- Page 1 WB110 WWW.FANVIL.COM.CN Wall Mount Bracket Quick Installation Guide...
- Page 2 Applicable model Model Size X305 WB110 156.93 x 124.82 x 38.9(mm) 3. Installation Diagram Place the bracket in the position to be installed and mark the position of the screw hole; After removing the bracket, use an electric drill to drill the 2 holes at the marked.
- Page 3 Pull the hookswitch tab in the handset cradle and rotate the hookswitch tab 180 degrees,then reinsert the hookswitch tab, as shown below: Finally, mount the IP phone to the wall, as shown below:...
