- Page 1 LDM231-251 All-in-One Direct View LED Display Installation Guide 快速入門指南 Guide de démarrage rapide Schnellstartanleitung Guía rápida de inicio...
- Page 2 Blank...
- Page 3 EU of the European Parliament and the Council on restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS2 Directive) and is deemed to comply with the maximum concentration values issued by the European Technical Adaptation Committee (TAC). ViewSonic Europe Limited Haaksbergweg 75 1101 BR Amsterdam Netherlands +31 (0) 650608655 EPREL@viewsoniceurope.com...
-
Page 4: Package Contents
Package Contents It is recommended to use pliers to open the shipping crate. Please wear protective gear, such as gloves and protective shoes. Before the installation, please take a moment to check if all components are included in the crate. If anything is missing or damaged, contact your dealer immediately. Item Quantity Note... - Page 5 Item Quantity Note Blank Wall Mount 1199 mm Brackets Wall Mount screwdriver screwdriver Connector Plates wrench wrench IR Extension IR Extension Cable Cable (3 m) power cord power cord Ethernet Cable 2 x Cross-head screwdrivers (1) Hand Tools 2 x Ratcheting wrenches (2) PM6 x 1 M8 nut PM6 x 1...
- Page 6 Ethernet Cable Ethernet Cable Item Quantity Note screwdriver Wall Mount wrench Brackets screwdr 1335 mm Blank (Hidden wrench power cord Installation) power c IR Ext PM6 x 10 mm M8 nut Screen Bezels M8 Washer M3 x 10 mm (Hidden M8 x 80 mm M3 x 6 mm Installation)
-
Page 7: Product Overview
Product Overview Front Panel I/O & Control Panel Speaker HDMI & Audio Out Speaker Rear Panel... -
Page 8: Before Installing
It is recommended to ask your reseller or licensed professional to install the LED Display. About the LED Display ViewSonic Direct View LDM231-251 is designed to be installed on the wall only. However, the System Control Box can be mounted in three different ways. - Page 9 Wall Mounting (Standard Installation) Eight Wall Mount Brackets are used for mounting the screen to the wall. Installing the Upper and Lower Wall Mount Brackets 10.5 Ø Ø 1. Ensure the wall area is an appropriate installation site. NOTE: Refer to page 11 for more information. 2.
- Page 10 6. Repeat Step 2~5 for the remaining two Upper Wall Mount Brackets. 7. Install the Lower Wall Mount Brackets in the same manner as the Upper Wall Mount Brackets. The distance between the Upper and Lower Wall Mount Brackets is 1440 8.
- Page 11 Spacing Instructions for Wall Installation (Standard Installation) mm (ceiling) 1440 Display 6132 mm (clearance) NOTE: • You can also install the Upper Wall Mount Brackets, hang the screen, and then install the Lower Wall Mount Brackets for a more precise fit. •...
- Page 12 Wall Mounting (Hidden Installation) When the System Control Box is installed behind the Cabinets, this installation type requires a different set of Wall Mount Brackets. You also need the System Control Box Mount Brackets to attach the System Control Box to the rear of the Cabinets. Wall Mounting Six Wall Mount Brackets are used for mounting the screen to the wall.
- Page 13 7. After installing both Upper and Lower Wall Mount Brackets, the installation wall should look like: 1335 1335 1335 10.5 Ø Ø After the Wall Mount Brackets are installed, please go to page 20 for the Cabinets (Hidden Installation). Spacing Instructions for Wall Installation (Hidden Installation) mm (ceiling) 1440 Display...
- Page 14 Wall Mounting (Separate Installation) When the System Control Box is installed apart from the Cabinets, this installation type shares the same Wall Mount Brackets as the Standard Installation. However, you will need to pre-drill additional holes for the System Control Box. Drill Hole Spacing for System Control Box Ensure there is enough space between the mounting holes and cable access holes.
- Page 15 Spacing Instructions for Wall Installation (Separate Installation) mm (ceiling) 1440 Display 55.5 6132 mm (clearance) System Control NOTE: • You can also install the Upper Wall Mount Brackets, hang the screen, and then install the Lower Wall Mount Brackets for a more precise fit. •...
- Page 16 Installing the Cabinets (Standard and Separate Installation) Place the Upper Cabinet section "D-1" and Lower Cabinet section "D-2" on stable furniture that can safely support the two Cabinet sections. NOTE: • One Cabinet is separated into two sections. Each section weighs around 18.6 •...
