NOCX3
Monocular
OWNERS MANUAL
CAUTION: Do not point Infrared Emitter directly into eye at close range.
Keep out of reach of children.
The infrared emitter emits a BRIGHT, although invisible, beam of light.
As with any bright light, do not point into the eye.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NOCX3 and is the answer not in the manual?

Questions and answers

Related Manuals for Night Owl NOCX3

Summary of Contents for Night Owl NOCX3

  • Page 1 NOCX3 Monocular OWNERS MANUAL CAUTION: Do not point Infrared Emitter directly into eye at close range. Keep out of reach of children. The infrared emitter emits a BRIGHT, although invisible, beam of light. As with any bright light, do not point into the eye.

  • Page 2: Quick Start

    Quick Start GET FAMILIAR WITH THE DEVICE HOW TO FOCUS YOUR NIGHT VISION DEVICE In a LIGHTED environment: Step 1 Install Batteries. Step 2 DO NOT REMOVE the LENS C P. The pinhole in the lens cap lets through a small amount of light. Removing lens cap in daylight could damage the unit.

  • Page 3: Image Quality

    In a DARK environment: Step 6 In the dark, remove LENS C P. Step 7 Do NOT rotate EYEPIECE. Rotate OBJECTIVE LENS until objects come into focus. You have already adjusted the EYEPIECE to your individual eyesight. Rotate the OBJECTIVE LENS to focus on objects at varying distances. Step 8 Click on the INFR RED button.

  • Page 4: Frequently Sked Questions

    Frequently sked Questions Why are the projected images always green using Night Vision technology? Night Vision phosphor screen is purposefully engineered because the human eye can differ- entiate more shades of green than other colors. Why do you focus both the front (Objective lens) and Eyepiece (Ocular)? You do not see through the Night Vision device, like a day monocular.

  • Page 5: Troubleshooting

    Performance under Various Light Conditions Complete Darkness Your Night Vision device works by amplifying available natural light. In complete darkness, with no available natural light, you cannot see without the use of the Infrared Illuminator (IR). The IR works like a flashlight, but is invisible to human and animal eyes. Half-Moon half-moon provides a substantial amount of ambient light to be amplified by the internal Electronic Intensifier Tube.
  • Page 6 How Night Vision Works Light coming into the device from the direction of the object is gathered by the objective lens and focused onto the Image Intensifier Tube. The front of the Image Intensifier Tube contains a photocathode which converts light into electrons. The device contains a very high voltage power supply, which converts the 3 volts supplied by the batteries into 17 kilovolts.

  • Page 7: Product Specifications

    Product Specifications NOCX3 GENERATION MAGNIFICATION 3.1X RANGE OF VIEW 583 ft. 175 m POWER SUPPLY 3V Lith (123) WEIGHT 16 oz. 454 g DIMENSIONS 7.2x2.3 x3.2 in 183x58x81 m OBJECTIVE LENS FOCAL LENGTH 50 mm APERATURE 1:1.2 FOV@1000 YDS 628 ft.
  • Page 8 1465 Henry Brennan El Paso, Texas 79936 1-800-444-5994 www.nightowloptics.com MCX3 Rev.2 111814...
