FASTTRAK SLIMLINE F63-D Assembly Instructions Manual

Hide thumbs

Advertisement

Table of Contents

SLIMLINE F63-D
REVISION 04/15
How to build Video
NOTES
BEFORE COMMENCING SHED ASSEMBLY, CHECK ALL PARTS. IF THERE IS A DISCREPANCY, PLEASE CALL
SPANBILT (SEE REAR OF INSTRUCTION BOOK)
DO NOT ASSEMBLE IN WINDY CONDITIONS
THE MANUFACTURERS CANNOT BE HELD RESPONSIBLE FOR ANY CONSEQUENCES DUE TO SHEDS THAT ARE NOT
INSTALLED PER INSTRUCTIONS OR FOR DAMAGE DUE TO WEATHER CONDITIONS, ACTS OF GOD OR FOR SHEDS THAT
ARE LEFT PARTIALLY ASSEMBLED OVERNIGHT. PARTS MAY CONTAIN SHARP EDGES & CORNERS. CARE MUST BE TAKEN
WHEN HANDLING VARIOUS PIECES TO AVOID A MISHAP, FOR SAFETY SAKE, PLEASE USE A PAIR OF WORK GLOVES, EYE
PROTECTION & PROTECTIVE CLOTHING WHEN ASSEMBLING OR PERFORMING ANY MAINTENANCE ON THE BUILDING.
Subject to changes © SPANBILD PTY LIMITED
ASSEMBLY
INSTRUCTIONS
W2105mm x D1070mm x H1800mm
READ INSTRUCTIONS FIRST
1
ST
2 PERSON ASSEMBLY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SLIMLINE F63-D and is the answer not in the manual?

Questions and answers

Related Manuals for FASTTRAK SLIMLINE F63-D

Summary of Contents for FASTTRAK SLIMLINE F63-D

  • Page 1 SLIMLINE F63-D ASSEMBLY INSTRUCTIONS REVISION 04/15 How to build Video W2105mm x D1070mm x H1800mm NOTES BEFORE COMMENCING SHED ASSEMBLY, CHECK ALL PARTS. IF THERE IS A DISCREPANCY, PLEASE CALL SPANBILT (SEE REAR OF INSTRUCTION BOOK) DO NOT ASSEMBLE IN WINDY CONDITIONS...

  • Page 2: Tools Required

    TOOLS REQUIRED Measuring Tape Electric Drill Cordless Drill Screwdrivers 8mm Masonry Drill Bit Shifting Spanner 5mm Drill bit Builders Pencil Rubber Mallet Sturdy Ladder (two if possible) Gloves Protective Eyewear HANDY HINTS FOR CONSTRUCTION Read instructions and check parts carefully Please wear safety gloves and glasses at all before assembling the shed.

  • Page 3: Parts List

    PARTS LIST PRODUCT ID PRODUCT ID Length Length 1800mm 1040mm Quantity Quantity Description: Description: Wall Panel Door Bracing PRODUCT ID PRODUCT ID Length Length 1800mm 1706mm Quantity Quantity Description: Description: Wall Corner Panel Door Seal PRODUCT ID PRODUCT ID Length Length 2099mm 1149mm...
  • Page 4 PARTS LIST PRODUCT ID Length Quantity 2096mm Quantity Description: Padbolt Description: Gutter Trim PRODUCT ID Length Quantity 1141mm Quantity Description: Keeper Description: Roof Angle Trim Quantity Quantity Description: Description: Self Tapping Screws - Silver Plastic Washer and Screw Cap Sheet Quantity Quantity Description:...
  • Page 5 PARTS LIST Quantity Quantity Masonry Anchor Phillips Head Bit PAGE 05...
  • Page 6 FOUNDATION Recommended edge thickening Recommended slab rebate detail Although not required, it is strongly recommended that, to avoid water leakage around the base of your shed, a rebate be cast into the slab. This will allow the shed to sit below the slab level and prevent water from reaching the upper level of the slab.
  • Page 7 REAR WALL PANEL Top of the shed If you are having trouble screwing the channel to the sheets, chock behind sign indicate the tek the hole . screw position Outside Looking from outside the shed Make sure to position the “D” panel here Small lip Ensure that the small lip of the channel is to the...

