DOUBLE DOOR MAGNETIC LOCK
INSTALLATION INSTRUCTIONS
ENGLISH
USER MANUAL
0E-MAG600DB (600 lbs.)
0E-MAG1200DB (1200 lbs.)
TABLE OF CONTENTS
Introduction...................................................2
Safety and Compliance................................3
Installation and Maintenance.....................4
Wiring.............................................................6
Troubleshooting...........................................8
Warranty.........................................................9
UL 1034 / UL 294
Standard for Burglary-Resistant
Electric Locking Mechanisms
Special Locking Arrangement Component
Electric Locking Mechanism
Access Control Accessory
ADI PRO TECHNICAL SUPPORT
1.833.574.9124
ORDERS
US: 1.800.233.6261
Canada: 1.877.234.7378
WEBSITE
US: adiglobal.com/adiexclusivebrands
Canada and PR: adiglobal.com
V3, 04-23
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ADI PRO 0E-MAG600DB
Summary of Contents for ADI PRO 0E-MAG600DB
-
Page 1: Table Of Contents
DOUBLE DOOR MAGNETIC LOCK INSTALLATION INSTRUCTIONS Special Locking Arrangement Component Electric Locking Mechanism Access Control Accessory ENGLISH USER MANUAL 0E-MAG600DB (600 lbs.) 0E-MAG1200DB (1200 lbs.) TABLE OF CONTENTS Introduction...........2 Safety and Compliance........3 Installation and Maintenance.....4 Wiring.............6 Troubleshooting...........8 Warranty............9 ADI PRO TECHNICAL SUPPORT 1.833.574.9124... -
Page 2: Introduction
1 - User Manual DESCRIPTION ADI PRO double door magnetic locks are the perfect solution for securing buildings in a cost-effective way. These locks are vandal resistant and compatible with all access/egress systems, making them easy to integrate into your existing security setup. -
Page 3: Safety And Compliance
SAFETY AND COMPLIANCE READ ALL INSTRUCTIONS BEFORE INSTALLING THE MAGNETIC LOCK Note: The maglocks are factory set to 24 VDC. If required, adjust the setting to match power source: 1. Remove Phillips head screw to access wiring compartment. 2. Toggle the 12V/24V slide switch to select the desired voltage. Phillips Head Screw Wiring compartment... -
Page 4: Installation And Maintenance
INSTALLATION AND MAINTENANCE IMPORTANT NOTES • Install in an indoor dry location. • Use caution when changing factory default setting and ensure the power input matches voltage before powering on. • It is recommended to apply a light coat of sillicone lubricant to the mating surface on a monthly basis to prevent rust. - Page 5 INSTALLATION AND MAINTENANCE INSTALLATION INSTRUCTIONS Outswing Door Outswing Door Installation Template Door Frame Template Door Door Out Swing Place the template against the door Fold the 0E-MAG Template along Close the door, position the EM lock & frame and drill holes according to the dotted line upto 90°.
-
Page 6: Wiring
WIRING CARD ACCESS Access Controller N.O. Input Trigger Ground To cut off power to the maglock Output Relay (Dry) for the duration of the output, Normally Open Fire Rated Power the access controller will send a dry contact closure to the input Supply for Maglocks of the fire-rated power supply. - Page 7 WIRING MOTION DETECTOR Motion Detector When the motion detector N.O. Input Trigger Ground Motion detects a presence its normally open contacts go closed and Detector trigger the fire-rated power Fire Rated Power supply to unlock the maglock. Supply for Maglocks The maglock will be unlocked for the output duration set in the motion detector.
-
Page 8: Troubleshooting
TROUBLESHOOTING Problem Statement Solution Low holding force • Maglock is set to 24VDC; however, the power supply is 12VDC • The armature plate is misaligned and does not provide complete coverage. • Unregulated/unfiltered power supply with AC ripple (fluctuating voltage level) Maglock is extremely •... -
Page 9: Warranty
Subject to the terms and conditions of this Limited Warranty, from the date of sale through the period of time for product categories specified in Section 1(b), ADI warrants its ADI PRO products to be free from defects in materials and workmanship under normal use and service, normal wear and tear excepted. - Page 10 If any ADI PRO product is found to be in good working order or such product’s inability to function properly is a result of user damage or abuse, the product will be returned to Buyer in the same condition as received and Buyer shall be responsible for any return freight changes.
