- Page 21 24” Ultra High Res LCD Display More control is always good. Especially when it is necessary and easy. Crystal Image provides MCS solution to control the OSD of ( Multi-display Control ) various Crystal Image LCD display up to 64 units.
- Page 22 24” High Resolution LCD Display More control is always good. Especially when it is necessary and easy. Crystal Image provides MCS solution to control the OSD of ( Multi-display Control ) various Crystal Image LCD display up to 64 units.
- Page 23 < 4.4 > Options : Touchscreen & driver 24” Ultra High Res LCD Display X24" USB Touchscreen Specifi cation Model TMR2 e-Resistive Multi-touch Technology 5-Wire Resistive Infrared Touch Point Single Dual Method Stylus or Finger Finger or Gloved Hand Activation Force ≤...
- Page 24 < 4.5 > Options : MIL-type or Lockable Connector 24” Ultra High Res LCD Display Input Part no. MIL Standard MIL - type MS3470W8-33P MIL - DTL - 26482 DC Power Connector ( Male ) MS3470W14-15P MIL - DTL - 26482 ( Male ) There are several additional MIL DC and VGA connector types with varying design characteristics to meet cost considerations and to provide users with the most...
- Page 25 < 4.6 > Options : TV ( Analog ) Power HDMI DVI-D Audio S-Video R C A Audio For RC-2 remote controller specifi cations, please refer to P.14...
