- Page 1 User Manual User Manual WN7522C 1 802.11n Single band WLAN module V1.0 WN7522C 1...
-
Page 2: Table Of Contents
3.1 Operating System Supported __________________________________________ 6 3.2 Wireless Mode Supported ____________________________________________ 6 3.3 Security___________________________________________________________ 6 3.4 Configuration _______________________________________________________ Chapter 4 Appearance _____________________________________________________ 7 Chapter 5 Specifications ___________________________________________________ 8 Table 1: Modulation Scheme and Nominal Transmit Power _________________________ 14 WN7522C 1... -
Page 3: Revision History
User Manual Revision History Edition # Reason for revision Issue date Written by ♦ V 0.1 Initial Document May 25, 2009 Stephen Fan ♦ V1.0 June 8,2009 Stephen Fan New USB connector WN7522C 1... -
Page 4: Chapter 1 Introduction
Introduction 1. Introduction WN7522C 1 is a single band wireless 802.11n USB module for Blu-ray players and other multi-media devices. It enables multi-media devices to connect onto 802.11n WLAN network and attain data communication speeds up to 300 megabits-per-second (Mbps). It is also backward compatible to the existing installed base 802.11b/g network. -
Page 5: Chapter 2 Hardware
PCB Dimensions: 68mm x 21.8mm x 1mm (L x W x H) • PCBA net weight: around 6g 2.5 Host Interface • USB 2.0 interface (4-pin connector) 2.5 Antenna • Single band on-board PCB antennas with 2 dBi antenna gain WN7522C 1... -
Page 6: Chapter 3 Software
♦ AP (Infrastructure) mode supports ♦ Static WEP that support both 64 and 128 bit keys. ♦ WPA(TKIP) with PSK ♦ Ad-hoc mode supports ♦ None (plaintext) ♦ Static WEP that supports both 64 and 128 bit keys. WN7522C 1... -
Page 7: Chapter 4 Appearance
User Manual Chapter 4 Appearance Figure 4-1 below illustrates the mechanic drawing of the module with 4-pin USB connector. Figure 4-1 Mechanic drawing WN7522C 1... -
Page 8: Chapter 5 Specifications
16.5 +/- 1 dBm@54Mbps 15.5 +/- 1 dBm Rx Sensitivity:(Typical) -84 dBm @11 Mbps -72 dBm @54 Mbps -64 dBm @64-QAM, 20MHz channel spacing -61 dBm @64-QAM, 40MHz channel spacing ♦ Modulation DBPSK @1Mbps DQPSK@2Mbp CCK@5.5/11Mbps BPSK@6/9 Mbps WN7522C 1... - Page 9 ♦ Storage Temperature: -10 ~ 70 C ambient ♦ Humidity: 5 ~ 90% and must be non-condensing ♦ Regulation and certification compliance available: ♦ WHQL ♦ ETSI/CE ♦ ESD: EN61000-4-2, which specifies 4kV contact and 8kV air discharge. WN7522C 1...
- Page 10 2.4GHz operation of this product in the U.S.A. is firmware-limited to channels 1 through 11. IMPORTANT NOTE: This module is intended for OEM integrator. The OEM integrator is still responsible for the FCC compliance requirement of the end product, which WN7522C 1...
- Page 11 Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. Industry Canada Statement This device complies with RSS-210 of the Industry Canada Rules. WN7522C 1...
- Page 12 20cm separation with the antenna while this end product is installed and operated. The end user has to be informed that the IC radio-frequency exposure guidelines for an uncontrolled environment can be satisfied. The end user has to also be informed that any changes or WN7522C 1...
- Page 13 (2) this device must accept any interference received, including interference that may cause undesired operation. LABEL OF THE END PRODUCT: The final end product must be labeled in a visible area with the following " Contains TX IC : 4711A-WN7522CJU ". WN7522C 1...
- Page 14 Technology Corp. issued in strict confidence and shall not, without the prior written permission of Arcadyan Technology Corp., be reproduced, copied or used, in parts or as a whole, for any purpose whatsoever, except the manufacture of articles for Arcadyan Technology Corp.
