- Page 1 USER MANUAL PowerDrive Optimizer Plus © 2021 - Godrej & Boyce Manufacturing Co. Ltd. ALL RIGHTS RESERVED...
- Page 2 Vikhroli (W), Mumbai- 79 Maharashtra. INDIA The information in manual is confidential and may not be disclosed to any third party without prior written consent of Godrej & Boyce Manufacturing Co. Ltd. First Edition 2021 Printed in INDIA Dear User, PowerDrive has been carefully conceptualized and designed keeping in mind your storage space, Ease of operation and Safety.
- Page 3 Godrej & Boyce Manufacturing Co. Ltd. Reserves the rights to make any changes without any notice in design, specifications, and models. To order additional copies of this manual, refer the contact information mentioned on the last page or contact your distributor.
-
Page 4: Table Of Contents
Table of Contents 1.1 Intended to Use 1.2 Safety 1.3 Item description 2.0 Operation 2.1 Start up 2.2 Basic Operation 2.2.1 Menu options LCD touchscreen (Dynamic Pro) 8 2.3 Access control 18 2.3.1 Floor lock with key lock (Euro lock 3) 3.0 Problems and error messages 19 4.0 Maintenance 28 4.1 Cleaning... -
Page 5: Intended To Use
PowerDrive should only be operated by authorized persons who have been instructed and understood operation and safety regulations. Not to be used above 2000m Altitude. Installation to be done only by authorized Godrej Interio representative. Pl contact Godrej Service Toll free contact number 1800 209 5511 or on interiocare@godrej.com. - Page 6 For proper movement of units, make sure rails are cleaned regularly. Don’t use the PowerDrive if any of the rail is damaged, Log complain to Godrej service on interiocare@godrej.com Don’t use the PowerDrive if any part is damaged, Log complain to Godrej service on interiocare@godrej.com...
-
Page 7: Item Description
Item Description PowerDrive Plus is smart tech-enabled mobile storage unit. It is carefully conceptualized and designed keeping in mind your storage space, Ease of operation and Safety. Each unit comes with individual touch control panel for operation of same unit. The product has an operating system that makes it simple to use. -
Page 8: Operation
7. Specialized Platform 8. IR sensor 9. Distance sensor 10. Central lock 11. Floor sensor – mounted underside of last moving unit 12. Mechanical lock Operation: Touch control panel is installed on front of unit and designed to operate product smoothly. Kindly read manual thoroughly to understand operation. - Page 9 6. ERROR/WARNING indicator: When an obstacle is detected during operation, it will turn 7. LOCK state indicator: When operation from the touch panel is not permitted due to some other person's use of the unit, the Lock will blink. Operating Instructions: 1.0 Power ON the PowerDrive: ...
- Page 10 1.4 Emergency stop safety feature: 1.4.1 Software and Hardware Reset mode – If units start moving while other user is in aisle, user should firmly push unit by feet or hand to stop movement. System will detect obstruction and will enter into reset mode;...
- Page 11 Troubleshooting Problem Cause Solution All touch panels are dead 1. mains switch is 1. Check mains (Blue LED (in fig A “1”) is not glowing on switch, turn it ON. touch panel) 2. Use different 2. no power even supply point after switch is ON 3.
- Page 12 2. Log a service call to not calibrated. calibrate the distance sensor In-case of above solution doesn’t help, please contact to Godrej service on Toll free contact number 1800 209 5511 or on interiocare@godrej.com Maintenance The system features need to be checked by qualified personnel once a year as pre-cautionary measure.
-
Page 13: Cleaning
Cleaning: It is recommended to clean the system with moist cloth to remove dust. Do not use abrasives, alcohol, or solvent-based cleaners as they may damage the surface. Do not use harsh scrubbing tools like steel wool, etc. Clean PowerDrive unit / electrical components only when system is powered off. Keep it dry all time. - Page 14 Indicate High Voltage Indicates Indoor Use Only Product complies with the European standards (IEC 60335-2-116:2019, IEC 60335-1:2010 & IEC 61000 series). Ignoring the warning can result in user injury and lead to equipment damage. Product Information Sticker:...
- Page 15 This sticker gives you all the information about the product such as weight, safe working load and the electrical norms it is complying for. It also specifies the date manufacture, product unique code and address for communication in case of emergency assistance. Caution Sticker:...
- Page 16 Technical Specifications:...
- Page 17 +5° to +50° temperature MODIFICATION OF PRODUCT COMPONENTS In the event of improvement / upgrade of our product / its components, contact to Godrej service on Toll free contact number 1800 209 5511 or on interiocare@godrej.com FOR OUR DISPOSAL POLICY, Please check our website www.godrejinterio.com,...
