Uniflame S-1028 Assembly Instructions

Hardware/Parts
Screen
1
Handle (2)
2
Bottom Foot (2)
3
Side Foot (2)
4
Screw
A
Nut
B
Tools Required for Assembly
Phillips Head Screw Driver and Adjustable
Wrench.
2
4
Manufactured in India for Mr. Bar-B-Q Products LLC
Hauppauge, NY 11788 USA • 1.800.398.8643 • MRBarBQProducts.com
Contact (866) 758-3900 for assistance.
Assembly Instructions
Model No. S-1028, S-1075, S-1127
Steps
Step 1
60-S1028-SN
Attach bottom foot to screen.
60-S1028-HD
60-S1028-BKF Step 2
60-S1028-FLG Attach side foot to screen.
Step 3
10 pcs
Attach handles to screen.
8 pcs
CAUTION: Keep this product clean by using a damp cloth.
·
DO NOT use abrasive cleaners, as it will cause parts to
tarnish.
(Not Included)
1
3
Do not return to place of purchase.
2
4
B
3
A
4
B
A
2
B
S-1028_s-OM-101 EF
