- Page 1 INSTALLATION AND OPERATION USER MANUAL WWW.UNICORE.COM UM220-INS Multi-GNSS Integrated Navigation and Positioning Module Copyright© 2009-2024, Unicore Communications, Inc. Data subject to change without notice.
- Page 2 Unicore holds the trademarks of “和芯星通”, “Unicore” and other trade name, trademark, icon, logo, brand name and/or service mark of Unicore products or their product serial referred to in this manual (collectively “Unicore Trademarks”).
- Page 3 Information, such as product specifications, descriptions, features and user guide in this manual, are subject to change by Unicore at any time without prior notice, which may not be completely consistent with such information of the specific product you purchase.
-
Page 4: Table Of Contents
Contents Contents ......................I Overview ....................1 Scope ........................1 Audience ......................1 Introduction ....................1 Product Description .................... 1 Key Features ....................... 2 Interfaces ......................4 System Installation ................... 6 Prerequisites ....................... 6 System Installation ..................... 7 Technical Specifications ................8 Electrical Specifications .................. - Page 5 UM220-INS Series Modules User Manual Product Labeling ....................22 Package Description ..................22 Clean....................... 23 Reflow Soldering ..................24...
-
Page 6: Overview
UM220-INS series products can output GNSS+MEMS integrated positioning results continuously even in tunnels and underground garages. The GNSS chip in the UM220-INS module is qualified according to AEC-Q100, and the production process complies with IATF 16949. Figure 2-1 UM220-INS Series Modules (left side: UM220-INS NL, right side: UM220-INS UC-00-M10 EN R1.9... -
Page 7: Key Features
UM220-INS NF ● ● ● ● ● ● ● ● UM220-INS series modules support multiple positioning modes including joint positioning and standalone positioning: GPS L1+SBAS+QZSS GPS+GLONASS+Galileo+SBAS+QZSS GPS+BDS+Galileo+SBAS+QZSS (default mode) ※ QZSS and SBAS are only available when GPS is enabled. - Page 8 Environment Operating Temperature -40° C ~ +85° C Storage Temperature -45° C ~ +90° C Input/ Output Data Interface UART*2, LVTTL. UART Baud Rate: 4800~460800bps GNSS Performance BDS B1: 1561.098MHz GPS L1: 1575.42MHz Frequency GLONASS L1: 1602+0.5625*k (MHz) Galileo E1: 1575.42MHz GPS+GLO+GA GPS+BD+GA TTFF...
-
Page 9: Interfaces
Figure 2-2 UM220-INS Series Modules Block Diagram UART UM220-INS series modules support two configurable UART ports. COM1 is the main serial port, which supports data transfer and firmware upgrade, the signal input/output is LVTTL. The default baud rate varies according to the version of firmware, and the... - Page 10 MEMS UM220-INS series modules integrate a six-axis MEMS, including a three-axis gyro and a three-axis accelerator on board. MEMS provides information on the carrier’s attitude and speed changes, which are combined with GNSS to perform an integrated navigation calculation.
-
Page 11: System Installation
Figure 3-1 shows the typical installation of UM220-INS series modules with Evaluation Kit. Antenna Figure 3-1 Typical Installation of UM220-INS Series Modules Please check the contents of the package carefully after receiving the UM220-INS series modules. UM220-INS EVK suite (with AC Adapter) UM220-INS Series Module User Manual ... -
Page 12: System Installation
Step 3: Use the GNSS antenna with appropriate gain and fix it in the non-blocking area; use the appropriate cable to connect the antenna to UM220-INS EVK. Step 4: Connect the PC to the EVK serial port through the serial cable or USB cable. -
Page 13: Technical Specifications
UM220-INS Series Modules User Manual 4 Technical Specifications 4.1 Electrical Specifications Absolute Maximum Ratings Item Unit Description Power Supply (VCC) -0.5 Main power Backup Voltage (V_BCKP) -0.5 Backup power supply for RTC Voltage of the digital signal Digital IO (RXD1, RXD2) -0.5... -
Page 14: Dimensions
4.3 Dimensions Symbol Min (mm) Typical (mm) Max (mm) 15.9 16.0 16.5 12.2 12.4 Figure 4-1 Mechanical Layout UC-00-M10 EN R1.9 Technical Specifications... -
Page 15: Pin Definition (Top View)
UM220-INS Series Modules User Manual 4.4 Pin Definition (Top View) Figure 4-2 Pin Assignment Name Electrical Level Description Reset nRESET LVTTL Low active, leave it floating if not in use Reserved TIMEPULSE LVTTL Time pulse (1PPS) Odometer speed pulse, leave it floating if not in use. -
Page 16: Pcb Packaging
Ground 4.5 PCB Packaging Figure 4-3 UM220-INS Series Modules Recommended PCB Packaging（unit: mil, in brackets: mm） In the design of PCB solder, make sure the area below the UM220-INS series modules are fully covered with solder layer. UC-00-M10 EN R1.9... -
Page 17: Hardware Design
