HP Network Configuration Utility Agent

User Guide

Part Number 381502-00K
October 2007 (Tenth Edition)

Advertisement

loading

  Related Manuals for HP BladeSystem Dual NC370i - Multifunction Network Adapter

  Summary of Contents for HP BladeSystem Dual NC370i - Multifunction Network Adapter

  • Page 1: User Guide

    HP Network Configuration Utility Agent User Guide Part Number 381502-00K October 2007 (Tenth Edition)
  • Page 2 © Copyright 2006, 2007 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
  • Page 3: Table Of Contents

    Contents Overview............................. 4 Network Configuration Utility Agent ......................4 Using Network Configuration Utility Agent with HP SIM ..............5 Replicate Agent Settings tool........................5 Replicating network configuration settings ....................6 Viewing task results ........................... 9 Acronyms and abbreviations......................10 Index............................11...
  • Page 4: Overview

    ProLiant server. To better support server management, the Replicate Agent Settings tool of HP Systems Insight Manager (HP SIM) has been enhanced to work with the NCU. The replication tool enables HP SIM to retrieve the Network Configuration Utility web agent's configuration settings from a source server and then apply it to one or more target servers remotely.
  • Page 5: Using Network Configuration Utility Agent With Hp Sim

    Adapters embedded on the system board are assigned the lowest numbers, followed by adapters ordered by their slot or switch bay number with the lowest slot or switch bay number first. Multiport adapters are ordered by ascending port or switch port number within each slot.
  • Page 6: Replicating Network Configuration Settings

    3 and 5 are teamed on the target system. In general, the adapters on the team on the target system do not have to be the same type of adapters that were teamed on the source server. However, some adapters cannot be teamed and if an attempt is made to form a team with invalid combinations of adapters an error occurs.
  • Page 7 Click Next. The Step 2: Choose Source System window appears. Select the specific server with a configured network to replicate on the target servers. The Web Agent that supports network configuration is HP Network Configuration Utility. Click Next. The Step 3: Choose Source Configuration Settings window appears.
  • Page 8 This option initiates the Wake-on LAN (WOL) feature to remotely power up the target servers, if they are equipped with a WOL-enabled adapter or if they have ACPI support in the operating system. Refer to the section called "Replicate Agent Settings - Reference"...
  • Page 9: Viewing Task Results

    Viewing task results The Task Results window displays the task instance results and status of each targeted server. Details identifies the success or failure of the configuration and may include one of the following messages: Status Message Agent Configured Network Configuration-Agent Configured Successfully.
  • Page 10: Acronyms And Abbreviations

    Acronyms and abbreviations ACPI Advanced Configuration and Power Interface iSCSI Internet Small Computer System Interface Network Configuration Utility Receive-Side Scaling Systems Insight Manager TCP/IP Offload Engine VLAN virtual local-area network Wake-on LAN Acronyms and abbreviations 10...
  • Page 11: Index

    Index configuration, target site 5 error messages 9 log file 9 network configuration replication 9 Network Configuration Utility 6 replication settings 4, 5, 6 team configuration 6 Index 11...
