- Page 1 User’s Manual 使用说明书 Brighten Your Digital View! DCH-3000EC MPEG-2 Encoder P/N.25001-68609 Rev: E www.pbi-china.com...
- Page 2 DCH-3000EC MPEG-2 Encoder Contents Warnings and Cautions 1 Summarization 1.1 Overview 1.2 System Frame 1.3 Working principles 1.4 Control panel and interface 2 Interface illumination 3 Typical Application 3.1 Encoder 3.2 Digital Sources for MUX 4 Menu structure and operate 4.1 Menu layer...
-
Page 3: Warnings And Cautions
2. Do not use unauthorized part for authorized entity after repair is done to repair be sure the equipment can be put back 3. Do not open the covers of the to operation. equipment without proper factory 6.Read the operating manual prior to authorization usage. www.pbi-china.com... - Page 4 1 Summarization 1.1 Overview DCH-3000EC is a professional MPEG-2/DVB real-time digital encoder which fully complies with ISO/IEC13818 standard. It is of highly integrated 1U chassis with a broad field of applications such as CATV digital network, digital TV broadcast, and transmission of programs for MPEG-2/DVB standard.
-
Page 5: Working Principles
Audio encoder: MPEG layer1 or layer2 1.3.2 DCH-3000EC control system DCH-3000EC provides two control methods, menu control mode and network operating mode. In menu operating mode, user can operate through buttons and the promotions on LCD. The detailed user guide is in chapter 4.Under the network operating mode, operation is done through software running on Windows, more detailed information is in network operation manual. - Page 6 DCH-3000EC MPEG-2 Encoder 2 Line×24 characters LCD Display A5-8 press KEY Select or change function parameters ENTER Run menu choice EXIT Exit current Menu and return to the previous menu 1.4.2 Rear panel B4 B5 B6 B7 B8 B9 B10 B11...
- Page 7 AC 90~260V，50Hz/60Hz DVB-ASI Serial digital output Port configuration 75 Ohms，BNC connector Transfer rate 270Mb/s Transfer model Byte Packet length 188 Bytes Signal level 800mV Other Net Weight Dimensions 44mm×240mm×430mm Power rating Operating temp 0~40℃ Storage temp -20~70℃ Moisture ＜85% www.pbi-china.com...
-
Page 8: Typical Application
DCH-3000EC MPEG-2 Encoder 3 Typical Application 3.1 Encoder 3000EC can output one channel of single program TS as an independent MPEG-2 compression Encoder. PBI-3000EC PBI-1000TM Encoder QAM transmodulator Cable PBI-3000EC PBI-1000TM Encoder QAM transmodulator Network PBI-3000EC PBI-1000TM Encoder QAM transmodulator 3.2 Digital Sources for MUX... - Page 9 IP Address: 10.10.70.55 Local Setting System Network Mask: 255.255.255.000 Gateway: 10.10.70.1 MAC Address: 00:7A:77:7A:77:7B Remote Setting Upgrade IP Address: 10.10.70.25 Upgrade Enable: Enable/Disabled Server IP Address: 10.10.70.25 Unit Name DCH-3000EC Main Software: 3.1.0 FPGA Software: 2.0.0 Code Software: 1.0.0 Save Parameter www.pbi-china.com...
- Page 10 DCH-3000EC MPEG-2 Encoder 4.2 Menu operation and illumination 4.2.1 Initializing Menu Once the Power is ON, the encoder begins initializing, LCD shows Waiting………. And, the setting Encoder parameters as follows: DCH-3000EC IP：10.10.70.55 1) First Line is 3000EC parameters, which shows Encoder type.
-
Page 11: Video Mode
Mode menu: Press[↓]or[↑], choose Mode option, enter the following menu: Video Mode： PAL BGHIN / NTSC 4.43M 50Hz / PAL N / NTSC N / SECAM / NTSC M / PAL 4.43M 60Hz / NTSC 4.43M 60Hz / PAL M www.pbi-china.com... -
Page 12: Video Resolution
DCH-3000EC MPEG-2 Encoder Video Mode：PAL BGHIN / NTSC 4.43M 50Hz / PAL N / NTSC N / SECAM / NTSC M / PAL 4.43M 60Hz / NTSC 4.43M 60Hz / PAL M, These are different TV modes. Press[←]or[→], choose input signal mode, press[ENTER] to confirm, press[EXIT] to exit. - Page 13 Press[↓]or[↑] to choose “Channel”, enter the following menu: Audio Channel： Stereo / Mono / Dual Stereo、Mono、Dual：Represents stereo audio, single audio and left /right track audio Press[←]or[→] to choose Stereo, Mono or Dual audio mode, press[ENTER] to confirm, press[EXIT]to exit. www.pbi-china.com...
- Page 14 DCH-3000EC MPEG-2 Encoder 4.2.2.3 Output Rate menu Move cursor to Output Rate, press [ENTER] to enter the following menu: Encoder：Locked 05.142856Mbit/s Press [EXIT] to exit. The setting is used for checking status and TS rate. 4.2.3 System menu Enter the Output Setup menu, as the follows:...
- Page 15 The option is used to setup MAC Address, press[←]or[→] to move to left or right, press[↓]or[↑] change MAC address, press[ENTER] to confirm, press[EXIT]to exit. Notice: MAC Address is unique in the worldwide, So it has been set before leaving factory. www.pbi-china.com...
- Page 16 DCH-3000EC MPEG-2 Encoder 4.2.3.2 Remote Setting Move cursor to Remote Setting, press [ENTER] to enter the following menu: Remote Setting Upgrade IP Address There are 4 options to be chosen: Upgrade IP Address, Upgrade, and Server IP Address. Network control setup parameters can be checked and edited. Press [↓] or [↑] to choose the option, press [ENTER] to confirm.
- Page 17 Brighten Your Digital View! Unit Name: DCH-3000EC It is the name of this machine. Press [ENTER]，then press[←]or[→] to move to left or right, press[↓]or[↑] to change, press[ENTER] to confirm, press[EXIT]to exit. 4.2.3.4 Main Software Move cursor to Main Software, press [ENTER] to enter the following menu: Main Software: 3.1.0...
- Page 18 ② 3000EC：Link the reticles as the above picture. Turn on the power supply, enter the menu， then set the DCH-3000EC and the needed to be set up menu as follows： System->Local Setting->IP Address->10.10.70.100 (3000EC IP address should be in local network that consist with the IP of FTP server) System->Remote Setting->Upgrade IP Address->10.10.70.3...
-
Page 19: Maintenance
Clean the device gently with a soft cloth. Avoid eroding Caution: Contact the agents if there is a problem with the device and do not attempt to repair the device without professional instructions by agents or PBI. www.pbi-china.com... - Page 20 DCH-3000EC MPEG-2 Encoder × Don’t dismantle the device Caution: It is recommended to use the AC regulated power supply. ~220V±10% 50Hz±10% Caution: The device must be grounded well. Caution: Well grounded 7 Accessories 1 power line, 75 ohm ASI line, 1 AV line, 1 S-video line, 1 CD of network management software, 1 user manual, 1 network operation manual，1 quality guarantee, 1 packing list.
- Page 21 DingJun Plaza, No. 75 Suzhou Street, Haidian District, Beijing, China, 100080 Tel：＋86 10-82617178 Fax：＋86 10-82610263 Mail：mkt@pbicn.com/sales@pbicn.com...