UM220-INS Series Modules User Manual 5 Hardware Design 5.1 Design in Considerations It’s required to connect the following signals correctly to make UM220-INS series modules work properly. When the module is not powered on, it is necessary to ensure that the power supply and all GPIOs are in a high impedance state or a low level to avoid abnormal operation of the module caused by power leakage. -
Page 18: Power Supply Requirements
5.2 Power Supply Requirements 5.2.1 Main Supply (VCC) The voltage range of VCC is 3.0 V ~ 3.6 V. Notes: The VCC initial level when power-on should be less than 0.4 V. The VCC ramp when power-on should be monotonic, without plateaus. The voltages of undershoot and ringing should be within 5% VCC. -
Page 19: Antenna
Figure 5-2 UM220-INS Passive Antenna Solution 5.4 Reset If the reset pin nRESET of the UM220-INS module needs to be used, the following timing requirements must be met between the nRESET and the power supply VCC. During normal operation of the module, pulling down the nRESET pin over 5 ms can also reset the module. -
Page 20: Serial Port
5.5 Serial Port The serial ports of UM220-INS series modules are of LVTTL level; use a RS232 converter for the PC connection. Figure 5-4 Connect COM to PC 5.6 Odometer Connection UM220-INS series modules support direction (FWD) and velocity pulse (WHEELTICK) signals connecting with odometer. -
Page 21: System Coordinates
UM220-INS Series Modules User Manual 5.7 System Coordinates The coordinate system of UM220-INS series modules must be consistent with that of the vehicle, otherwise you must perform the related configuration following the CFGROTAT command in the corresponding protocol manual. Figure 5-6 Module Coordinate System Figure 5-7 Car Coordinate System 1. -
Page 22: Installation Of The Module
5.8 Installation of the Module UM220-INS series modules must be rigidly connected to the vehicle body and firmly fixed. 1. The antenna should be installed with the front facing up as much as possible and firmly fixed; ensure that the elevation angle of the environment where the antenna is located is greater than 15° and the space is unobstructed. -
Page 23: Installation Options Of The Module
Free Installation (Default Mode) UM220-INS series modules integrate a three-axis gyroscope and a three-axis accelerometer, with a built-in self-calibration algorithm, which supports the free installation of the module with respect to any installation angle of the vehicle coordinate system, such as, the completely horizontal installation, inclined installation at a certain angle, and flip installation. -
Page 24: Reference Messages
5.8.4 Reference Messages 1. CFGROTAT Message format: $ CFGROTAT,angleX,angleY,angleZ,mode Description: Set or output the installation angle of the module with respect to the vehicle coordinate system. Parameters: ◆ angleX, angleY and angleZ are defined in section 5.8.2, with the unit of 0.01° ◆... - Page 25 UM220-INS Series Modules User Manual 2: The installation angle is known 3: Initialization is completed ◆ odostatus: Odometer initialization status -1: Odometer device failure 0: Disabled 1: Initialize the scale factor 2: The scale factor initialization is completed 3: The scale factor calibration is completed ◆...
-
Page 26: Module Calibration And Notes
5.8.5 Module Calibration and Notes Self-Calibration After the installation of the UM220-INS series modules, the self-calibration is required to ensure the accuracy of the module output. In the process of the self-calibration, the module estimates installation status parameters and sensor parameters. The module is in GNSS navigation mode before the self-calibration is completed, and is in GNSS + INS integrated navigation mode after the self-calibration is completed. -
Page 27: Disassembly
Product QR Code 7.2 Package Description The UM220-INS series modules use carrier tape and reel (suitable for mainstream surface mount devices), packaged in vacuum-sealed aluminum foil antistatic bags, with a desiccant inside to prevent moisture. When using reflow soldering process to solder modules, please strictly comply with IPC standard to conduct humidity control on the modules. -
Page 28: Clean
Thickness: 2.0mm Carrier Tape Space between: 20mm UM220-INS series modules are rated at MSL level 3, refer to the relevant IPC/JEDEC standards for baking requirements. Please access to the website www.jedec.org to see the details. The shelf life of UM220-INS series modules is one year. -
Page 29: Reflow Soldering
UM220-INS Series Modules User Manual 9 Reflow Soldering In order to avoid device falling off, the module should be placed on the top of the main board during soldering. Reflow soldering temperature curve is recommended as shown in Figure 9-1 below (M705-GRN360 is recommended for solder paste). - Page 30 和芯星通科技（北京）有限公司 Unicore Communications, Inc. 北京市海淀区丰贤东路 7 号北斗星通大厦三层 F3, No.7, Fengxian East Road, Haidian, Beijing, P.R.China, 100094 www.unicore.com Phone: 86-10-69939800 Fax: 86-10-69939888 info@unicorecomm.com www.unicore.com...