- Page 17 3. Carefully lift the assembled Cabinet "D" onto the center of the Upper Wall Mount Brackets. 4. Ensure the Mounting Brackets sit securely on the Wall Mount Brackets as shown below. Mounting Brackets Display Display Wall Mount Brackets...
- Page 18 5. Repeat Step 1~2 for Cabinet "E". 6. Install the assembled Cabinet "E" on the right side of Cabinet "D" with the provided screws (M8 x 20 mm). NOTE: There are 12 screws between each Cabinet.
- Page 19 7. Check for unevenness of the Cabinets by rubbing the cross section between each Cabinet. If the cross section is not aligned, loosen the M8 screws slightly and tap the Cabinets until the cross section is flat. 8. Repeat Step 1~2 for the remaining Cabinets and install them onto the Wall Mount Brackets.
- Page 20 Installing the Cabinets (Hidden Installation) Before installing the System Control Box behind the Cabinets, the Upper System Control Box Mount Bracket must be mounted to the Cabinets first. 1. Place the Upper Cabinet section "D-1" and Lower Cabinet section "D-2" on stable furniture that can safely support the two Cabinet sections.
- Page 21 3. Repeat Step 1~2 for Cabinet "E". 4. Install the Upper System Control Box Mount Bracket to the side of the two assembled Cabinets "D" and "E" as shown below using the provided screws (M8 x 20 mm). 1335 1335 1335 Rear View of Cabinet "E"...
- Page 22 6. Ensure the Mounting Brackets sit securely on the Wall Mount Brackets as shown below. Mounting Brackets Display Display Wall Mount Brackets...
- Page 23 10.5 Ø 7. Install the assembled Cabinet "E" on the right side of the Cabinet "D" with the Ø provided screws (M8 x 20 mm). Rear View of Cabinet "E" (left) and Cabinet "D" (right) NOTE: There are 12 screws between each Cabinet.
- Page 24 8. Check for unevenness of the Cabinets by rubbing the cross section between each Cabinet. If the cross section is not aligned, loosen the M8 screws slightly and tap the Cabinets until the cross section is flat. 9. Repeat Step 1~2 for the remaining Cabinets and install them onto the Wall Mount Brackets.
- Page 25 Connecting the System Control Box (Standard Installation) The left and right sides of the System Control Box are pre-installed with its Covers in the factory. The main system control board is on the right. The safety wires are used to prevent the Right Cover from falling when accessing the System Control Box.
- Page 26 Remove the Left Cover by gripping the top edge of the Cover and pulling it toward you. The Left Cover should simply lift away. 4. Secure the System Control Box panel with the Connector Plate using the provided screws (M3 x 6 mm). Further secure the Connector Plate with the two provided screws (M3 x 5 mm).
- Page 27 6. Align the holes of the Cabinets with the System Control Box to attach. Carefully route the Network and Power Cables through the holes in each Cabinet. 8. Install the System Control Box to the bottom of the Cabinets with the provided screws (M8 x 20 mm).
- Page 28 Connect the Network Cables (Green) of the Cabinets. Start from the bottom and move to the top. • Connect the four Network Cables from the System Control Box to Cabinet "B", "D", "F", and "H". Ensure to match the corresponding letters on the Network Cables to the Cabinets (B to B, D to D, F to F, and H to H).
- Page 29 10. Connect the Power Cables (Red/Orange) of the Cabinets. Start from the bottom and move to the top. • Connect the Power Cables from the System Control Box to the eight Cabinets. Ensure to match the corresponding letters on the Cables to the Cabinets (A to A, B to B, C to C, D to D, and so on).
- Page 30 11. Connect the two AC units of the System Control Box to the main system control board. 12. Connect the LED Display's left speaker to the Audio Out port. NOTE: Ensure that the right speaker is properly connected to the other Audio Out port.
- Page 31 13. Ensure the two AC units of the System Control Box is properly connected. DO NOT connect the System Control Box Power Cables at this time. System Control Box Power Cables • The neutral wires (usually white/blue) are connected to the "N1", "N2", and "N" terminals.
- Page 32 14. After connecting all Cables and wires, hold the top edge of the Right Cover toward the System Control Box to replace it. Once the Right Cover is replaced, it will be held in place magnetically. NOTE: Ensure the Power Button cable is connected before securing the Right Cover.
- Page 33 Connecting the System Control Box (Hidden Installation) The left and right sides of the System Control Box are pre-installed with its Covers in the factory. The main system control board is on the right. The safety wires are used to prevent the Right Cover from falling when accessing the System Control Box.
