KYLAND PTS-10A Web Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PTS-10A
Time Server
WEB Manual
Kyland Technology (Shanghai) Co., Ltd.
Version Copyright
R7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PTS-10A and is the answer not in the manual?

Questions and answers

Related Manuals for KYLAND PTS-10A

Summary of Contents for KYLAND PTS-10A

  • Page 1 PTS-10A Time Server WEB Manual Kyland Technology (Shanghai) Co., Ltd. Version Copyright...
  • Page 2 Kyland Technology (Shanghai) Co., Ltd. 20th Floor, No.399 Yungu Road, Jiading District, Shanghai，China Tel: +86-21-80321288 Fax: +86-21-80321289...

  • Page 3: Table Of Contents

    Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server Contents 1. Basic Features ........................4 1.1. Introduction ......................4 2. Operations ........................5 2.1. Login ........................5 2.2. Logout ........................5 2.3. Languages ......................6 2.4. Status ........................6 2.4.1. Time Information ..................7 2.4.2. Source Status .....................7 2.4.3.
  • Page 4 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server Notice for Safety Operation The product performs reliably as long as it is used according to the guidance. Artificial damage or destruction of the device should be avoided. Before using the device, read this notice carefully for personal and equipment safety.
  • Page 5 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server environmental pollution. In the following cases, please immediately shut down your power supply and contact your Kyland representative:  Water gets into the equipment.  Equipment damage or shell damage.  Equipment operation or performance has abnormally changed.

  • Page 6: Basic Features

    NTP/SNTP and PTP (IEEE1588 v2). IEEE1588 can works in several modes by the software configuration including grandmaster clock, slave clock and boundary clock. PTS-10A has LCD to show any status and do configuration by keyboard. Meanwhile, PTS-10A supports WEB and SNMP functions to manage system.

  • Page 7: Operations

    Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server Operations 2.1. Login Please connect PTS time server and PC by network cable. Open any WEB Browser of PC and input http://192.168.0.111 and press enter, the login WEB screen of PTS will be shown on your screen.

  • Page 8: Languages

    Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server [Figure 2- 2] Default Screen On the top right corner, system has a [Logout] option, if you want to logout system, you might directly click this and then system will go to original login screen and wait user to input login information again.

  • Page 9: Time Information

    Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server 2.4.1. Time Information On the top right navigation bar, there is an area to show the current local time. [Figure 2- 4] Time Information Screen 2.4.2. Source Status Press ‘Source Status’ on the left navigation bar to show source status screen.
  • Page 10 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server Items Parameters Description sources by source priority. Select ‘SAT2’ in Source Channel, the screen will be shown as: [Figure 2- 6] Source Status Screen (SAT2) Table 2 – Source Status Information (SAT2)
  • Page 11 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server [Figure 2- 7] Source Status Screen (IRIG-B1) Table 3 – Source Status Information (IRIG-B1) Items Parameters Description Show the time source status. Normal Source Status Normal: The time source can use; Alarm Alarm: The time source cannot use.

  • Page 12: Clock Status

    Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server Items Parameters Description lowest source. It has 10 levels. System can select best time sources by source priority. Select ‘PTP’ in Source Channel, the screen will be shown as: [Figure 2- 9] Source Status Screen (PTP) Table 5 –...
  • Page 13 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server [Figure 2- 10] Clock Status Screen Table 6 – Clock Status Information Items Parameters Description Show which time source is the current time source. SAT1 SAT1: The time source is SAT1 source channel.

  • Page 14: Configuration

    Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server Items Parameters Description Show the internal temperature. Temperature The 16383 means it has not temperature sensor inside. Frequency 0.000 Show the frequency or power grid. Longitude 0.00 Show longitude of geographic position information.
  • Page 15 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server [Figure 2- 12] Sync Source Setting Screen (SAT1) Table 7 – Sync Source Setting (SAT1) Item Parameter Description Set satellite receiver module to receive satellite signal. UBLOX5: Select UBLOX5 receiver module; UBLOX5 UBLOX8: Select UBLOX8 receiver module;...
  • Page 16 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server Item Parameter Description A-GLN: Make satellite priority working at GLONASS mode by mixed position fix mode with GLONASS and GPS, when GLONASS is invalid, it can work at GPS mode; F-BDS: Make satellite only working at BDS mode;...
  • Page 17 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server [Figure 2- 13] Sync Source Setting Screen (SAT2) Table 8 – Sync Source Setting (SAT2) Item Parameter Description Set satellite receiver module to receive satellite signal. UBLOX5: Select UBLOX5 receiver module; UBLOX5 UBLOX8: Select UBLOX8 receiver module;...
  • Page 18 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server Item Parameter Description A-GLN: Make satellite priority working at GLONASS mode by mixed position fix mode with GLONASS and GPS, when GLONASS is invalid, it can work at GPS mode; F-BDS: Make satellite only working at BDS mode;...
  • Page 19 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server [Figure 2- 14] Sync Source Setting Screen (IRIG-B1) Table 9 – Sync Source Setting (IRIG-B1) Item Parameter Description Set the priority for time source. 1 is highest source and 10 is Source 1~10 lowest source.
  • Page 20 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server If select ‘IRIG-B2’ in Source Channel, the setting screen will be shown as: [Figure 2- 15] Sync Source Setting Screen (IRIG-B2) Table 10 – Sync Source Setting (IRIG-B2) Item Parameter Description Set the priority for time source. 1 is highest source and 10 is...

