Enterasys XSR 1800 Series Installation Manual

The standard XSR 1800 Series Dual In-line Memory Module (DIMM) of 32 or 64 MB (XSR-1805/1850) can easily be
upgraded to 64 or 128 MB simply by disassembling the chassis, removing the existing DIMM, and installing the
new DIMM. Refer to the XSR-1850 instructions below or the XSR-1805 instructions on
Electrical Hazard: Only qualified personnel should perform installation procedures.
Riesgo Electrico: Solamente personal calificado debe realizar procedimientos de instalacion.
Elektrischer Gefahrenhinweis: Installationen sollten nur durch ausgebildetes und qualifiziertes Personal
vorgenommen werden.
Before You Begin
To complete this installation, you need only a Phillips-head screwdriver and an antistatic wrist strap.
Caution: To prevent component damage from electrostatic discharge, use an antistatic wrist strap, and observe all
electrostatic precautions during this procedure. Failure to do so could damage the DIMM, the XSR, or both.
XSR-1850 DIMM Upgrade Instructions
To upgrade the XSR-1850, follow the procedure described below:
1. Attach an antistatic wrist strap to your wrist.
2. Unplug the XSR-1850.
Electrical Hazard: Because you are removing the chassis cover and exposing electrical connections, the device
must be disconnected from its power source to prevent electric shock.
Riesgo Electrico: Ya que se esta removiendo la cubierta del chassis y se esta expuesto a conexiones electricas, el
dispositivo debe estar desconectado de la electricidad para prevenir un choque electrico.
Elektrischer Gefahrenhinweis: Da die Chassis-Abdeckung entfernt wird und somit die elektrischen Verbindungen
freiliegen, muss das Gerät von der Stromzufuhr getrennt sein, um den Schutz vor Stromschlägen zu gewährleisten.
PN 9033829-02
XSR 1800 Series DIMM Upgrade
Installation Guide
page 3.
Page 1 of 6
