- Page 1 S E T U P M O N T A J E S M E L L Y F A N T E L E L S L E D...
-
Page 2: Technical Specifications
CONTENTS CONTENIDO 1 x Body Cuerpo 2 x Ears Orejas 1x Allen key No. 2,5 Llave allen 2.5 TECHNICAL SPECIFICATIONS ESPECIFICACIONES TÉCNICAS Integrated LED LED Integrado Europe US & Canada 220 - 250V 50Hz 120V Class I Clase I Led module Led module 230V 120V... - Page 3 ASSEMBLY INSTRUCTIONS INSTRUCCIONES DE MONTAJE OPEN ACCESS PATCH ABRIR REGISTRO Open the access patch located on the upper back of the elephant, by unscrewing the 4 screws that hold it using an Allen key. Abra el registro ubicado en la parte superior de la espalda del elefante.
- Page 4 ASSEMBLY INSTRUCTIONS INSTRUCCIONES DE MONTAJE FIX EARS FIJAR OREJAS Undo the fly nuts at the end of the rods of each ear. Insert the rods in the tubes and then fix the ears by screwing back in the fly nuts. Fix them tightly.
- Page 5 ASSEMBLY INSTRUCTIONS INSTRUCCIONES DE MONTAJE CONNECTION CONEXIÓN Plug in the lamp and press the pulse-button to turn on. PULSE-BUTTON Conecte la lámpara y presione el pulsador para BOTÓN-PULSADOR encenderla. Lamp Lámpara * Example drawing. Plug changes accordingly to the stan- dard of the territory.
-
Page 6: Useful Information
Ivory White 20, Natural Beech 22 y Natural Cherry 21: 3000 o 4000k. Amarillo 24, Naranja 25, Rojo 26, Chocolate 31 y Rosa Palo 33: 3000k. MORE INFO: http://www.lzf-lamps.com/guarantee/ MÁS INFORMACIÓN: http://www.lzf-lamps.com/guarantee/ © Luziferlamps, S.L All rights reserved. Valencia, Spain. 2020 - www.lzf-lamps.com - support@lzf-lamps.com REV. 05 05-2024 D88_339...
