Fire 2-4 Zone Detection System
Contents
Model 08458
Rev 1.4
Page | 1
Advertisement
Related Manuals for FirePro 08458
Summary of Contents for FirePro 08458
- Page 1 Fire 2-4 Zone Detection System Model 08458 Rev 1.4 Contents Specifications ..................2 Mounting ..................... 2 Terminals & Cable Size ................. 2 Siren Output ..................3 Installation ................... 3 Operation ..................... 3 Page | 1...
- Page 2 Fire 2-4 Zone Detection System Model 08458 Rev 1.4 Specifications Dimensions 143mm high, 84mm wide, 31mm deep Enclosure material ABS plastics, black colour Operating voltage 12-30VDC Operating current 50mA on 12V 74mA on 24V Power supply inputs Main and backup...
- Page 3 Backup Power (if installed) must be same voltage as Main. Operation The FP-08458 Control Panel uses LED indicators to notify the operator of the condition of the control panel and each of the monitored circuits. If an LED is illuminated, it indicates the following:...
- Page 4 Fire 2-4 Zone Detection System Model 08458 Rev 1.4 Switch Pressing the switch until 1 beep is heard from the panel sounder, then releasing the switch. The panel is in isolation mode. The circuits continue to monitor the fire detectors for alarm and fault, and show the alarm and fault indications, but will not operate the siren.
