Instruction Manual for LED HTPAR56B-P-T
Models: HTPAR56B-P-T
Manufacturer: Hentech Technology Development Co., LTD
Add: No. 58 Tianren Industrial Estate, Liandu Village, Leliu Town, Sh unde District,
Foshan City, Guangdong, China 528322
Telephone: +86-757-22609165/22609168/22609169
Fax: +86-757-22609170
Website: http://www.hentech.cn/en
IMPORTANT: This manual includes essential information on the safety measures to be
implemented for installation and start-up. Therefore, the installer, as well as the user,
must read these instructions before beginning installation and start-up.
Technical Specification
Standard input voltage: 12V AC/DC (Range: 12~18VAC or DC)
Standard input watt:
RGB
18W
23W
30W
33W
40W
White
21W
26W
33W
36W
45W
Use life: 60,000 hours
16 programs with Synchronization capability
Dimension
Instruction & Use
This is a high technology electronic controlled light based on LED's in three colors: red, green
and blue. These three base colors together can produce many other colors to create the perfect
atmosphere in the pool. Any of the 16 pre-programmed effects can be selected with the on/off
55W
60W
Advertisement
Related Manuals for hentech HTPAR56B-P-T
Summary of Contents for hentech HTPAR56B-P-T
- Page 1 Instruction Manual for LED HTPAR56B-P-T IMPORTANT: This manual includes essential information on the safety measures to be implemented for installation and start-up. Therefore, the installer, as well as the user, Models: HTPAR56B-P-T must read these instructions before beginning installation and start-up.
- Page 2 switch of your pool lights. The LED’s can also be warm white only or natural white only. The LED’s are driven by constant current. The technology of True PWM is adopted on the lights. High temperature protection makes the LED’s be protected while the internal temperature reaches a high level.
- Page 3 If the cable pipes you use has inner diameter 26mm or more, you can use the retrofit connector to connect the cable easily. Simply crimp both connections with the splice connectors, slide the Safety Warnings cable sleeve over the connection and hand tighten the gland nuts. Then hide the retrofit The persons who are in charge of installation should have the required qualifications for this type connector in the pipe.
- Page 4 Plastic fixing clip M5*15 SS self-tapping screw Cable rolling clip M5*12 SS self-tapping screw...
