PU3 Underwater LED Light
PU3MLP, PU3MLP+B – Concrete Pools
PU3MLPW, PU3MLPW+B – Concrete Pools
PU3MLPL, PU3MLPL+B – Liner Pools
PU3MLPWL, PU3MLPWL+B – Liner Pools
IMPORTANT:
READ CAREFULLY BEFORE USE. KEEP FOR FUTURE REFERENCE.
Notice to Installer:
The information within this document must be read
before the installation and start-up of this product.
Once the product has been installed this document
must be given to the owner/operator of this equipment.
WARNING:
The RGBW Constant Current 350mA light will be damaged
beyond repair if it is overpowered.
Please ensure that the Constant Current Driver (R4-CC)
is set to 350mA before powering on.
Warranty is not applicable if used incorrectly.
WARNING
A qualified electrician must carry out all
electrical wiring in accordance with local electrical regulations.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Certikin PU3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for fluidra Certikin PU3

  • Page 1 PU3 Underwater LED Light PU3MLP, PU3MLP+B – Concrete Pools PU3MLPW, PU3MLPW+B – Concrete Pools PU3MLPL, PU3MLPL+B – Liner Pools PU3MLPWL, PU3MLPWL+B – Liner Pools IMPORTANT: READ CAREFULLY BEFORE USE. KEEP FOR FUTURE REFERENCE. Notice to Installer: The information within this document must be read before the installation and start-up of this product.
  • Page 2: Safety Notices

    Product conformity information This product complies with the following Statutory Instruments and Directives: S.I. 2016:1091 ECR 2016 & 2014/30/EU EMC S.I. 2012:3032 RoHS 2012 & 2011/65/EU Directive: RoHS Directive: • 22/30441335 DC • BS EN IEC 62351-4:2018+A1:2020 • BS EN IEC 61000-3-2:2019+A1:2021 •...
  • Page 3: About The Product

    About the product The PU3 LED Light is a full colour changing or mono-colour (RGBW), or single white (W) light. The RGBW unit offers the flexibility to allow a choice of colours and shades, create programmable lighting sequences and to be dimmable. The W unit is a simple on/off white light It can be used as a stand alone light, or in multiples.
  • Page 4 Technical Specification (Concrete Pool Lights) Model PU3MLP, PU3MLP+B PU3MLPW, PU3MLPW+B Rated Power Input 24VDC 12VDC Drive Mode External Constant Current Driver (Model: R4-CC) Drive Current RGBW: 350mA Control WIFI 104 Switch power on/off Product Dimension (We reserve the right to change product dimensions without notice if this does not compromise the...
  • Page 5 Technical Specification (Liner Pool Lights) Model PU3MLPL, PU3MLPL+B PU3MLPWL, PU3MLPWL+B Rated Power Input 24VDC 12VDC Drive Mode External Constant Current Driver (Model: R4-CC) Drive Current RGBW: 350mA Control WIFI 104 Switch power on/off Product Dimension (We reserve the right to change product dimensions without notice if this does not compromise the...
  • Page 6: Installation

    Installation WARNING This equipment must be installed by qualified persons only. Improper installation can create electrical hazards which could result in property damage, serious injury or death. Improper installation and servicing will void the warranty. WARNING A qualified electrician must carry out all electrical wiring in accordance with local electrical regulations.
  • Page 7 For vinyl liner pools – PU3MLPL, PU3MLPWL, PU3MLPL+B, PU3MLPWL+B List of supplied components • PU3 LED Light incl 20m cable pre-wired • Information for use document This light is designed to be installed into a Certikin liner inlet fitting connected to either 1 ”...
  • Page 8 RGBW lights Each RGBW light requires its own R4-CC driver unit (supplied separately) but multiples can be powered and controlled by a single power supply and Wi-Fi 104 receiver/transmitter (supplied separately). The following control items are recommended and available from Certikin, for powering of up to 26 lights: PU2MLPS Power Supply 24v 320w...
  • Page 9 White (W) lights: White lights operate as a simple switch power on/off only, however multiple lights can be powered by a single power supply. The following power supply is available from Certikin, for powering of up to 16 lights: PU2MLPS12V Power Supply 12v 320W (White light only) WARNING Refer to and follow in the installation and operation instructions of each individual...
  • Page 10: Operation

    Operation: RGBW lights are operated via the control unit and/or App provided with the Wi-Fi 104 unit. Please refer to these instructions for operational procedures relating to the light. White lights are controlled by an in-line switch (not supplied) – this switch can be manual or automatic/timed.
  • Page 11 Notes:...
