- Page 1 Weather Station Product Model: WP-2S...
-
Page 2: Installation Preparation
Weather Station-Installation Guide Installation Preparation Please confirm the checklist before installation. If any damage, loss or 1 .1 Checklist inconformity are found in the devices or parts, please contact the manufacturer immediately. Tip: Please do not disassemble the connected wiring. 1.Sm Bracket Expansion Screw lrradiance Sensor x2... -
Page 3: Installation
Weather Station-Installation Guide Installation 2. For safety reasons, please cover the wire with PVC pipe. If the wire must 2.1 Bracket Installation go underground, please take waterproof measures and install an air switch. 3. Please use the concrete of grade C25 or above to make cement platform. (Diameter>80cm, Thickness>25cm) Integrated 'w'eo ther Sto tion... - Page 4 Weather Station-Installation Guide Warning: 2. Unscrew the protective cover of irradiance Sensor. The lightning rod is required, if the installation site is in the wild. The lightning rod is quite dangerous, please mind your own safety. IGEN is not responsible for the damage caused by no lightning rod.
- Page 5 Weather Station-Installation Guide 2.4 Integrated Sensor Installation 1. Please confirm that N sign should point to the north. □ Installation without lighting rod Installation with lighting rod 2.5 Junction Box Installation 2. If you do not want to install a lightning rod, please install the integrated Please fix the junction box on the bracket and tighten the screws.
- Page 6 Weather Station-Installation Guide Connection 3.2 Connection between Logger and Weather Station 1. Connect 485A (Green) to logger interface A. 3.1 Integrated Sensor Connect 4858 (Blue) to logger interface B. Connect a temperature sensor with an integrated sensor via this wiring. 2.
- Page 7 Weather Station-Installation Guide 3. Check if the wiring is correct 4. Connect L-line and N-line according to UN sign. Power on the device and all indicator lights keep on. Connection Diagram Warning, 1.Please double check the connection and power on. 2.Please make sure the DC connection is correct.
- Page 8 Weather Station-Installation Guide 2. Registration on SOLARMAN SMART USER MANUAL for SOLARMAN APP Go to SOLARMAN Smart and register. Click "Register" and create your account here. 1. Download app ..-·- - --- ------ ------ ____ T ______ _____________ _ �...
- Page 9 Weather Station-Installation Guide 4. Add a Device 5. Network Configuration [fhis step is required for logger (WiFi). For Method 1: Enter logger SN manually. logger (GPRS)/logger (4G), users can skip this step.]After the logger is Method 2: Click the icon in the right and scan to enter logger SN. You can added, please configure the network to ensure normal operation.
- Page 10 Weather Station-Installation Guide Step 2: Connect to AP network Step 1: Confirm WiFi Info Click "Go to connect" and find the right "AP _XXXXX" network. Please make sure your phone has connected to the right WiFi network. {XXXXX refers to logger SN). And click "Start".
- Page 11 ....<-- Device Configuration Connect to <ltWlce Conhguring • • If configuration failure occurs, please check the following reason and try it again. (1) Make sure WLAN is ON. (2) Make sure WiFi is normal. (3) Make sure wireless router does not implement the white-black list.
