- Page 1 Model 4215C TEDS Guide Morehouse Instrument Company, Inc. 1742 Sixth Ave, York PA 17403 USA Tel: (717) 843-0081, Fax: (717) 846-4193 www.morehouseinst.com...
-
Page 2: Warranty And Limitation Of Liability
Morehouse Instrument Company, Inc. May 15, 2024 Morehouse Instrument Company. All rights reserved. Model 4215 Pg. 1 PUB.3499-01 Morehouse Instrument Company, Inc. -
Page 3: Table Of Contents
MOREHOUSE INSTRUMENT COMPANY INC. MODEL 4215 V7.1.0 contents WARRANTY AND LIMITATION OF LIABILITY ................. 1 COPYRIGHT ..............................1 CONTENTS ..............................1 INTRODUCTION ............................3 USING THE TEDS FEATURES OF THE M4215 ..................3 TEDS T ..................3 ENERAL NFORMATION BOUT... -
Page 4: Introduction
MOREHOUSE INSTRUMENT COMPANY INC. MODEL 4215 V7.1.0 Introduction The Model 4215 is capable of handling and using TEDS sensors as an assistant to the calibration process. A listing of TEDS related features are as follows: TEDS Template 33 Plug & Play features. -
Page 5: Using Teds33/40/41 With A New Sensor Or Teds Chip
MOREHOUSE INSTRUMENT COMPANY INC. MODEL 4215 V7.1.0 The first new function added to the System Options is the “TEDS Enable” option. The TEDS Enable Option will give the user the ability to toggle TEDS functionality on or off. Turning this Option “On” will allow the M4215 to recognize any connected TEDS 33, 40, or 41 Sensors and turn on the TEDS annunciator on the front panel (denoted by the letter “T”). -
Page 6: Copying And Erasing Teds Data
MOREHOUSE INSTRUMENT COMPANY INC. MODEL 4215 V7.1.0 Once “Enter” is pressed, the channel selection screen will appear. This will ask the user to select which channel the TEDS device to be formatted is connected to. You may select which channel using the Item, Unit, +, and – buttons. When the channel you wish to format is selected, press Enter. -
Page 7: Teds Submenu
MOREHOUSE INSTRUMENT COMPANY INC. MODEL 4215 V7.1.0 TEDS Submenu The TEDS Submenu contains the majority of the TEDS Read / Write functionality for the three major templates. To access this submenu, go to the Setup Menu by pressing the Item and Unit buttons at the same time. Scroll over to the “>TEDS Menu” selection and press the Enter button. -
Page 8: Teds 40 Read / Write
MOREHOUSE INSTRUMENT COMPANY INC. MODEL 4215 V7.1.0 this submenu can be navigated using the Item and Unit buttons. Pressing the Enter button will allow you to begin editing the selected field. While editing a specific field, using the + and – buttons will change the character that the cursor is highlighting, and the Item/Unit buttons will change the position of the cursor. -
Page 9: Teds 41 Read / Write
MOREHOUSE INSTRUMENT COMPANY INC. MODEL 4215 V7.1.0 the selected field. While editing a specific field, using the + and – buttons will change the character that the cursor is highlighting, and the Item/Unit buttons will change the position of the cursor. Pressing the Enter button in this state will confirm any changes made. -
Page 10: Teds 41 Write
MOREHOUSE INSTRUMENT COMPANY INC. MODEL 4215 V7.1.0 T41 Data: 1. Domain Parameter 2. Curve Segments 3. Segment Start % 4. Segment Number of Polynomial Terms 5. Segment Exponent 6. Segment Coefficient Each of the above items can be individually viewed in the TEDS 41 Read menu. To change the currently observed item on the front panel, press the Item and/or unit buttons to scroll through the list. -
Page 11: Teds 41 Terms
MOREHOUSE INSTRUMENT COMPANY INC. MODEL 4215 V7.1.0 TEDS 41 Terms The quantity of terms that the M4215 is able to support when writing to a TEDS 41 chip will vary depending on the family of chip being used. Generally, DS2433 chips will be able to handle and store significantly more polynomial terms than the DS2431 chips. -
