Operating Instructions
Pneumatic Seed Drills
Solitair 9 KA
and
Solitair 9 SA
Safety is our concern!
ÃÃÃÃÃÃÃÃÃÃ
Part No. 175 1358
GB-4/03.01
LEMKEN GmbH & Co. KG
Weseler Straße 5, D-46519 Alpen / Postfach 11 60, D-46515 Alpen
Telefon (0 28 02) 81-0, Telefax (0 28 02) 81-220
e-mail: lemken@lemken.com, Internet: http://www.lemken.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Solitair 9 KA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LEMKEN Solitair 9 KA

Summary of Contents for LEMKEN Solitair 9 KA

  • Page 1 Safety is our concern! ÃÃÃÃÃÃÃÃÃÃ Part No. 175 1358 GB-4/03.01 LEMKEN GmbH & Co. KG Weseler Straße 5, D-46519 Alpen / Postfach 11 60, D-46515 Alpen Telefon (0 28 02) 81-0, Telefax (0 28 02) 81-220 e-mail: lemken@lemken.com, Internet: http://www.lemken.com...
  • Page 3 Only use genuine Lemken spare-parts. Spurious parts negatively influence the function of the implement, show a shorter lifetime and increase in nearly all cases additional maintenance. We trust that you will understand that LEMKEN is unable to guarantee poor operation and damage caused by using spurious parts!

  • Page 4: Table Of Contents

    Under „defined use“ the manufacturer’s prescribed operation-, maintenance- and repair conditions are to be adhered to! • The LEMKEN Solitair may only be operated, maintained and repaired by such persons who have been made acquainted with it and who have been advised about the dangers! •...
  • Page 5 6.3.2 Detaching from the three point linkage.......... 17 7 REAR GROUND WHEEL ................18 8 FAN ......................18 9 DUST FILTER ..................... 18 10 ADJUSTMENTS..................19 10.1 Drilling depth..................19 10.2 Coulter pressure ................... 19 10.2.1Single coulter pressure adjustment ..........19 10.2.2Central coulter pressure adjustment ..........
  • Page 6 19 ON-BOARD COMPUTER LH 5000 ............37 20 FUSES AND SENSORS ................38 21 TRANSPORT ..................... 39 22 TYRES ....................... 39 23 NOTES ....................... 40 24 NOISE, AIRBORNE SOUND..............40 25 PRODUCT REGISTRATION / GUARANTEE..........40 26 TECHNICAL DATA ..................40 27 MAINTENANCE ..................

  • Page 7: Safety Instructions

    1 SAFETY INSTRUCTIONS General Safety Instructions • Before using the machine, always check both it and the tractor for roadworthiness and operational safety! • As well as the notes in these instructions the operator is advised to comply with the generally applicable safety at work regulations and those relating to use of the public highway! •...
  • Page 8 • Do not operate any hydraulic controls while anybody is in the operating area! • On all pivoting parts actuated by power assistance (e.g. hydraulics) exists danger of injury by bruising and crushing! • Before leaving the tractor lower the machine to the ground. Apply the parking brake, stop the engine and remove the ignition key! •...
  • Page 9 • Regularly check the hydraulic pipes and replace them in the event of damage or signs of ageing. The replacement pipes must comply with the technical specification as laid down by Lemken! • When searching for leaks appropriate equipment should be used because of the danger of injury! •...
  • Page 10 • Any spare parts fitted must meet with the implement manufacturer’s strict technical standards! This is for example ensured by using genuine spare parts! Seed drills • During calibration test watch out for rotating or oscillating parts of the implement! •...

  • Page 11: Warning Stickers

    2 WARNING STICKERS 2.1 General Instructions The LEMKEN Solitair is equipped with all features ensuring safe operation. There, where danger spots of the implement could not be safeguarded sufficiently, warning stickers are fitted which point to the remaining danger spots. Damaged, lost or unreadable warning stickers must be replaced immediately.

  • Page 12: Table Of Variants

    3 TABLE OF VARIANTS Distance of seeding rows: 125 mm 150 mm 175 mm Harrows: S-harrow Tramline width: 2 x 1 rows 2 x 2 rows 2 x 3 rows 2 x 4 rows Track width: Centre – Centre = 1800 mm Centre –...

  • Page 13: Preparation Of The Tractor

    4 PREPARATION OF THE TRACTOR 4.1 Hydraulic asssembly The Solitair 9 KA and Solitair 9 SA are designed for the use in combination with LEMKEN semi-mounted soil cultivation implements Zirkon, Terradisc, Terratilth and Quarz. These soil cultivation implements are equipped with a connection bracket (25) with marked hose connections, to which the hydraulic hoses of the Solitair must be connected.

