GENERAL PUMP
FEATURES
• Shockproof plastic housing
• Internal construction of brass and
Stainless Steel
SPECIFICATIONS
Part Number
Maximum Volume
Rated Discharge Pressure
Maximum Discharge Pressure
Maximum Fluid Temperature
Inlet Port Thread
Discharge Port Thread
Weight
Dimensions
Materials
DIMENSIONS
General Pump
is a member of
the Interpump Group
A member of the Interpump Group
Straight, Rear Entry Spray Gun
• Ergonomic design
• Minimizes fatigue for the operator
YG4032S
32 GPM
4,050 PSI
4,500 PSI
210⁰ F
1/2" NPT-F
1/2" NPT-F
2.8 lbs
10.08" x 6.68" x 1.2"
Stainless Steel, Brass, Plastic,
Viton
YG4032S
Ref 300944 Rev. J
01-24
Advertisement
Related Manuals for Interpump Group General Pump YG4032S
Summary of Contents for Interpump Group General Pump YG4032S
- Page 1 YG4032S GENERAL PUMP A member of the Interpump Group Straight, Rear Entry Spray Gun FEATURES • Shockproof plastic housing • Ergonomic design • Internal construction of brass and • Minimizes fatigue for the operator Stainless Steel SPECIFICATIONS Part Number YG4032S...
- Page 2 YG4032S GENERAL PUMP A member of the Interpump Group Straight, Rear Entry Spray Gun PARTS LIST No. Part No. Description Qty. No. Part No. Description Qty. Y30403831 Front Plug, M18x1.5, Brass 11. Y30068135 Housing 2.* Y30404524 Piston + Seal Kit 12.
