AMGO Hydraulics J6A Installation And Service Manual

Rolling jacks
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Cargo Claims
If there is any missing or damaged
product during transportation, the
buyer must notate on the shipping
paperwork or refuse the shipment.
NOTATE ALL DAMAGE OR REFUSE
DAMAGED SHIPMENT!
ROLLING JACKS
Model: J6A J6H
△
DANGER
!
Read the entire contents of this manual before
using this product. Failure to follow instructions and
safety precautions could result in serious injury or
even death. Make sure all other operators also read
this manual. Keep this manual near the machine so
that it can be seen by all users. By proceeding with
installation and operation, you agree that you are
fully understand the contents of this manual and
take full responsibility for the use of the product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the J6A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AMGO Hydraulics J6A

Summary of Contents for AMGO Hydraulics J6A

  • Page 1 ROLLING JACKS Model: J6A J6H △ DANGER Read the entire contents of this manual before using this product. Failure to follow instructions and Cargo Claims safety precautions could result in serious injury or even death. Make sure all other operators also read If there is any missing or damaged this manual.

  • Page 2: Table Of Contents

    CONTENTS PROFILE ..........................1 IMPORTANT SAFETY INSTRUCTIONS ................ 2 I. PRODUCT FEATURES AND SPECIFICATIONS ............ 4 II. STORAGE AND INSTALLATION REQUIREMENT ..........6 III. INSTALLATION STEPS ..................... 6 IV. OPERATION INSTRUCTIONS .................. 8 V. MAINTENANCE SCHEDULE ..................13 VI. TROUBLE SHOOTING ..................... 14 VII.

  • Page 3: Profile

    PROFILE This instruction manual is specially prepared for you. Your new lift is the product of over a decade of continuous research, testing and development and is the most technologically advanced lift on the market today. Please make sure to read through this manual before operating the lift. Record the information on the nameplate label here: Model No.: Serial No.:...

  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Please read this safety instructions entirely in first! In order to properly maintain your product and ensure operator safety, it is the responsibility of the product owner to read and follow these instructions! 1. Read explicitly and understand all safety warnings before operating the lift. 2.
  • Page 5 14. Maintain with care. Keep the machine clean for better and safer operation. Perform proper lubrication and maintenance procedures according to the manual. Keep handles or buttons clean, dry, and free of oil. 15. Stay alert. Use common sense to observe what you are doing. 16.

  • Page 6: Product Features And Specifications

    Self-locking safety mechanism: dual safety lock device & mechanical lock.   Easy operation：J6A equipped with pneumatic pump activated by air,J6H equipped with hand pump. Can be used separately or work with four post lifts and large scissors lifts. ...
  • Page 7 Measurement Image Fig.2 Specifications Lifting Model Arm Pads Min. Support Base Min. Rubber Max Lifting Height Max Lifting Height Overall Pump capacity Pressure Reach Height Width pad height (without adapters) (with adapters) Width Pneumatic 33 3/16”- 53 33 11/16”- 52 0.8MPa 6,000lbs 8 1/2”...

  • Page 8: Storage And Installation Requirement

    The equipment should be unloaded and transferred by forklift or lifting crane. Fig.3 3. Air source requirements(Only J6A) The air source pressure must be above 0.8MPa III.Installation procedure 1. Check the parts before assembly, confirm all the parts are prepared.
  • Page 9 (large scissor lift). Fig.5 Stuck roller in the slot 3. Connecting air source(Only J6A) After the rolling jack is installed, plug air line fitting into pneumatic pump input fitting, the air source is then connected to the pump.

  • Page 10: Operation Instructions

    1. Preparation before use: 1.1 Make sure the 4-post lift or large scissor lift is locked; 1.2 J6A is activated by air source, please prepare air source in advance; J6H no need air source. An oil-water separator must be installed on the air source device. Failure to install oil-water separator may cause a damage to the equipment.
  • Page 11 2.2 Lifting operation of J6A Adjust the rubber pad assy. positions according to the vehicle lifting points. Fig.8 B. Press ‘PUMP’ to fill air into the pump and the rolling jack rises. Fig.9 C. When the rolling jack reaches the appropriate working height, press ‘RELEASE’ to lock it at the nearest safety lock.
  • Page 12 2.3 Descending operation of J6A A. Press ‘PUMP’ to raise the jack for few seconds till the safety lock is released (safety block completely out of safety lock position). Safety lock released Fig.11 B. Turn up the safety block handle with a hand and press ‘RELEASE’ with the other hand , the jack descends.
  • Page 13 3. Operation of J6H 3.1 Lifting operation of J6H A. After installation, tighten the release rod in clockwise direction and loosen the white exhaust screw at the end of hand pump in counterclockwise direction for about 1 turn. Then pump the hand pump operation handle to raise the jack. ③...
  • Page 14 3.2 Descending operation of J6H A. Pumping the hand pump to raise the jack for few seconds till the safety lock device is released. Safety lock is released Fig.16 Turn up the safety block handle to release the safety lock, and rotate the release rod in counterclockwise direction to descend the jack.

  • Page 15: Maintenance Schedule

    V. MAINTENANCE SCHEDULE Keep the Rolling Jack clean; wipe up any oil spills. Do not let dirt get into the hydraulic system. 1. Daily： • Make a visual inspection of all moving parts and check for damage or excessive wear. Replace any damaged or worn parts before setting the Jack back into service.

  • Page 16: Trouble Shooting

    trash or dumped to the environment.It pollutes the environment and is illegal. Instead, take it to a recycling center. Used/dirty hydraulic oil can be cleaned and re-used. VI. TROUBLE SHOOTING TROUBLE CAUSE REMEDY 1. Low pressure 1. Recheck air pressure 0.8Mpa 2.
  • Page 17 TROUBLE CAUSE REMEDY 1. Low oil level 1. Fill in the tank 2. Oil line leakage 2. Check the oil line, tighten fittings. 3. Dirty hydraulic oil 3. Check the oil, replace and clean Jack raises hydraulic system slowly or descent 4.

  • Page 18: Exploded View

    VII. EXPLODED VIEW Hand Pump Hydraulic Pump Fig.20...
  • Page 19 Straight fitting 3/8NPT*1/4JIC(M) 1004334013 Pneumatic input fitting 1/4 NPT Male 10670002 Pneumatic pump (J6A) 1005064001-01 Wave tube φ25.5*φ20*550 (J6A) 10680084-01 Oil hose assy. 1/4*20 1/2” (J6A) 10420097 fitting 10690002 Hand pump (J6H) 10209043 Hex bolt 1005034001-01 Wave tube φ25.5*φ20*360 (J6H) 10680088 Oil hose assy.
  • Page 20 CYLINDER （10600030） 28-4 28-1 28-2 28-5 28-6 28-3 28-7 28-8 28-9 Fig.21 28-10 28-11 PARTS FOR HYDRAULIC CYLINDER Item Part No. Description 28-1 10209078 Dust RingФ38*Ф46*5 28-2 11670006 Head Cap 28-3 11670007 Bore Weldment 28-4 11670008 Piston Rod 28-5 11670009 Piston 28-6 10201031...

  • Page 21: Viii.car Lift Safety Tips

    VIII. Car lift safety tips Put this safety tips in a place where you can always alert the operator. Please reference to the lift manufacturer’s manual for specific information about the lift. 1. Check the lift daily. If the machine breaks down or has damaged parts, do not operate, and use the parts of original equipment to repair.
  • Page 22 Manual no.:72267901 Revision date: 2024/04...
