Summary of Contents for Fanvil WB107
- Page 1 WB107 www.fanvil.com Wall Mount Bracket Quick Installation Guide...
- Page 2 1. Package Contents WB107 www.fanvil.com Wall Mount Bracket Quick Installation Guide Wall Mount Bracket Quick Installation Guide Screw 2. Physical specification Model Size Applicable models V series IP Phone WB107 162.55 x 121.83 x 41.7(mm) 3. Installation Diagram 1) Place the bracket in the position to be installed and mark the position of the screw hole;...
- Page 3 3) Push or hammer screw anchors into the drilled holes, then insert 2 screws, as shown below： 4) Insert the tabs on the wall mount bracket into the slots on the back of IP phone. And then slide the wall mount bracket to right, as shown below: 5) Pull the hookswitch tab in the handset cradle and rotate the hookswitch tab 180 degrees, then reinsert the hookswitch tab, as shown below: 6) Finally, mount the IP phone to the wall, as shown below:...