  • Page 21: Clock Settings

    Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server If select ‘PTP’ in Source Channel, the setting screen will be shown as: [Figure 2- 16] Sync Source Setting Screen (PTP) Table 11 – Sync Source Setting (PTP) Item Parameter Description Set the priority for time source. 1 is highest source and 10 is...
  • Page 22 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server [Figure 2- 17] Clock Setting Screen Table 12 – Clock Setting Items Parameters Description Set reference time as required. UTC: Make reference time work at UTC format; Time Reference TAI: Make reference time work at TAI format.
  • Page 23 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server Items Parameters Description parameter will be set by manual. Set signal output mode. Always Always: Any interfaces can output signal for any time. Output Mode Lock Lock: Any interfaces only can output signal after the first time synchronization with any time source.
  • Page 24 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server Items Parameters Description Set start parameters for DST starting time. Set start time to define what time to start DST. Format is 24 hours format. Start Time 00:00~24:00 Range is between 00:00 and 24:00.

  • Page 25: Ntp Settings

    Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server Items Parameters Description Set stop time to define what time to start DST. Format is 24 hours format. Range is between 00:00 and 24:00. Default value is 00:00. The Daylight Saving Time (DST) will define by what month, week, day and time to stop.
  • Page 26 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server [Figure 2- 19] PTP Setting Screen Table 14 – PTP Setting Items Parameters Description Set PTP Clock working mode. Master: Set PTP Clock working at Master of OC mode. Master Slave: Set PTP Clock working at Slave of OC mode.
  • Page 27 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server Items Parameters Description Set PTP Clock sending delay measurement message rate of Slave mode. -8~4: Set a number for interval. If it is n, the actual interval is Delay seconds. -8~4 Measurement STOP: Don’t send delay measurement message.

  • Page 28: Output Settings

    Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server Items Parameters Description Priority Range is between 0 and 7. Default value is 0. Set vLan CFI information of PTP message. VLan Range is between 0 and 1. Default value is 0.
  • Page 29 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server Items Parameters Description Range is between -999999999s and 999999999s. Default value is 0s. Set reference time for TOD output signal of SO. UTC: Make output time working at UTC format; Time Format TAI: Make output time working at TAI format.
  • Page 30 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server Items Parameters Description PPH: Set output signal is PPH. The PPS is pulse signal. It is one pulse per second. The PPM is pulse signal. It is one pulse per minute. The PPH is pulse signal. It is one pulse per hour.
  • Page 31 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server [Figure 2- 22] Output Setting Screen (O2) Table 17 – Output Setting (O2) Items Parameters Description Set output signal type for O2. PPS2: Set output signal is PPS; PPS2 IRIG-B2: Set output signal is IRIG-B;...
  • Page 32 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server Items Parameters Description Polarity +: positive polarity DC, high level is 1; -: negative polarity DC, low level is 1. Press ‘Save’ button to save the current setting when you change setting.
  • Page 33 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server Items Parameters Description Format Local TAI: Make output time working at TAI format. Local: Make output time working at Local format. Set IRIG-B check code for O3. IRIG-B Even Even: Use Even mode check code to code IRIG-B signal;...
  • Page 34 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server Items Parameters Description Set PPS compensation offset for O4. Unit is nanosecond(ns); Compensation Range is between -250000000ns and 250000000ns. Default value is 0ns. Set reference time for IRIG-B output signal of O4.
  • Page 35 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server Items Parameters Description The PPM is pulse signal. It is one pulse per minute. The PPH is pulse signal. It is one pulse per hour. Set second compensation offset for O5. Second Unit is second(s);...

  • Page 36: Network Settings

    Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server Items Parameters Description Step is 0.5V; Range is between 3.0V and 12.0V. Default value is 12.0V. The modulated IRIG-B signal has the same encoder with O1 output channel, the other parameters please refer to O1 output parameters.

