Avenue 2
Class 1
LED
1
Scellement des tiges &
fixation du mât
Install anchor J-Bolts in
concrete foundation &
fix the mast
110
Classe énergétique du luminaire à disposition sur notre site internet. - Type et puissance max. indiqués sur l'étiquette signalétique dans le luminaire. - Energy label for lighting fixture available on our website. - To know the bulb type and max wattage, please, refer to the label inside light fitting.
2
Montage des bras
Assemble the brackets
1
2
3
110
3
Montage de l'ensemble sur le mât
Mount the sub-assembly on the mast
1
x3
x3
2
x3
x3
x3
x12
x3
4
Raccordement électrique
Connect electrical wires
3
x1
Advertisement
Related Manuals for Roger Pradier Avenue 2
Summary of Contents for Roger Pradier Avenue 2
- Page 1 Avenue 2 Class 1 Scellement des tiges & Montage des bras Montage de l’ensemble sur le mât Raccordement électrique Assemble the brackets Mount the sub-assembly on the mast Connect electrical wires fixation du mât Install anchor J-Bolts in concrete foundation &...
- Page 2 Installation des verres Montage du chapiteau Fixation des luminaires Put in place glasses Assemble the dome Fix the luminaires contact LUBRIFIANT Grease Serrer la vis dans la gorge pour maintenir le contact et la compression du joint d’étanchéité Tighten the screw into the groove in order to keep surface in contact and ensure proper sealing gasket compression roger-pradier.com...