  • Page 8: Front Wall Panel

    FRONT WALL PANEL Top of the shed If you are having trouble screwing the channel to the sheets, chock behind the hole . Outside Looking from outside the shed Small lip Ensure that the small lip Bottom of the shed of the channel is to the outside of the shed.
  • Page 9 PAGE 09...
  • Page 10 FRONT WALL PANEL PAGE 10...
  • Page 11 SIDE WALL PANELS (2 REQUIRED) Top of the shed Top of the shed If you are having trouble Top of the shed Right side wall Top of the shed Left side wall screwing the channel to the sheets, chock behind the hole .
  • Page 12 STAND AND JOIN WALL PANELS NOTE: The diagram below shows a 44 flat roof shed. The assembly process is the same for all flat roof sizes. Overlap corners of panels as shown and fix midway along the corner with self tap screw Once the four wall panels are assembled, they can now be stood and fixed together.
  • Page 13 Step 3: Screw the front side Step 1: Place roof sheet on Step 2: Start from rear side. through all holes “C”. top, start from the left, big rib Screw all holes “B” one screw per sheet. should flush with channel “N” Do not screw the hole “A”...
  • Page 14 FIT ROOF TRIMS First Remove the tek screws from top of side wall sheets then fix it along with the Trim W. Fix Trim V on front and back of the shed. Trim V should position on op of Trim W. Scew the trim W on every rib PAGE 14...
  • Page 15 ASSEMBLE DOOR Use clip nuts only where large lip lap over large lip Small Lip Large Lip Screw the sheets in the center. Use clips nuts Both of the door sheets come with one rib h f h d where ever required as per the above diagram partially slit.
  • Page 16 ASSEMBLE DOOR Fix the frame H to the sheeting with screws through the small channel lips into the large sheeting ribs. Door boxing “J” must be fitted to the door frames ”I” and a door seal fitted on the door 2. The seal fits to the frame and boxing as shown to the right.
  • Page 17 ASSEMBLE DOOR Flip the door assembly’s over and fix the door frames with screws evenly spaced as shown above. Make sure to screw through the sheeting. Door bracing will also need to be fitted to the doors to ensure sturdiness. Drill pilot hole for top and bottom bracing joint, and fix with self tapping screw.
  • Page 18 ASSEMBLE DOOR Use plastic Screw cap Flip the door back over to the front side facing up. Using the pilot holes drilled before, fix the door bracing from the front with self tapping screws. Use screw cap on all 8 screws here. Drill a 2.5mm pilot hole through the door plate and into the sheeting and...
  • Page 19 BOLT DOWN Bolt the shed down through the four corner brackets as shown. Ensure the shed is square. Drill pilot hole as in the following pictures and fix the M8 Anchor bolt to the floor through the angle bracket. M8 x 40 M8 x 40 M8 x 40 M8 x 40...
  • Page 20 BOLT DOWN Bolt the shed down through the angle brackets as shown. Drill the hole for the anchor to 50mm depth and then using a 5mm drill bit, drill the holes through the sheeting to attach the bracket to the shed.
  • Page 21 HANG DOOR NOTE: The diagram below shows a 64 flat roof shed. The assembly process is the same for all sheds. Fit the doors by fixing the hinges to the pre-drilled holes in the door jambs. Fit the padbolt and keeper to the front of the doors.
  • Page 22 Thank you for purchasing FASTTRAK system steel garden shed. ® Your personal warranty is backed by Spanbilt, the manufacturer of FASTTRAK system garden sheds, and our proven commitment to quality and customer service. Our goods come with guarantees that cannot be excluded under Australian consumer law.

  • Page 23: Owners Details

    Please attach here a photocopy of proof of purchase Retain the original for your records You must submit your warranty registration certificate within 60 days of the purchase date of your FASTTRAK® garden shed. Post your certificate and supporting documentation to: Australia...
  • Page 24 PO B ox 1581 B rowns Plains , QLD 4118 Enquiries 07 3827 8000 1800 222 166 Building Ad vice Line 1800 032 077 w ww .spa nbilt.c om.au 112 Waterlo o Road PO B ox 11-013 Sockburn, Christchurch TELEPHONE 03 349 3480 0800 772 6245 w ww .sp anbilt.c o.nz...