  • Page 14: Electrical Assembly

    4.2 Electrical assembly For the on-board computer LH 5000, the seed wheel drive and the seed drill control an electric power of approximately 300 Watts with a supply voltage of 12 V is required. The on-board computer is connected directly to the battery of the tractor.

  • Page 15: Preparation Of The Solitair - Check List

    5 PREPARATION OF THE SOLITAIR – CHECK LIST Before first using the Solitair the following items must be checked. • Disc Coulters and pressure rollers The links (LO) and (LU) of the disc coulters should be positioned nearly horizontally in the working position.
  • Page 16 All other adjustments and warning functions can be used if required, see instruction book of the on-board computer LH 5000 from version Lemken 52.03 and higher. Solitair seed drills with electric motor fitted in front are equipped with the on-board...

  • Page 17: Possibilities Of Use

    6 POSSIBILITIES OF USE The Lemken Solitair 9 KA and Solitair 9 SA seed drills can be mounted directly to the semi-mounted implements Zirkon, Smaragd, Kompaktor and Quarz, if these implements are equipped with a braking system. In connection with a trailer, these seed drills can also be fitted to the three-point linkage of a tractor or a soil cultivation implement.

  • Page 18: Uncoupling

    Therefore the pivots (14) will be locked by the pins (13). After that secure with pins (13) (with Solitair 9 KA, only). − Ensure that the left and right hand upper pins (21) and stops (22) are adjusted equally and secure.

  • Page 19: Attachment And Detachment

    − Connect hydraulic hose of the Track markers to a single acting spool valve. − Connect the hydraulic hoses of the folding coulter bar to a double acting spool valve (with Solitair 9 KA, only). − Finally connect the electric cable of the seed drill control and seed shaft electric drive to the on-board computer.

  • Page 20: Rear Ground Wheel

    7 REAR GROUND WHEEL The rear drive wheel (18) must be swung- down before operation in the field, the impulse signals will be transmitted to the on-board computer LH 5000. See also the instruction book of the on-board computer LH 5000. By means of the stop bolts (AS) the drive wheel must be adjusted so that it will not be 5 cm deeper than the pressure rollers, with...

  • Page 21: Adjustments

    10 ADJUSTMENTS 10.1 Drilling depth With the two screws (20) the seeding depth is adjusted. It is important that both screws (20) are adjusted the same amount, in order to reach an even seeding depth. The scale (SK) serves as a guide to the current seeding depth.

  • Page 22: Coulter Frame Hydraulic Lift

    If after the central coulter pressure adjustment the working position is too deep or too shallow, the link position must be corrected by means of each spring adjustment (24). Links are too deep in driving direction Õ Lengthen spring adjustment (24). Links are too shallow in driving direction Õ...

  • Page 23: Seeding Shaft

    10.5 Seeding shaft The seeding shaft (SW) is equipped with 7 seed wheels for each dosage unit (34), with two fine seed wheels (FS), two narrow seed wheels (SS) and three wide seed wheels (BS). Between each seed wheel a separation plate (not shown) is provided. They ensure that each seed wheel works independently from each other.
  • Page 24 a) Switching on the seed wheels Switching on the seed wheels is done by means of screwing in the stop screw (MS). When screwing in the stop screws (MS) it must be ensured that they engage exactly in the groove (NU) of the seeding shaft axle (SA). Also the screws are within the seed wheel circumference and will not cause interference when rotating.

  • Page 25: Seed Tables

    Seeding table For the seed drills Solitair 9/300 and 9/600 with electric motor fitted at the rear...
  • Page 26 Seeding table For the seed drills Solitair 9/400 with 4 distributors and electric motor fitted at the rear...
  • Page 27 Seeding table For the seed drills Solitair 9/450 with 4 distributors and electric motor fitted at the rear...
  • Page 28 Seeding table For the seed drills Solitair 9/500 K with 4 distributors and electric motor fitted at the rear...
  • Page 29 Seedtable for Solitair seed drills with electric motor fitted in front Arbeits- Saatgut breite Seed Working width Graine de Largeur semence k g / h a de travail 35 - 100 100 - 220 220 - 300 Getreide 40 - 110 110 - 240 240 - 300 Grain 45 - 120 120 - 260...

  • Page 30: Slide Plates

    10.7 Slide plates During operation all slide plates (A) must be opened fully. If necessary the seed flow from the hopper to the metering units can be stopped by means of the slide plates (A). As an option the slide plates can be operated via an electrical motor from the tractor seat if required.