Page 12: Remote Communications
MOREHOUSE INSTRUMENT COMPANY INC. MODEL 4215 V7.1.0 Remote Communications Most features in relation to TEDS can also be accessed via a remote ASCII command set. Communications can be established via RS-232/RS-485 protocols through the serial port on the rear panel of the unit or via USB communications through the USB port on the rear panel of the unit in conjunction with the USB driver installed on the host PC. -
Page 13: Teds Features Command Summary
MOREHOUSE INSTRUMENT COMPANY INC. MODEL 4215 V7.1.0 TEDS Features Command Summary @(addr) ╠═ System Options ║ ╠═ TEDS Enable ║ ╠═ TEDS Options ║ ╠═ TEDS 33 Settings ║ ║ ╠═ C (Channel Letter) Change Current Settings ║ ║ ╠═... -
Page 14: Teds B/33 View Command (Jfv)
MOREHOUSE INSTRUMENT COMPANY INC. MODEL 4215 V7.1.0 TEDS B/33 View Command (JFV) The TEDS Basic / 33 View Command (JFV) can be used to view all current TEDS Basic and 33 template settings. Example (User Entered): @123JFV Acknowledgment: TEDS BASIC... - Page 15 MOREHOUSE INSTRUMENT COMPANY INC. MODEL 4215 V7.1.0 JF1 (manufacturer code)# valid range 17 – 16381 JF2 (model number)# valid range 0-32767 JF3 (Version letter)# valid range A-Z, space, comma, period, right slash, underscore. Note that the @ symbol is a legal character but cannot be sent over the serial line because it is a command terminator.
-
Page 16: Teds B/33 Write Command (Jfw)
MOREHOUSE INSTRUMENT COMPANY INC. MODEL 4215 V7.1.0 JF15 (normal excitation level)# Valid values are 0.1v to 51.1V. The M4215 can provide 5v or 10v excitation to the load cell. Nominal excitation should be set to either 5v or 10v for use with the M4215. If the excitation voltage is set within 10% of 5V, 5V is used. If the excitation voltage is set within 10% of 10V, 10V is used. -
Page 17: Teds 40 Change Channel Command (Jgc)
MOREHOUSE INSTRUMENT COMPANY INC. MODEL 4215 V7.1.0 TEDS 40 Change Channel Command (JGC) The TEDS 40 Change Channel Command (JGC) is used to specify which channel is currently being observed for the purposes of TEDS functionality. This function will only operate if the M4215 has more than one channel active. -
Page 18: Teds 41 Change Channel Command (Jhc)
MOREHOUSE INSTRUMENT COMPANY INC. MODEL 4215 V7.1.0 command, the M4215 will begin its write operation to the TEDS Chip. The Front Panel will acknowledge this with a message that notifies the user that A TEDS write operation has begun. Upon successful completion, the M4215 will send acknowledgements both through the front panel and RS232 reflecting the successful operation. -
Page 19: Teds 41 User Data Entry (Jh)
MOREHOUSE INSTRUMENT COMPANY INC. MODEL 4215 V7.1.0 TEDS 41 User Data Entry (JH) This set of commands is used to enter information for programming a TEDS device. Note that percentages are represented as floating point numbers between 0 and 100. -
Page 20: Teds 41 Write Command (Jhw)
MOREHOUSE INSTRUMENT COMPANY INC. MODEL 4215 V7.1.0 JH6 (Segment Number) (Coefficient Number) (Value)# To add a constant to the equation, use exponent zero and set the corresponding coefficient to the constant value. For example, to set the first constant in segment 3 equal to 5 use the following command: JH5 3 0 5#. -
Page 21: Teds 41 Terms
MOREHOUSE INSTRUMENT COMPANY INC. MODEL 4215 V7.1.0 TEDS 41 Terms The quantity of terms that the M4215 is able to support when writing to a TEDS 41 chip will vary depending on the family of chip being used. Generally, DS2433 chips will be able to handle and store significantly more polynomial terms than the DS2431 chips.