- Page 34 3. Install the provided screw (M8 x 16 mm) on the Lower System Control Box Mount Bracket. Thread the provided M8 nut onto the screw and fully tighten the nut. Installing the provided screw and nut to the Brackets (Rear View) 4.
- Page 35 6. Remove the pre-installed Power and Network Cables of the Cabinets from the System Control Box. NOTE: • There are eight Power and four Network Cables to remove. • It is recommended to take photos of the completed wiring in the left and main system control boards before removing the Cables.
- Page 36 After threading the Network Cables, please follow the diagram below to connect the longer Power Cables to the two AC units of the System Control Box. DO NOT connect the System Control Box Power Cables at this time. System Control Box Power Cables •...
- Page 37 10. Thread the Power Cables of the Cabinets through the hole provided in the System Control Box to the rear. Avoid sharp bends in the Cables. NOTE: • There are three Power Cables to thread. • The rubber hole plugs must always be placed in the holes. •...
- Page 38 14. Thread the Power and Network Cables through the holes at the lowest row of the Cabinets to the front. NOTE: • There are eight Power and four Network Cables to thread. • Ensure the corresponding letters on both Cables are matched to the Cabinets (A to A, B to B, C to C, and so on).
- Page 39 15. Carefully place the Lower System Control Box Mount Brackets onto the Upper System Control Box Mount Brackets. NOTE: To avoid sharp bends in the Cables, please pull them into the Cabinets and manage the Cables there. Placing the Lower System Control Box Mount Brackets to the Upper (Rear View) 16.
- Page 40 18. Route the Power and Network Cables around the rods provided in the Cabinets and secure the Cables to the rods with the Cable Zip Tie and screw (PM3 x 10 mm). Leave a little slack for later adjustments if needed. After the System Control Box is connected, please go to page 45 for the LED Modules.
- Page 41 Connecting the System Control Box (Separate Installation) The left and right sides of the System Control Box are pre-installed with its Covers in the factory. The main system control board is on the right. The safety wires are used to prevent the Right Cover from falling when accessing the System Control Box.
- Page 42 2. Connect the connector of the longer Power Cable to the power connector of the Cabinet. Then, connect one end of the longer Network Cable to the network port of the Cabinet. NOTE: • The longer Power and Network Cables are supplied in the case. •...
- Page 43 6. Carefully thread the Power and Network Cables through the holes provided in the System Control Box from behind. Ensure to use the correct cable holes for the Power and Network Cables. NOTE: • There are three Power and four Network Cables to thread. •...
- Page 44 11. Please follow Step 11-12 on page 30 for the system control board. NOTE: After the IR Extension Cable is connected, route it through the hole of the System Control Box to the rear. Connection port for IR Extension Cable IR Extension Cable hole 12.
- Page 45 Installing the LED Modules Please wear Anti-Static Gloves before handling the LED Modules. To avoid direct contact with the LED Modules, please remove watches, rings, bracelets, or other metal objects. Use caution when installing the LED Modules. 1. Starting from the LED Module labeled "1" in the top left corner, align each LED Module with the Cabinet, then carefully press the Module into place.
- Page 46 Installing the Screen Bezels (Standard Installation) The Screen Bezels' plastic tabs are pre-installed onto the Bezels. Ensure all plastic tabs are properly mounted before installing the Screen Bezels onto the screen. The label indicates the top of each Screen Bezel. To ensure the Bezels are installed in the correct position, please use the labels on the inside of the Bezels as a guide.
- Page 47 2. Align the plastic tabs of the Screen Bezel with the holes provided in the screen. 3. Press down on the Screen Bezel until you hear it click into place. 4. Place the remaining Screen Bezels onto the left and right sides of the screen. NOTE: ...
- Page 48 Installing the Screen Bezels (Hidden and Separate Installation) The Screen Bezels' plastic tabs are pre-installed onto the Bezels. Ensure all plastic tabs are properly mounted before installing the Screen Bezels onto the screen. The label indicates the top of each Screen Bezel. To ensure the Bezels are installed in the correct position, please use the labels on the inside of the Bezels as a guide.
- Page 49 At the bottom of the screen, loosen the screws securing the pre-installed Screen Bezel and remove it. This provides enough room to the bottom Screen Bezels. NOTE: • There are two pre-installed Screen Bezels to remove. • The pre-installed Screen Bezels come in with two different lengths. Remove the shorter ones.
- Page 50 Power Indicator Light will be a steady red. This means the LED Display is in standby mode. Please refer to the User Guide for more details. Your LED Display is now ready to power on. LDM231-251_QSG_1a_ENG_20240409 Copyright © 2024 ViewSonic Corporation. All rights reserved.
