- Page 1 DOLPHIN BABY CHANGING STATION BC200EH INSTALLATION AND SAFETY INSTRUCTIONS...
-
Page 2: Before You Begin
European and local, that are in force at the time. Dolphin solutions Ltd. is not liable for damages caused by the improper installation, poor maintenance or misuse of this baby changing station. -
Page 3: Installation Instructions
INSTALLATION INSTRUCTIONS REQUIRED TOOLS You will need the following tools for the installation of the baby changing station: Measuring tape in order to install the changing station to the appropriate height and distance Phillips Head Screwdriver in order to tighten the fasteners of the changing station A level in order for the changing station to be installed completely horizontal to the ground... - Page 4 www.dolphinsolutions.co.uk Step 1. Material inspection It is very important to carry out a visual inspection of the packaging of the baby changing station in order to ensure that it has not suffered any damage during transport and handling. If damage to the packaging is found, the changing station should be carefully inspected to see if it has suffered any damage.
- Page 5 Following the above scheme, using the pencil, mark on the wall the top two holes of the changing station's holding structure. It is very important to make sure that the locations marked with the pencil for the mounting holes are at the same level before drilling the holes. Installation according to ADA regulations.
- Page 6 www.dolphinsolutions.co.uk Once completed, proceed with cleaning the holes and placing the remaining four Ø10 mm nylon plugs. Put the changing station back on the top two screws and fix the structure to the wall with the four Ø6.3x70 mm screws and the four DIN125 M8 washers of the lower holes, then fully tighten the top two screws, the distribution of the components is shown in the following figure: Make sure that the six screws securing the unit to the wall have been properly tightened and that the changing station is firmly fixed to the wall.
- Page 7 Open the liner dispenser with the special key provided. The four holes for mounting the liner dispenser on the holding structure of the changing station will be visible. Fit the dispenser to the holding structure of the changing station and align the mounting holes of the dispenser. Fix the liner dispenser to the holding structure of the changing station using the four M4x8mm screws and the four DIN125 M4 flat washers, as shown in the figure.
- Page 8 www.dolphinsolutions.co.uk BASIC EXPLODED VIEW Remember that any additional component or spare part required for the baby changing station should only be purchased from the manufacturer or an authorized distributor. COMPONENT Label Shock absorber Lock + key Protective liners Shock absorber...
- Page 9 RECOMMENDATIONS FOR PREVENTIVE MAINTENANCE AND CLEANING Proper preventive maintenance and careful cleaning are essential for an appropriate, clean and safe product use. For proper maintenance, follow these steps: Inspect the components of the baby changing station: make sure that there are no cracks, dents or any other sign that would suggest any fault in the product.
- Page 10 www.dolphinsolutions.co.uk For proper cleaning, follow these steps: In order to avoid contact with the detergent, it is recommended to remove the liners from their housing before cleaning. Clean all plastic pieces of the changing station using antibacterial soap. Remove the soap residue with a dry cloth, making sure that the cleaning has been effective and that there are no residues of dirt or soap.