  • Page 37: Tms Settings (Optional)

    ETH0:255.255.255.0 IP Mask Address XXX.XXX.XXX.XXX ETH1:255.255.255.0 ETH2:255.255.255.0 ETH3:255.255.255.0 PTS-10A can provide more network types. One of them can set ETH0/ETH1 mode work with Auto or work with Auto, 100M and 1000M fiber. 100M-FX FDX, Auto: 100M/1000M Copper automatic mode; Interface Mode 100M-FX-HDX, 100M-FX FDX: 100M Optical full duplex mode;...
  • Page 38 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server [Figure 2- 28] GOOSE Publisher Screen (GOOSE-P0) Table 22 – GOOSE Publisher Setting (GOOSE-P0) Items Parameters Description Activate GOOSE publisher feature for ETH0. Enable GOOSE Publisher Enable: Make GOOSE publisher start working;...
  • Page 39 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server Items Parameters Description Set GCB reference of GOOSE message. It is a string defined by GOOSE standard. GOOSE GoCBRef PTSTTR/LLN0$GO$gocb0 Default value is PTSTTR/LLN0$GO$gocb0. Provide IEC61850 ICD file, the current default value is made by this ICD file.
  • Page 40 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server Items Parameters Description Default value is 7. Set vLan CFI information of GOOSE message. vLan CFI Range is between 0 and 1. Default value is 0. Set vLan ID information of GOOSE message.
  • Page 41 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server Table 23 – GOOSE Publisher Setting (GOOSE-P1) Items Parameters Description Activate GOOSE publisher feature for ETH1. Enable GOOSE Publisher Enable: Make GOOSE publisher start working; Disable Disable: Make GOOSE publisher stop working.
  • Page 42 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server Items Parameters Description The 0 means no data change and the non- zero means system will send a new GOOSE when the current time at PPS, PPM or PPH can be divisible by trigger period.
  • Page 43 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server If select ‘GOOSE-S0’ in GOOSE Channel, the setting screen will be shown as: [Figure 2- 30] GOOSE Subscriber Screen (GOOSE-S0) Table 24 –GOOSE Subscriber Setting (GOOSE-S0) Items Parameters Description Activate GOOSE subscriber feature for ETH0.
  • Page 44 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server Items Parameters Description Provide IEC61850 ICD file, the current default value is made by this ICD file. Set the entry index of GOOSE message. Range is between 0 and 31. Entry 0~31 Default value is 0.
  • Page 45 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server Items Parameters Description Disable Enable: Make GOOSE subscriber start working; Disable: Make GOOSE subscriber stop working. Set APPID of GOOSE message. Range is between 0x0000 and 0xFFFF. 0xXXXX Default value is 0x0002.

  • Page 46: System

    Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server Press ‘Save’ button to save the current setting when you change setting. 2.6. System The WEB management system supports to manage Gateway, Route information and to backup and restore configuration file, in the same time it also supports firmware management and log management of PTS time server by WEB.

  • Page 47: Route

    Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server [Figure 2- 33] Gateway Screen The current routing table will be listed on the bottom of screen. Press ‘Add’ to add a new gateway for PTS time server. Press ‘Del’ to delete the selected route information.

  • Page 48: Configuration

    Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server 2.6.3. Configuration Press ‘Configuration’ on the left navigation bar to backup and restore configuration file. The configuration screen will be shown as: [Figure 2- 35] Configuration Screen Press ‘Backup’ and system will pop-up a tip window, let user to select a directory to save configuration file.

  • Page 49: Snmp (Optional)

    Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server [Figure 2- 37] Log Screen Log management supports to view and export log file to local. The each page will show the maximum 20 log items. More log will show the others page. You might change by navigation bar of top page.

  • Page 50: Management

    Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server [Figure 2- 38] SNMP Screen SNMP management supports to modify agent port and to add or delete V1/V2C, V3 and TRAP access parameters. The default agent port of SNMP is 161 and the default trap port of SNMP is 162.

  • Page 51: Reboot

    Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server password screen will be shown as: [Figure 2- 40] Change Password Screen Please ‘Save’ to confirm the new password. 2.7.2. Reboot Press ‘Reboot’ on the left navigation bar to reboot device. The reboot screen will be...
  • Page 52 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server Table Index Table 1 – Source Status Information (SAT1) ..............7 Table 2 – Source Status Information (SAT2) ..............8 Table 3 – Source Status Information (IRIG-B1) ...............9 Table 4 – Source Status Information (IRIG-B2) ...............9 Table 5 –...
  • Page 53 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server Figure Index [Figure 1- 1 ] PTS-10A Time Server ..................4 [Figure 2- 1 ] Login Screen ....................5 [Figure 2- 2 ] Default Screen ....................6 [Figure 2- 3 ] Status Screen ....................6 [Figure 2- 4 ] Time Information Screen ................7 [Figure 2- 5 ] Source Status Screen (SAT1) ................
  • Page 54 Kyland Technology (Shanghai) Co., Ltd PTS-10A Time Server [Figure 2- 34 ] Route Screen ....................45 [Figure 2- 35 ] Configuration Screen ................46 [Figure 2- 36 ] Firmware Screen ..................46 [Figure 2- 37 ] Log Screen ....................47 [Figure 2- 38 ] SNMP Screen ....................48 [Figure 2- 39 ] Management Screen ................48...
