- Page 1 AIOS-7.0 P a g e User Manual Model Name: WN9722OAX22-DM-MAIN (AIOS7.0) Brand Name：Arcadyan...
-
Page 2: Table Of Contents
AIOS-7.0 P a g e Table of Contents 1 SPECIFICATION ........................ 3 Basic Specification ............................. 3 2 DETAIL SPECIFICATION ....................4 Product Specification ............................7 2-1-1 WLAN0 Specification ..........................5 2-1-2 Bluetooth Specification ........................... 5 3 Normal setup ........................6... -
Page 3: Specification
AIOS-7.0 P a g e 1 SPECIFICATION 1-1 Basic Specification Item Contents Manufacture Arcadyan Product Name HEOS 7.0 Platform Module Model Name WN9722OAX22-DM-MAIN (AIOS7.0) Chip Vendor Model name Mediatek 2.4GHz MAC/BB/RF Mediatek 2.4GHz PA(Tx) Mediatek 2.4GHz LNA(Rx) Mediatek 2.4GHz BPF(Rx) -
Page 4: Detail Specification
HDMI PCIe Supply Voltage Power consumption 13.08W (maximum) Weight Under 78g Dimensions 95.6 x 75 x 1.2mm Design life time 5years at 25 degrees 2 Detail Specification Product Specification Items Contents Vendor Parts number Operation frequency 1.7GHz Type DDR3 Width 16bit Operation Freq... -
Page 5: Wlan0 Specification
Item Specification Remark Chip Interface SDIO Frequency 2400~2483.5MHz(FCC, CE, JP) 2471~2497MHz(JP) 5150~5250MHz(W52, U‐NII‐1, Band 1) 5250~5350MHz(W53, U‐NII‐2A, Band 2) 5470~5725MHz(W56, U‐NII‐2C, Band 3) 5725~5850MHz(W58, U‐NII‐3, Band 4) DFS support 6GHz band 5955~7125MHz Data Rate IEEE 802.11b: 11, 5.5, 2, 1Mbps IEEE 802.11a 54, 48, 36, 24, 18, 12, 9, 6Mbps IEEE 802.11n HT20 Up to 144Mbps IEEE 802.11n HT40 Up to 300Mbps IEEE 802.11ac VHT80 ... -
Page 6: Normal Setup
Normal Setup • (EUT 1G ETH RJ45 link PC，IP domain set to 192.168.50.xxx , use telnet and set IP to 92.168.50.100，input ”root” then press "enter" button. Fig. Windows CMD Fig. Login for telnet 192.168.50.100... - Page 7 Setup EUT to link AP: Prepare an AP device (with wi-fi 5G function)，set IP address to 192.168.0.102，and set SSID of 5G to “5G” / password : 12345678。 # telnet command: • python3 arc_wifi.py -s 5G -p 12345678 -I 192.168.0.102 #connect AP and EUT，set IP address of wlan0 to 192.168.0.102 •...
- Page 8 Fig. ping 192.168.0.101 from 192.168.0.102 FCC Statement Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 9 For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of other channels is not possible. This device is restricted for indoor use. Operation of transmitters in the 5.925-7.125 GHz band is prohibited for control of or Communications with unmanned aircraft systems.
- Page 10 This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
- Page 11 For indoor use only. Pour une utilisation en intérieur uniquement. Devices shall not be used for control of or communications with unmanned aircraft systems. Les appareils ne doivent pas être utilisés pour contrôler ou communiquer avec des systèmes d'aéronefs sans pilote. IC Radiation Exposure Statement: This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment.
- Page 12 or product packaging or product literature which shall be available with the end product or online. Devices shall not be used for control of or communications with unmanned aircraft systems. Les appareils ne doivent pas être utilisés pour contrôler ou communiquer avec des systèmes d'aéronefs sans pilote.
- Page 13 Arcadyan Germany Technology GmbH Koelner Strasse 10b, 65760 Eschborn, Germany Telec Statement 5GHz band (W52, W53): Indoor use only (except communicate to high power radio)
- Page 14 Gain (dBi) Antenna Set Ant. Port Brand Model Name Connector Type 2.4GHz 5GHz 6GHz Bluetooth Dipole I-PEX ARY196-0383-005-00 WIESON Antenna Dipole I-PEX ARY196-0383-006-00 WIESON Antenna Dipole I-PEX ARY196-0383-007-00 WIESON Antenna Dipole I-PEX ARY196-0383-008-00 WIESON Antenna Dipole I-PEX ARY196-0383-009-00 WIESON Antenna Dipole ...
- Page 15 用，並改善至無干擾時方得繼續使用。前述合法通信，指依電信管理法規定作業之無線電通信。低功率射頻器 材須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。 應避免影響附近雷達系統之操作。 本模組於取得認證後將依規定於模組本體標示審驗合格標籤, 並要求平台廠商於平台上標示 「本產品內含射頻 模組 CC XX xx LP yyy Z z。 ...
