Cargo Claims
If there is any missing or damaged
product during transportation, the
buyer must notate on the shipping
paperwork or refuse the shipment.
NOTATE ALL DAMAGE OR REFUSE
DAMAGED SHIPMENT!
SLIDING JACKS
Model: J5H
△
!
Read the entire contents of this manual before
using this product. Failure to follow instructions
and safety precautions could result in serious
injury or even death. Make sure all other
operators also read this manual. Keep this
manual near the machine so that it can be seen
by all users. By proceeding with installation and
operation, you agree that you are fully
understand the contents of this manual and take
full responsibility for the use of the product.
DANGER
Advertisement
Table of Contents
Related Manuals for AMGO Hydraulics J5H
Summary of Contents for AMGO Hydraulics J5H
- Page 1 SLIDING JACKS Model: J5H △ DANGER Read the entire contents of this manual before using this product. Failure to follow instructions and safety precautions could result in serious Cargo Claims injury or even death. Make sure all other operators also read this manual. Keep this...
-
Page 2: Table Of Contents
CONTENTS PROFILE ..........................1 IMPORTANT SAFETY INSTRUCTIONS ................ 2 I. PRODUCT FEATURES AND SPECIFICATIONS ............ 4 II. STORAGE AND INSTALLATION REQUIREMENT ..........6 III. INSTALLATION STEPS ................... 6 IV. OPERATION INSTRUCTIONS ................8 V. MAINTENANCE SCHEDULE ..................10 VI. TROUBLE SHOOTING ..................... 11 VII. -
Page 3: Profile
PROFILE This instruction manual is specially prepared for you. Your new lift is the product of over a decade of continuous research, testing and development and is the most technologically advanced lift on the market today. Please make sure to read through this manual before operating the lift. Record the information on the nameplate label here: Model No.: Serial No.:... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Please read this safety instructions entirely in first! In order to properly maintain your product and ensure operator safety, it is the responsibility of the product owner to read and follow these instructions! 1. Read explicitly and understand all safety warnings before operating the lift. 2. - Page 5 14. Maintain with care. Keep the machine clean for better and safer operation. Perform proper lubrication and maintenance procedures according to the manual. Keep handles or buttons clean, dry, and free of oil. 15. Stay alert. Use common sense to observe what you are doing. 16.
-
Page 6: Product Features And Specifications
I. PRODUCT FEATURE AND SPECIFICATIONS Self-locking safety mechanism: dual safety lock device & mechanical lock. Easy operation. Can be used separately or work with four post parking lift. Drop in rubber pads with 1.5", 2.5" extension adapters. Fig.1... - Page 7 Measurement Image Fig.2 Specifications Lifting Model Arm Pads Min. Support Base Min. Rubber Max Lifting Height Max Lifting Height Overall Pump capacity Reach Height Width pad height (without adapters) (with adapters) Width 35 5/8”- Hand 5000 lbs 33”-53 7/16” 8 5/8” 5”...
-
Page 8: Storage And Installation Requirement
II.Storage and Installation 1. Requirements. 1.1. Store the equipment in a dry, non-moldy, non-flammable environment.; 1.2. The lift is only approved for indoor installation and use, and outdoor installation is prohibited; When installing the device, take safety precautions according to the instructions to 1.3. - Page 9 Equipment installation 2.1 The extendable lower sliding are telescoped to shortest fully. See Fig 5.The limit screws which on both sides of the extendable lower sliding should be loosen before installation. Fig.5 Limit screw Limit block 2.Adjust the extendable lower sliding to ensure limit 1.Loosen the limit screw and pull out the screw is between two limit blocks, and then tighten the extendable lower sliding.
-
Page 10: Operation Instructions
3. Operation instruction 3.1 Lifting operation of J5H A. After installation, tighten the release rod in clockwise direction and loosen the white exhaust screw at the end of hand pump in counterclockwise direction for about 1 turn. Then pump the hand pump operation handle to raise the jack. - Page 11 3.2 Descending operation of J5H A. Pump operation handle to raise the jack for few seconds till the safety block completely out of safety lock position, then stop pumping. Safety block completely out of safety lock position Fig.11 B. Turn up the safety block handle to release the safety lock, and rotate the release rod in counterclockwise direction to descend the jack.
-
Page 12: Maintenance Schedule
V. MAINTENANCE SCHEDULE Keep the Rolling Jack clean; wipe all spills. Do not let dirt get into the hydraulic system. 1. Daily： • Make a visual inspection of all moving parts and check for damage or excessive wear. Replace any damaged or worn parts before setting the Jack back into service. •... -
Page 13: Trouble Shooting
VI. TROUBLE SHOOTING TROUBLE CAUSE REMEDY 1. Low oil level 1. Fill in the tank 2. Oil line leakage 2. Check the oil connection and the fittings are tighten 3. Dirty hydraulic oil 3. Check the oil, replace and Jack raises clean hydraulic system slowly or 4. -
Page 14: Exploded View
VII. EXPLODED VIEW Fig.15 Exploded view of cylinder 27-4 27-1 27-2 27-5 27-6 27-3 27-7 Fig.16 27-8 27-9 27-10 27-11... - Page 15 Rolling Jack parts list Item Part No. Description 11680030C Rubber pad assembly Hex bolt M8*16 (include φ8 flat washer, φ8 1005134004 lock washer) 11600039 Extendable arm frame 11600038 Upper support 11600036 Pin for upper roller 11600035 Upper roller 10206032 Ф25 clip ring 11680011 Pin for lower roller 10680009...
- Page 16 PARTS FOR HYDRAULIC CYLINDER Item Part No. Description 27-1 10209078 Dust Ring Ф38*Ф46*(5~6.5) 27-2 11670006 Head Cap 27-3 11670011 Bore Weldment 27-4 11670008 Piston Rod 27-5 11670009 Piston 27-6 10201031 O Ring Ф56*3.55 27-7 10201029 Support Ring Ф57*Ф63*12.5*3 27-8 10201030 Y Ring OSI Ф57*Ф63*6 27-9 10201030A...
-
Page 17: Viii.car Lift Safety Tips
VIII. Car lift safety tips Put this safety tips in a place where you can always alert the operator. Please reference to the lift manufacturer’s manual for specific information about the lift. 1. Check the lift daily. If the machine breaks down or has damaged parts, do not operate, and use the parts of original equipment to repair. - Page 18 Manual no.:72267801 Revision date: 2024/04...
