Ecco EC7003-QM Installation Instructions Manual

Camera/monitor system

Advertisement

Quick Links

The EC7000-QK Camera and Monitor Kit from ECCO is designed
to provide a driver with video and audio from up to four cameras (kit
is supplied with one EC2014-C) individually or together on a split
screen for ultimate driver awareness. When properly installed and
used in conjunction with vehicle mirrors, ECCO's EC7000-QK assists
drivers during hazardous parking and backing situations. This manual
provides information about installation, function, safety, maintenance,
replacement parts and warranty.
!
WARNING!
Failure to install or use this product according to manufacturers recommendations may result in property damage, serious injury, and/or death to
those you are seeking to protect!
Do not install and/or operate this safety product unless you have read and understand the safety information
contained
1.
Proper installation combined with operator training in the use, care, and maintenance of emergency warning devices are essential to ensure
the safety of you and those you are seeking to protect.
2.
Exercise caution when working with live electrical connections.
3.
This product must be properly grounded. Inadequate grounding and/or shorting of electrical connections can cause high current arcing,
which can cause personal injury and/or severe vehicle damage, including fire.
4.
Proper placement and installation are vital to the performance of this warning device. Install this product so that output performance of the
system is maximized and the controls are placed within convenient reach of the operator so that s/he can operate the system without losing
eye contact with the roadway.
5.
It is the responsibility of the vehicle operator to ensure during use that all features of this product work correctly. In use, the vehicle operator
should ensure the projection of the warning signal is not blocked by vehicle components (i.e., open trunks or compartment doors), people,
vehicles or other obstructions.
Specifications:
Camera
Effective Pixels: 725 x 488
Voltage Requirement
Power Consumption
Lens
Lens Angle
Audio
Light Sensor
Infrared LEDs
Pigtail Connection: CAM
Housing
Mech. Vibration
Mounting
Dimensions (WxHxD)
Operating Temp.
IP Rating
Approvals
FCC, CE, C-Tick, E13/R10
Current Consumption
Installation, Wiring and Function
!
Caution! When drilling into any vehicle surface, make sure that the area is free from any electrical wires, fuel lines,
vehicle upholstery, etc. that could be damaged.
EC2014-C
1/3" CMOS PC1089 Color
12V
3 W
F=2.8mm / F=2.0
120°
Yes
Auto Switch B&W
11 (10M Max. Visibility)
Male 4 Pin Threaded
Aluminum Alloy
10g
Rear/Front
2.87"x2.99"x2.60"
-22°F to 158°F
IP69K
175mA Max
Installation Instructions
Camera/Monitor System
Monitors
Controller
Voltage
Power Consumption
Mirror Imaging
Split Screen Feature
AV Compatible
DVR Compatible
Audio
Contrast/Brightness
Light Sensor
Camera Selection
Connection: CAM
Connection (Monitor Pigtail)
Connection: CB
Housing
Mounting
Mech. Vibration
Weight
Dimensions (WxHxD)
Operating Temp
Remote Control
Approvals
EC7003-QM 7" LCD Monitor
7" LCD Color, 16:9
4 Camera
12-24VDC
25 W Max
Yes (via Camera and Monitor Switch)
Yes
Yes
No
Yes
Yes
Day/Night Auto Dim
1-4 Via Trigger Wires
Female 4 Pin Threaded
Male 22 Pin
N/A
Plastic
Permanent - HD (2 bracket options
provided)
Pedestal Bracket - 3G
Cradle Bracket - 8G
1.26 lbs
7.21"x5.04"x1.24"
4°F to 158°F
Yes
FCC, CE, RoHS