  • Page 31: Emptying The Hopper

    10.9 Emptying the hopper 10.9.1 Emptying flaps The hopper (15) can be emptied easily by means of opening the emptying flaps (40). The handles of the flaps can be found - seen from the rear - to the right under each dosage unit (34).

  • Page 32: Cleaning The Dosage Units

    10.10 Cleaning the dosage units The dosage units (34) must be cleaned regularly, at least once a day with rape seed. Therefore the stop slides (A) must be closed, the calibration tray (41) set into position and the emptying flaps (40) opened. Remove protection covers (33) and open bottom flap shaft completely by means of the lever (HE) or (35).

  • Page 33: Tramline Mechanism

    10.13 Tramline mechanism By means of the tramline mechanism (FA) either 1x2, 2x2, 2x3 or 2x4 seeding rows will be closed, when tramlines are made. Via the on-board computer LH 5000 the rhythm and bout can be adjusted. See instruction book for the on-board computer LH 5000.

  • Page 34: Partly Width Switch Off

    11 PARTLY WIDTH SWITCH OFF Depending on the working width of the Solitair 1 to 4 dosage units can be switched off by means of closing the slides plates (A). This can be done by hand or by means of the electric motor (EM). With the electric width switch off device, electric motors are provided above the slide plates (A).

  • Page 35: Scrapers

    12 SCRAPERS The double disc coulters (55) are equipped with self-adjustable scrapers (54). They must be replaced after wear. After wear the scrapers must be replaced. Each scraper is secured by a supporting plate and a spring pin. The cover (56) prevents clods and soil penetrating the inner disc area.

  • Page 36: Sensors

    16 SENSORS controlling Solitair several sensors (71) are fitted. At the coulter bar lifting device (tramline switch), the fan, the drive wheel, the seeding shaft and the electric motor. The sensors have been adjusted at the factory. An adjustment correction must only be done, if with intact sensor a malfunction is found out.

  • Page 37: Folding- In And -Out Of The Coulter Bar

    17 FOLDING- IN AND -OUT OF THE COULTER BAR (with Solitair 9 KA, only) Hook (H) is unlocked Hook (H) is locked The seed drills Solitair 9 KA are equipped with hydraulically foldable coulter bars (12). Before folding-in, the locking pin (13) must be unsecured and removed.

  • Page 38: Track Markers

    18 TRACK MARKERS The Track markers (45) are folded-in and -out vertically by means of single acting hydraulic rams. The alternating action of the Track markers happens by means of an hydraulic switch valve. The Track markers are adjusted to the centre of the tractor at the factory.

  • Page 39: On-Board Computer Lh 5000

    19 ON-BOARD COMPUTER LH 5000 All adjustments of the seed drill monitoring are adjusted, regulated and controlled by the on-board computer. Warning! If the tractor with seed drill Solitair is parked, the on-board computer must be switched off, in order to avoid discharge of the battery.

  • Page 40: Fuses And Sensors

    20 FUSES AND SENSORS The on-board computer LH 5000 and the controlling of the Solitair are protected against damage by fuses and sensors. a) Up to fabrication No. 263 121 (collecting box made out of synthetic) Two different circuit boards (P) are fitted in the grey box. The circuit board (P) for the electric motor of the pre-emergence markers shows 3 additional fuses.

  • Page 41: Transport

    21 TRANSPORT Before transport the coulter bar of the Solitair 9 KA must be folded-in. The Solitair 9/400 SA is wider than 3 m and therefore may not be driven on public roads. The transport height and width regulations must be adhered to. The regulations and laws concerned must be abided by.

  • Page 42: Notes

    24 NOISE, AIRBORNE SOUND The noise level of the LEMKEN Solitair 9 KA is between 90 and 95 dBA during work. Close the tractor cabin or use ear defenders during work. 25 PRODUCT REGISTRATION / GUARANTEE We would like to point out that the guarantee period starts, only when the completely filled-in and signed product registration has been returned to us .

  • Page 43: Maintenance

    20 working hours and tightened if necessary. ∗ Worn double disc coulters and scrapers must be replaced in time, so that the carrying parts will not be damaged. Use only genuine Lemken spare parts! ∗ Hydraulic hoses must be checked regularly. Defective and porous hydraulic hoses must be replaced immediately.
  • Page 44 • The filter (ZY) separates the dust from the in taken air by 85 % automatically. The function of the filter (ZY) must be checked regularly as follows: - Throw dust into the intake opening of the filter (ZY). - When the T-joint (TV) does not throw out dust, the flexible hose (FL) must be removed from the filter and the filter must be cleaned.
